L E D S T A T U S I N D I C A T O R S
Status indications are displayed on the V-shaped LED of the V-BOX Pro Charging Station. The Power Button LED on the
right-hand side of the unit indicates if the charging station is switched on.
F U N C T I O N & S T A T U S I N D I C A T I O N
( V - S H A P E D L E D )
F U N C T I O N
S T A T U S
LED displays
Normal status light
Has power, not connected
Connected, not charging
Charging
Charging complete
Communication error
Surge-voltage protection
Low-voltage protection
Surge-current protection
Leakage protection
High-temperature protection
Current fault / short circuit
L E D C O L O R
(Red) (Blue) (Green) (Yellow)
On- Flashing- Off-
P O R T A B L E E V D I A G R A M
Charger-connection
status
Power status
On/Off
Charging
status
Error
indicator
