3500263
Please read all instructions carefully before use and
retain for future reference.
CAUTION Do not immerse in water.
Wear a dust mask.
Protect your eyes.
Protect your ears.
To reduce the risk
of electric shock
or injury, do not
expose to wet
conditions.
Risk of explosion.
Do not spray with
flammable liquids.
A5P | 01
Protect your hands.
ATTENTION This appliance has a thermal cut out
switch. The thermal cut out will activate and shut down
the appliance should the appliance overheat.
Unplug from the mains and or battery and allow to cool
for 30 minutes before re-use.
Do not use chemicals or detergents that are toxic,
flammable, or high in acidic/alkaline base with this
Pressure Washer.
Always use a detergent that has been specifically
manufactured for pressure washer use.
Always exercise extreme caution when using the
Pressure Washer not to direct the water jet at items
other than the surface intended.
The user is responsible for using this Pressure Washer
safely and as instructed in this manual. DOMU Brands
Ltd cannot be held responsible for damage to property
resulting from misuse of the Pressure Washer, or the
use of detergents not suitable for the intended task.
WARNING – RISK OF INJECTION! Unit will start
spraying when trigger is squeezed. When turning the
unit off after use, high pressure still exists inside the
hose and unit. Point the lance in a safe direction and
discharge the excess pressure. NEVER direct the high
pressure water stream at people or animals.

Advertisement

loading
Need help?

Need help?

Do you have a question about the A5P 01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VonHaus A5P 01

  • Page 1 3500263 Protect your hands. Please read all instructions carefully before use and retain for future reference. ATTENTION This appliance has a thermal cut out switch. The thermal cut out will activate and shut down CAUTION Do not immerse in water. the appliance should the appliance overheat.
  • Page 2 Please read all instructions carefully before use and retain machine in unexpected situations. for future reference. Dress appropriately. Do not wear loose clothing or jewellery. INTENDED USE Only operate the power tool/machine Keep your hair, clothing and gloves away from moving for its intended purpose and within the parameters parts.
  • Page 3 maintenance on the tool. store indoors while not in use”. Use only extension cords with an electrical rating equal to or greater than Maintain your power tool. Check for misalignment or the rating of the Pressure Washer. binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation.
  • Page 4: Technical Specification

    Always turn the water supply on first before turning the Never leave the Lance Trigger Handle assembly Pressure Washer on. Running the pump dry can cause unattended whilst the Pressure Washer is running. serious damage. When moving the machine, always transport by the Make sure the inlet water pressure remains between Carry Handle.
  • Page 5 COMPONENTS 1. Short Handle 2. Accessory Holder 3. Lance Hook 4. Switch 5. Nozzle 6. Extension Wand 7. High Pressure Lance 8. Cleaning Pin 9. Pressure Hose 10. Water Inlet Connector 11. Power Cord Hook 12. Detergent Bottle A5P | 01...
  • Page 6 ASSEMBLY 4.8*20 3.5*16 A5P | 01...
  • Page 7 ASSEMBLY A5P | 01...
  • Page 8 ASSEMBLY Push to Release A5P | 01...
  • Page 9 ASSEMBLY A5P | 01...
  • Page 10 SAFETY LOCK OFF Ensure that the water source is not placed more <50cm than 50cm lower than the Pressure Washer inlet. Ensure that the water source is not placed more than 50cm higher than the Pressure Washer inlet. After starting the Pressure Washer, wait for water to flow out from the Lance, and then connect the nozzle to use.
  • Page 11 SPRAY NOZZLE ADJUSTMENT (Fig 1) The adjustable nozzle will allow you to use any variety of spray patterns from a full fan spray to a direct (Fig 2) stream spray When using the pressure washer to clean wood decks, siding, vehicles etc., always start using the fan spray and begin spraying from a minimum 36”...
  • Page 12 USING THE DETERGENT BOTTLE A5P | 01...
  • Page 13 USING THE DETERGENT BOTTLE SWITCHING OFF / ON A5P | 01...
  • Page 14 AUTO ON/OFF The Pressure Washer is equipped with an automatic on/ off switch. The Pressure Washer will only run when the power switch is in the ON position and the trigger on the lance is squeezed. When you release the trigger to stop spraying water through the lance, the motor on the Pressure Washer will automatically shut off.
  • Page 15 CLEAN UP AND STORAGE SHUTTING DOWN THE CLEANER. Remove water intake filter and flush with water to remove dirt and debris, return filter once cleaned. Turn the Pressure Washer off. Empty and clean the detergent reservoir. Turn off the water supply. Wipe away any remaining water on any parts or components.
  • Page 16: Cleaning Tips

    CLEANING TIPS WOOD AND VINYL DECKS CARS, BOATS, AND MOTORCYCLES Rinse deck and surrounding area with fresh water. If Rinse cleaning and surrounding area with fresh water. If using detergent, fill the detergent reservoir and apply to using detergent, fill the detergent reservoir and apply to the area being cleaned at low pressure.
  • Page 17 A5P | 01...
  • Page 18 VonHaus is a registered trademark of DOMU Brands Ltd. Made in China for DOMU Brands. Unit 30, Stakehill Industrial Estate, Middleton, Manchester M24 2RW. Authorised Representative: Authorised Representative Service, 77 Camden Street Lower,Dublin, D02 XE80, Ireland.
