ALX-D SERIES

COLUMN ARRAY LOUDSPEAKERS

INSTALLATION GUIDE

1601 JACK MCKAY BLVD.

ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: (800) 876-3333

SUPPORT@ATLASIED.COM

AtlasIED.com

Table of Contents

Need help?

Do you have a question about the ALX-D Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlas IED ALX-D Series

Page 1 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE 1601 JACK MCKAY BLVD. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 TELEPHONE: (800) 876-3333 AtlasIED.com AtlasIED.com ENNIS, TEXAS 75119 U.S.A. ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM SUPPORT@ATLASIED.COM...
Page 2 • Mounting the loudspeakers using one of the following - Method A: L-bracket Kit - Method B: Multiflex Bracket Kit - Method C: Flush Mount Kit - Method D: Speaker Stand Adapter The ALX-D Series Column Array Loudspeakers consists of the following models: • ALX-4D • ALX-8D • ALX-16D • ALX-24D •...
Page 3: Table Of Contents
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE TABLE OF CONTENTS INTRODUCTION MOUNTING METHOD C: FLUSH MOUNT Introduction ........................2 Summary of Steps ......................31 Tools Required – Column Array Installation............. 4 Step 1 – Remove connector cover plate from loudspeaker ......32 Step 2 – I nstall flush mount bracket in place of top...
Page 4: Tools Required - Column Array Installation
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G This section applies to ALX-D models ALX-16D, ALX-24D, ALX-32D, ALX-40D, and ALX-48D. SUMMARY OF STEPS – Loudspeaker Joining and Wiring TOOLS REQUIRED – Column Array Installation Step 1 •...
Page 5 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 1 – Remove decorative loudspeaker endcaps When cascading any two loudspeaker modules, the Bottom module should only have the top endcap removed, and the Top module should only have the bottom endcap removed relative to one another.
Page 6 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 2 – Install replacement joiner endcaps For each endcap removed a joiner endcap must be installed to allow mechanical connection to the cascaded module(s). There are two types of plates: one with holes and one with pegs.
Page 7 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 3 – Remove connector plate covers On the backside of each loudspeaker module, remove the top and bottom connection plate covers by removing the four (4) screws holding it in place. Set the plates and screws aside for use in a later step.
Page 8 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 4 – Slide the other coupling plate in grooves For each module pair to be joined, slide one joiner plate into the slotted grooves of the Bottom module. This part will remain loose for now but will be used in a later step to permanently secure the adjacent modules together.
Page 9 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 5 – Feed Interlink power and Interlink Ethernet cables through endcap opening Using the cable opening on the Bottom loudspeaker, feed both the power and network cables through the hole in the top endcap. These will later be fed through the bottom of the joining module endcap.
Page 10 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 6 – Align joining loudspeaker modules and feed cabling First, on a flat surface place the joining Top and Bottom modules in close proximity and feed the power/network THRU cables of the Bottom module to the connector cavity of the Top module. Next, align the opposite endcaps of both modules so the endcap holes fit around the pegs, then slide forward until the fronts are aligned. Warning: At this point, the loudspeaker modules are not securely connected together. This step should be performed on the floor or other large, flat, secure surface until properly secured in a later step.
Page 11 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 6 – (continued) Top speaker Top speaker Top speaker Top speaker Bottom speaker Bottom speaker Bottom speaker Bottom speaker...
Page 12 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 7 – Connect the cascading Interlink power and Interlink Ethernet cables to the Top loudspeaker module With the wires fed through the opening from the previous step, connect the network cable to the DATA-THRU port, and the power cable to the MAINS port. Place any remaining cable slack back through the cavity into the Bottom module.
Page 13 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 8 – Secure the loudspeaker modules together with the joiner plate Slide the joiner plate from Step 4 up to bridge across both Top and Bottom modules. Secure the modules together by tightly securing the four (4) included screws;...
Page 14 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 9 – Reattach the connector covers Reattach the cable covers and cylindrical foam pieces removed in Step 3 using the same four (4) screws each that were initially securing them in place.
Page 15 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 10 – Connect remaining loudspeaker modules together Repeat steps 1-9 for all remaining module pairs. The top-most module for the loudspeaker configuration will not require any additional cascading. The bottom-most Leader module will be wired in the next step to upstream devices and AC mains. Figure 11: Connecting remaining loudspeaker modules together 1601 JACK MCKAY BLVD.
Page 16 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 11 – Connect wires to bottom Leader module The bottom-most module is the Leader module for the entire ALX-D configuration. This module receives a single network connection (data and Dante) to the upstream audio system, and well as power for all modules via AC mains.
Page 17 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE LOUDSPEAKE R JOINI NG AN D WIRI N G ( CONT INUE D ) Step 12 – Remove badge from Top speaker (optional) Remove redundant badges by carefully peeling badge stickers off except for bottom badge. Figure 13: Removing badge from Top speaker (optional) 1601 JACK MCKAY BLVD.
Page 18: Mounting Method A: L-Brackets
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD A : L-B RAC KE TS SUMMARY OF STEPS – Mounting Method A: L-Brackets Step 1 • – Attach brackets to wall • Step 2 – Attach speaker to brackets...
Page 19 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD A : L-B RAC KE TS ) Step 1 – Attach brackets to wall Attach the L-brackets to the wall with appropriate hardware for the mounting surface and weight of ALX-D configuration. Figure 14: Attaching the brackets to the mounting surface 1601 JACK MCKAY BLVD.
Page 20: Step 2 - Attach Loudspeaker To Brackets
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD A : L-B RAC KE TS ( CO NTINU ED ) Step 2 – Attach loudspeaker to brackets Slide the speaker into the brackets and attach them using two (2) locking screws. You can also tilt the loudspeaker module right or left depending on installation needs.
Page 21: Mounting Method B: Multiflex Brackets
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS Use this method for ALX-4D and ALX-8D; see Step 9 for ALX-16D installations. Note: The multiflex 10 and 20 mounting brackets are only to be used with ALX-4D, ALX-8D, and ALX-16D SUMMARY OF STEPS – Mounting Method B: Multiflex Brackets Step 1 •...
Page 22 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS Step 1 – Remove one loudspeaker module endcap and connector cover Select either the top or bottom endcap and corresponding connector cover and remove (bottom endcap and connector cover shown below).
Page 23 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS ( CO N T IN U E D ) Step 2 – Slide adaptor plate into grooves on the rear of enclosure Using the grooves shown below as a guide, slide the adapter plate past the connector area.
Page 24 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS ( CO N T IN U E D ) Step 3 – Determine placement of the adapter plate, secure with screws Based on the specific installation needs, determine the placement of the adapter plate, Fasten the adapter plate into place using the four (4) provided screws.
Page 25 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS ( CO N T IN U E D ) Step 4 – Replace the endcap Replace the existing endcaps by removing the four (4) screws affixing each endcap to the loudspeaker. Bo ot A -T H...
Page 26: Step 5 - Attach Loudspeaker-Side Of The Multiflex Bracket To The Adapter Plate
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS ( CO N T IN U E D ) Step 5 – Attach loudspeaker-side of the multiflex bracket to the adapter plate Attach the loudspeaker-side of the multiflex bracket to the adapter plate using the pegs to help align them correctly. Tighten the two (2) locking washers...
Page 27: Step 6 - Attach Multiflex Mounting Bracket To The Wall
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS ( CO N T IN U E D ) Step 6 – Attach multiflex mounting bracket to the wall Attach wall side of flex mount bracket to wall with appropriate hardware for the mounting surface. Attach to the wall using two (2) screws. Figure 21: Attaching multiflex mounting bracket to wall 1601 JACK MCKAY BLVD.
Page 28: Step 7 - Align Loudspeaker-Side Bracket To Wall-Side Bracket
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS ( CO N T IN U E D ) Step 7 – Align loudspeaker-side bracket to wall-side bracket Attach the loudspeaker to the wall-side bracket by aligning the slots in the loudspeaker bracket to the mounting holes on the wall bracket.
Page 29: Step 8 - Attach The Two Brackets Together Using The Supplied Washers And Screws
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS ( CO N T IN U E D ) Step 8 – Attach the two brackets together using the supplied washers and screws Place the flat end of the swivel bracket onto the connector on the back of the loudspeaker. Use the UP arrow printed on the swivel bracket to properly align the bracket...
Page 30: Step 9 - Optional: Cascading Loudspeaker Module Mounting
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD B : M ULT IFLEX B RACKETS ( CO N T IN U E D ) Step 9 – Optional: Cascading loudspeaker module mounting If you require ALX-16D loudspeaker modules to be stacked/cascaded, use the multiflex 20 bracket on the Top loudspeaker and use the multiflex 10 bracket on the Bottom speaker. Figure 24: Cascading loudspeaker module mounting (optional) 1601 JACK MCKAY BLVD.
Page 31: Mounting Method C: Flush Mount
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD C: FLUSH M O UN T Note: The flush mount bracket method is only to be used with ALX-4D and ALX-8D. SUMMARY OF STEPS – Mounting Method C: Flush Mount • Step 1 – Remove connector cover plate from loudspeaker • Step 2 – Install flush mount bracket in place of top connection cover...
Page 32 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD C: FLUSH M O UN T Step 1 – Remove connector cover plate from loudspeaker The Flush Mount consists of a two-piece bracket. One piece attaches to the loudspeaker module and the other attaches to the wall.
Page 33 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD C: FLUSH M O UN T ( CO NTINU E D ) Step 2 – Install flush mount bracket in place of top connection cover Install the loudspeaker-facing flush mount bracket using the four (4) screws from the previous step. Figure 26: Install the loudspeaker-facing flush mount bracket 1601 JACK MCKAY BLVD.
Page 34 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD C: FLUSH M O UN T ( CO NTINU E D ) Step 3 – Attach adhesive rubber foot to bottom connector cover Attach the adhesive rubber foot to the bottom connector cover so the loudspeaker hangs parallel to the wall.
Page 35 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD C: FLUSH M O UN T ( CO NTINU E D ) Step 4 – Attach wall-side bracket to mounting surface Attach the wall-side bracket (cleat) using three (3) screws.
Page 36 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD C: FLUSH M O UN T ( CO NTINU E D ) Step 5 – Hang the loudspeaker module on the wall Carefully slide the loudspeaker module down the wall until the two bracket pieces connect securely.
Page 37: Mounting Method D: Alm Sm8 Speaker Stand Adapter
ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD D: ALM SM8 SPEAKE R STAN D ADAPTE R Depending on installation needs for the ALX-4D and ALX-8D loudspeaker modules, use the ALM SM8 Speaker Mount adapter for 35mm tripod speaker stands.
Page 38 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD D: ALM SM8 SPEAKE R STAN D ADAPTE R Step 1 – Thread the loudspeaker adapter into the bottom endcap until fully tightened Securely connect the ALM SM8 Speaker Stand Adapter to the loudspeaker module by turning the adapter clockwise until fully tightened.
Page 39 ALX-D SERIES COLUMN ARRAY LOUDSPEAKERS INSTALLATION GUIDE MOUN TI NG ME THOD D: ALM SM8 SPEAKE R STAN D ADAPTE R ( CO NTINUE D ) Step 1 – (continued) Figure 31: Tightening the ALM SM8 Speaker Stand Adapter to the loudspeaker module 1601 JACK MCKAY BLVD.
