Atlas IED IP-PM8GD Install Sheet

Safety Instructions

Please read carefully before installing or operating.
• Read all instructions carefully
• Heed all warnings
• Assure that the speaker is securely mounted
• Always assure amplifier power is off before making any connections
• Keep instructions for future reference
• Should any questions arise after reading this document, please call Atlas Sound Tech Support at 800-876-3333

Hearing Damage

CAUTION: All professional speaker systems are capable of generating very high sound pressure levels. Use care with placement and operation to
avoid exposure to excessive levels that can cause permanent hearing damage.
ATTENTION: Tous les systèmes de haut-parleurs professionnels sont capables de générer des niveaux de pression sonore très élevés. Utilisez les
soins avec le placement et l'opération pour éviter l'exposition à des niveaux excessifs pouvant causer des dommages auditifs permanents.

Suspension and Mounting

Suspending or "flying" speaker systems requires training and expertise. Improper rigging of a flying speaker may result in injury, death, equipment
damage, and legal liability. Installation must be carried out by fully qualified installers, in accordance with all required safety codes and standards at the
place of installation.
A 5:1 design factor is a generally accepted minimum standard. However, legal requirements for overhead suspension vary by municipality, please
consult your local safety standards office before installing any product. We also recommend that you thoroughly check any laws and bylaws prior to
installation.
Speakers flown in theaters, nightclubs, conference centers, or other places of work and entertainment must be provided with an independent,
correctly rated and securely attached secondary safety — in addition to the principle suspension point(s). This secondary safety must prevent the
speaker from dropping more than (6") should the principle suspension device fail. If you lack the skills, training, and proper ancillary equipment to fly a
speaker system, do not attempt to do so.

Introduction

AtlasIED IP endpoint speakers consist of a factory assembled speaker and baffle with PCB amplifier / control board. The amplifier / control board is
capable of producing 15-watts RMS into the 8Ω loudspeaker with IEEE 802.3at compliant PoE switches. Interconnection is via a top panel mounted
female RJ-45 connector. All models are compatible with AtlasIED's GCK
standalone operation.

Functionality

Before installing, note the unit's MAC address found under the top cover (example 00:02:C1:81:00:00). Once connected to a network and powered,
the IP endpoint speaker will boot up and automatically obtain an IP address from a DHCP server on the network. Next, the unit will start the
registration process to find the controller software. Once the IP endpoint speaker identifies the software's location, it will send a registration request
to the software and register. The MAC address of the unit will then be visible in the software's interface. Please refer to the installation manual of the
software for additional configuration settings.
After the speaker has registered with the software, using any Internet browser like Internet Explorer, Safari, Firefox, Chrome, etc., will allow access
to the unit's HTTPS page by navigating to its IP address. This page will show the unit's current firmware version and registration information. If unsure
about the IP address, press the unit's service button for one second and the unit's IP address will be announced through the speaker. This will require
removal of the top panel of the enclosure to access PCB. Please contact AtlasIED for instructions to configure the IP-PM8GD in SIP Standalone Mode.
IP-PM8GD
IP Enabled Pendent Mount Speaker
, Syn-Apps SA-Announce
©
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
, Singlewire's InformaCast
©
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
1/8
software, and SIP
©
AtlasIED.com
