- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua IPC- HF7442F o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza HD Box Network Camera Quick Start Guide V1.0.0 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD...
-
Page 2: Foreword
Foreword General This Quick Start Guide (hereinafter referred to be "the Guide") introduces the functions, installation and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the guide. Signal Words Meaning Indicates a high potential hazard which, if not avoided, will result in death or serious injury. -
Page 3: About This Guide
area and providing related contact. About this Guide The Guide is for reference only. If there is inconsistency between the Guide and the actual product, the actual product shall prevail. We are not liable for any loss caused by the operations that do not comply with the Guide. ... -
Page 4: Important Safeguards And Warnings
Important Safeguards and Warnings Electrical safety All installation and operation should conform to your local electrical safety codes. The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1. - Page 5 It is recommended connect the grounding hole to the ground to enhance the reliability of the device. Do not touch the image sensor directly (CMOS). Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol. ...
-
Page 6: Regulatory Information
Regulatory Information FCC Information Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC conditions: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. -
Page 7: Table Of Contents
Table of Contents Foreword ..............................II Important Safeguards and Warnings ....................III Regulatory Information ..........................V 1 Introduction ............................1 1.1 Device Structure..........................1 1.2 Connecting Alarm Input/output ..................... 4 2 Network Configuration.......................... 6 2.1 Initializing Device .......................... 6 2.2 Modifying Device IP Address ......................7 2.3 Logging in Web Interface ...................... -
Page 8: Introduction
Introduction 1.1 Device Structure Structure type might vary with different devices, and the actual product shall prevail. Introduction 1... - Page 9 Figure 1-1 Device Structure Figure 1-2 Device Structure Figure 1-3 Device Structure For more information about ports, see Table 1-1. Table 1-1 Port Information Port Name Port Function VIDEO OUT Video output port Outputs analog video signal. It can connect to Introduction 2...
- Page 10 TV monitor to check image. Previews image via the DVR which supports HDCVI when it outputs HDCVI signal. HDMI HDMI interface Connects to HDMI monitor to preview image. AC 24V/ DC 12V Power port Inputs 12V DC or AC 24V power supply, and supports power supply at the same time ...
-
Page 11: Connecting Alarm Input/Output
RESET RESET button Restores device factory default setup. When system is running normally, press the RESET button for at least 5 seconds, system can restore factory default setup. Auto back focus Auto back focus adjustment, by adjusting Sensor adjustment board position to achieve precise back focus adjustment. - Page 12 Figure 1-4 Alarm input Step 2 Connect alarm output device to the alarm output end of the I/O port. The alarm output is relay switch output, which can only connect to NO alarm devices. N1 and C1 or N2 and C2 constitute a switch to provide the alarm output, which is shown in Figure 1-5.
-
Page 13: Network Configuration
Network Configuration Device initialization and IP setting can be finished with the "ConfigTool" or in web interface. For more information, see the WEB operation manual. Device initialization is available on select models, and it is required at first use and after device is being reset. -
Page 14: Modifying Device Ip Address
All the devices found in the network segment are listed. Step 5 Select one or several devices which Status are Uninitialized, and then click Initialize. The Device initialization interface is displayed. Step 6 Select the devices that need initialization, and then click initialize. The password setting interface is displayed. -
Page 15: Logging In Web Interface
Step 3 Select the devices which IP addresses need to be modified, and then click Modify IP. The Modify IP Address interface is displayed. See Figure 2-3. Figure 2-3 Modify IP Address interface Step 4 Select Static mode and enter start IP, subnet mask and gateway. IP addresses of multiple devices will be set to the same if you select Same IP. - Page 16 Figure 2-4 Main interface Network Configuration 9...
-
Page 17: Installation
Installation 3.1 Packing List The tool required for the installation such as electric drill is not provided in the packing. The operation manual and related tool are contained in the disk or the QR code, and the actual packing shall prevail. 3.2 Dimension Following figures are for reference only, the actual product shall prevail. - Page 18 Model B (Unit: mm [in]) Model C (Unit: mm [in])
-
Page 19: Installing Device
3.3 Installing Device 3.3.1 Installation method Indoor Wall-mounted Indoor Hang-mounted Install Housing Please use housing if the device needs to be installed outdoors, which is to avoid device damage caused by water soaking. -
Page 20: Installing Lens
3.3.2 Installing Lens Auto iris socket: it needs to plug the cable of auto iris lens into auto iris socket when the installed lens is auto iris lens. Bayonet Mount Screw-threaded Mount CS Lens C Lens 3.3.3 Attaching Device Make sure the mounting surface is strong enough to hold at least three times of the device weight. - Page 21 Cable going through the cable tray...
-
Page 22: Using I/O Port
3.3.4 Using I/O Port 3.3.5 Adjusting Angle... - Page 23 【社会的安全 我们的责任】 SOCIAL SECURITY IS OUR RESPONSIBILITY Zhejiang Dahua Vision Technology Co., Ltd Address：No.1199 Bin’an Road, Binjiang District, Hangzhou, PRC. Postcode: 310053 Tel: +86-571-87688883 Fax: +86-571-87688815 Email:overseas@dahuatech.com Website: www.dahuasecurity.com...
