Chapter 5 System Operation

5.3.35 System Information screen

＜ＩＮＦＯＲＭＡＴＩＯＮ＞
ＣＰＲＳＲ Ｄｏｗｎ Ｍｏｄｅ，
Ｒｕｎｎｉｎｇ Ｓｔｏｐ
The "System Information screen", as shown above, may be displayed upon system Start/Stop.
No. Item
INITIALIZE MODE
(CONTROL VALVE)
(RESERVOIR)
1
Pump Up Mode
Running Start
CPRSR Down Mode.
Running Stop
5.3 Operation Screen
5-36
1
Figure 5-37 System Information screen
Table 5-34 System Information screen
Operation prepares mode after turning on the main breaker. System
operation is disabled if this message is displayed.
CONTROL VALVE: Positioning of the electronic expansion valve is
performed.
RESERVOIR: The circulating fluid flows in this product through the
internal pump.
If your piping is supplied with an insufficient amount of the circulating fluid
at system startup, the circulating pump in this product activates
(repeating ON/OFF) to replenish piping with the circulating fluid.
Continuous operation is initiated once piping is replenished with the fluid.
Compressor operation remains for approx. 20 seconds after circulating
pump stops for the protection of the compressor at the time of system
shutdown.
POWER ON
Descriptions
HRZC Series
