Summary of Contents for Atlas IED M1000A35
- Page 1 M1000A35 Self-Contained Active Masking System 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 1 –...
-
Page 2: Table Of Contents
M1000A35 Owner’s Manual Table of Contents Important Safety Instructions ....................................3 Introduction ........................................... 5 Key Features .......................................... 5 Applications ........................................... 5 Controls and Features ......................................6 Installation ..........................................8 Installation Diagram ........................................ 9 Specifications ........................................10 Dimensional Drawings ......................................11 Warranty ..........................................12 1601 JACK MCKAY BLVD. -
Page 3: Important Safety Instructions
M1000A35 Owner’s Manual Important Safety Instructions The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage “ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 4 M1000A35 Owner’s Manual WARNING - When The Device Is In Use • WARNING: For the terminals marked with symbol of may be of sufficient magnitude to constitute a risk of electric shock. The external wiring connected to the terminals requires installation by an instructed person or the used of ready-made leads or cords.
-
Page 5: Introduction
M1000A35 is ideal for small to medium size installations that require a self-contained system. The M1000A35 is highly efficient utilizing a Class D topology amplifier and is UL2043 Plenum rated. The included power supply is an external in line UL rated 24VDC power supply requiring no additional electrical conduit in most United States cities’... -
Page 6: Controls And Features
A UL Certified external 24VDC 2.5A power supply is supplied to power the M1000A35. Powering the M1000A35 requires use of the included external power supply. It is suggested to place the M1000A35 within 6ft of a 120V AC outlet. If this is not possible, the power supply wire for the 24VDC output can be extended up to 50ft. - Page 7 We recommend using the AtlasIED ATMASKSC Speech Privacy Level Control. The ATMASKSC features calibrated 1dB level steps making it ideally suited to work with the M1000A35 when commissioning a masking system. Note: The ATMASKSC will attenuate the level a maximum of 9dB and will not turn the signal completely off.
-
Page 8: Installation
Installation The illustration below shows how to mount the M1000A35 to an open or plenum ceiling. AtlasIED suggests suspending the unit via a cable to the enclosed hanging brackets. The cable must be secured enough to handle 5 times the weight of the unit. Note: The suspension location in the ceiling must meet local building codes. -
Page 9: Installation Diagram
M1000A35 Owner’s Manual Installation Diagram 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 9 –... -
Page 10: Specifications
M1000A35 Owner’s Manual System Type Self-Contained Active Sound Masking System Speaker 8" Full Range, Qty 1 Amplified Power Internal 5-Watts, External Amplifier Slave Output 30-Watts Electrical Frequency Response 80Hz - 16kHz Masking Noise Generator Contoured Pink Noise Level Control Internal Speaker, External Amplifier Slave Output... -
Page 11: Dimensional Drawings
M1000A35 Owner’s Manual Dimensional Drawings 13.32" 8.35" (338mm) (212mm) 11.81" (300mm) 2.13" 5.67" (54mm) (144mm) 3.94" (100mm) 11.61" 11.61" (295mm) (295mm) 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 11 –... -
Page 12: Warranty
Service Should your M1000A35 Self-Contained Active Masking System require service, please contact the AtlasIED warranty department at 1-800-876-3333 or atlaswarranty@atlasied.com to obtain an RA number.
