NOTICE: For your safety, the mower may stop driving as the seat switch
got disconnect during driving. In this case, please refer to the section
"TROUBLESHOOTING" for more information.
C1-1 Cable
C1-2 Plug
C1-3 Socket
C1-4 Suspension Base
INSTALLING THE STEERING LEVERS (Fig. C3)
C3-1 Steering Levers
C3-2 Hex Bolts
OPERATION
BEFORE USING THE MOWER
Checking environment
a. Ensure that the work area is clear of children, bystanders, and pets.
b. Clear the work area of objects that may be thrown by the mower
blades.
c. Check and ensure that the LED lights are in proper status:
◾
The headlights, sidelights and rear lights are controlled by the
LED light switch.
◾
The running lights always keep on during driving.
◾
When backing up, if the rear lights are turned off, they will flash
to warn bystanders; if the rear lights are turned on, they will
remain on.
◾
All lights will switch off automatically when the mower shuts off
automatically after a period without operating.
Checking the cold tire pressure (Fig. D1)
Checking the mower status and battery charge level
a. Mower fuel-gauge indicator (Fig. A2 - 27a)
Each segment of the mower fuel-gauge indicator indicates 20%
charge of the inserted battery packs.
NOTICE: The mower fuel gauge indicator and the fuel gauge on the LCD
screen indicate the average capacity of the inserted battery packs.
b. Mower status indicator (Fig. A1 & Fig. A2 - 27b)
If the status indicator shows green, the mower is ready for driving. If not,
Please refer to the section "MOWER STATUS REFERENCE" and "FAULT
CODE REFERENCE"
Testing the safety interlock system (Fig. D2 - Fig. D8)
NOTICE:: The operator must be on the seat before test.
a. Before testing (Fig. D2 – Fig. D4)
b. To test the deck-blade system (Fig. D5) then slowly stand up
c. To test the driving system (Fig. D6 – Fig. D8) then slowly stand up
C1-5 Socket-Head Screws
C2-1 Hook
C2-2 Steel Rails
C2-3 Socket-Head Screws
Steering lever Mounting
C3-3
Holes
If the deck-blade system and/or the driving system fails to stop when the
operator is off of the seat and if the cause cannot be determined after
confirming the plug and socket connection of the seat is well connected,
contact your EGO customer service center immediately.
ADJUSTMENT (Fig. E1 – Fig. E13)
Preparation (Fig. E1 – Fig. E5)
Adjusting the cutting-deck height (Fig. E6)
Adjusting the anti-scalp wheels (Fig. E7 – Fig. E10)
E7-1 Anti-Scalp Wheel
E9-1 Nut
Adjusting the seat (Fig. E11)
Adjust the seat position to ensure you are able to make firm contact
with the parking-brake pedal before operating the mower. Seat
suspension adjustment could make you achieve the most comfortable
experience on the seat.
Seat Position
E11-1
Adjustment Lever
Setting the parking brake (Fig. E12 – Fig. E13)
E13-1 Braking Position
CHARGING (Fig. F1 – Fig. F11)
In order to start this mower, EGO batteries totaling 15 Ah (2 X
BA4200/BA4200T) or more are required. For best performance, we
recommended use of EGO batteries that total 30 Ah or more.
Use only with the recommended battery packs and
chargers. (Fig. F9 & F10)
Preparation for charging (Fig. F1 – Fig. F4)
Charging the battery pack(s) separately (Fig. F5 – Fig. F9)
F5-1 Cover Release Button
◾
To attach the battery pack(s) (Fig. F5 – Fig. F6)
◾
To detach the battery pack(s) (Fig. F7 – Fig. F8)
NOTICE:: Charge the battery pack(s) refer to the corresponding battery
and charger manuals.
Charging the battery packs via charging port (Fig. F10)
F10-1 Dust Cap
ZERO TURN RIDE-ON MOWER — ZT5200E-L
E9-2 Lag Bolt
E10-1 Deck Height Label
Seat Suspension
E11-2
Adjustment Knob
E13-2 Released Position
F7-1 Battery Release Button
F10-2 Charging Port
