Globe S13 Instruction Manual

Vegetable hopper
Hide thumbs Also See for S13:

Advertisement

Quick Links

Vegetable Hopper Assembly
Vegetable Hopper Assembly
Models: S13, SG13, S13A & SG13A
For all after sales support, visit www.globefoodequip.com
For additional Technical Support call Globe at 1-866-260-0522.
This manual contains important safety instructions which
Maintain and use this manual as a reference for training.
Instruction Manual for the
Complete the Warranty Registration
Find an Authorized Servicer
View Parts Catalogs
Download an Electronic Copy of the Owner's Manual
- IMPORTANT SAFETY NOTICE -
must be strictly followed when using this equipment.
Model #:
Serial #:

Advertisement

loading
Need help?

Need help?

Do you have a question about the S13 and is the answer not in the manual?

Questions and answers

Summary of Contents for Globe S13

  • Page 1 View Parts Catalogs • Download an Electronic Copy of the Owner’s Manual For additional Technical Support call Globe at 1-866-260-0522. - IMPORTANT SAFETY NOTICE - This manual contains important safety instructions which must be strictly followed when using this equipment.
  • Page 3 INSTALLATION ..............................4 OPERATION ..............................5 DISASSEMBLY ..............................6 GLOBE FOOD EQUIPMENT CO. 2153 DRYDEN RD. DAYTON, OH 45439 Toll Free: 800-347-5423 PHONE: 937-299-5493 EMAIL: info@globefoodequip.com WEBSITE: www.globefoodequip.com © Globe Food Equipment Company, 2024 980136 Ver. 1 Rev. A 10-2024 Page 3...
  • Page 4: Installation

    Installation 1. Hold end weight and unscrew end weight slide rod (Figure 4-1). Figure 4-1. End Weight Slide Rod 2. Pull end weight slide rod out of end weight (Figure 4-2). End Weight 3. Remove end weight and end weight slide rod from food chute. Figure 4-2.
  • Page 5: Operation

    Operation SHARP KNIFE BLADE TO AVOID SERIOUS PERSONAL INJURY: • NEVER touch rotating knife. • ALWAYS keep hands clear of all moving parts. • NEVER put hands/fingers into vegetable hopper during operation. ONLY USE VEGETABLE HOPPER END WEIGHT ASSEMBLY to push vegetables into vegetable hopper.
  • Page 6 Disassembly 1. Remove vegetable hopper end weight assembly from vegetable Food Chute hopper. 2. Loosen two knobs that secure vegetable hopper to food chute Knob (Figure 6-1). 3. Remove vegetable hopper from food chute. Figure 6-1. End Weight 4. Reinstall end weight. Align end weight with food chute and insert Slide Rod end weight slide rod through food chute and end weight (Figure 6-2).
