Dahua Technology IPC-HFW1531S Operation Manual

Dahua Technology IPC-HFW1531S Operation Manual

Web3.0
Hide thumbs

Advertisement

Quick Links

Download this manual
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
Dahua IPC-
HFW1531S
o cerca il tuo prodotto tra le
migliori offerte di Videosorveglianza
Dahua Network Camera Web 3.0 Operation Manual
Dahua Network Camera Web3.0 Operation Manual
Version 1.0.2
Zhejiang Dahua Vision Technology CO., LTD
i

Advertisement

loading
Need help?

Need help?

Do you have a question about the IPC-HFW1531S and is the answer not in the manual?

Questions and answers

Related Manuals for Dahua Technology IPC-HFW1531S

Summary of Contents for Dahua Technology IPC-HFW1531S

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua IPC- HFW1531S o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza Dahua Network Camera Web 3.0 Operation Manual Dahua Network Camera Web3.0 Operation Manual Version 1.0.2 Zhejiang Dahua Vision Technology CO., LTD...

  • Page 2: Table Of Contents

    Dahua Network Camera Web 3.0 Operation Manual Table of Contents Product Overview ........................1 Initial Config ..........................2 Device Initialization ....................... 2 Login and Logout ......................5 2.2.1 Log in WEB Interface ....................5 2.2.2 Logout ........................6 Reset Password ......................6 Live ..............................
  • Page 3 Dahua Network Camera Web 3.0 Operation Manual 5.2.2 Playback File ......................29 5.2.3 Snapshot Type ......................31 Setup ............................33 Camera ......................... 33 6.1.1 Conditions ....................... 33 6.1.2 Video ........................45 6.1.3 Audio ........................57 Network ......................... 59 6.2.1 TCP/IP ........................59 6.2.2 Connection ......................
  • Page 4 Dahua Network Camera Web 3.0 Operation Manual 6.5.2 Account ......................... 130 6.5.3 PTZ ........................133 6.5.4 Default ........................134 6.5.5 Import/Export ....................... 135 5.5.6 Remote control ......................135 6.5.6 Auto Maintenance ....................136 6.5.7 Upgrade ........................ 137 Information ......................... 137 6.6.1 Version ........................
  • Page 5 Dahua Network Camera Web 3.0 Operation Manual Important The following functions are for reference only. Some series products may not support all the functions listed below. Cybersecurity Recommendations 1. Change Passwords and Use Strong Passwords The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible.
  • Page 6 Dahua Network Camera Web 3.0 Operation Manual On older IP Camera firmware, the ONVIF password does not change when you change the system‟s credentials. You will need to either update the camera‟s firmware to the latest revision or manually change the ONVIF password. 6.
  • Page 7 Dahua Network Camera Web 3.0 Operation Manual 12. Multicast: Multicast is used to share video streams between two recorders. Currently there are no known issues involving Multicast, but if you are not using this feature, deactivation can enhance your network security. 13.
  • Page 8 Dahua Network Camera Web 3.0 Operation Manual  Do not aim the device at strong light to focus, such as lamp light and sun light, otherwise it might cause over brightness or light marks, which are not the device malfunction, and affect the longevity of Charge Coupled Device (CCD) or Complementary Metal-Oxide Semiconductor (CMOS).

  • Page 9: Product Overview

    Dahua Network Camera Web 3.0 Operation Manual 1 Product Overview The common networking mode for IPC is to connect IPC to PC via switch or router. The common network mode is shown in Figure 1-1. Figure 1-1 Before you have access to network camera via the Internet, you need to acquire its IP address. Users can search IP address of network camera via Quick Config Tool.

  • Page 10: Initial Config

    Dahua Network Camera Web 3.0 Operation Manual 2 Initial Config In this chapter it is to introduce the device initial config operation, which includes device initialization, login device, log out WEB interface and password reset. 2.1 Device Initialization It needs to implement device initialization when you use the device for the first time. Here it is to take WEB operation as an example to introduce device initialization.
  • Page 11 Dahua Network Camera Web 3.0 Operation Manual Parameter Note User name The default user name is admin Password The password ranges from 8 to 32 digitals. It can contain letters, numbers and special characters (excluding “'”,“"”,“;”,“:”,“&”) . The password shall Confirm contain at least two categories.
  • Page 12 Dahua Network Camera Web 3.0 Operation Manual Figure 2-3 Step 5 Select Easy4iP according to actual needs and realize Easy4iP registration for device, click next. The system will display the interface of Online Upgrade, which is shown in Figure 2-4 Figure 2-4 Step 6 It is to set upgrade method according to the actual requirements.

  • Page 13: Login And Logout

    Dahua Network Camera Web 3.0 Operation Manual Select Auto-check for upgrade and the system will check once daily automatically when there is system upgrade prompt. Note After login, you can make setting in „Setup > System > Upgrade > Online Upgrade‟. Step 7 Click Save and device initialization is completed.

  • Page 14: Logout

    Dahua Network Camera Web 3.0 Operation Manual Step 2 Input the password of admin user. Step 3 Click Login. It will display the Live interface after it logged in successfully, which is shown in Figure 2-6. Note Different devices have different functions with different interface display; please refer to the actual interface for more details.
  • Page 15 Dahua Network Camera Web 3.0 Operation Manual Figure 2-7 Step 2 Click Forgot password? The system will display the interface of Reset Password, which is shown in Figure 2-8. Figure 2-8 Step 3 Reset login password. Scan the QR code according to the interface prompt and acquire security code, then input the security code which is received via your reserved email.
  • Page 16 Dahua Network Camera Web 3.0 Operation Manual  Please use the security code to reset the password within 24 hours after you received the security code via your reserved email. Otherwise the security code will be invalid.  If you fail to use security code for twice continuously, then the system will prompt that it fails to acquire security code for the third time.

  • Page 17: Live

    Dahua Network Camera Web 3.0 Operation Manual 3 Live After you logged in, you can see the live monitor window. See Figure 3-1. Figure 3-1 There are four sections:  Section 1: Encode setup bar  Section 2: System menu ...

  • Page 18: System Menu

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function Click it to enable main stream video monitoring and click again Main stream to disable it. Generally for storage and monitor. Click it to enable Sub Stream1 video monitoring and click again Sub Stream 1 to disable it.

  • Page 19: Video Window Setup

    Dahua Network Camera Web 3.0 Operation Manual  When the video is in the original status, click it you can Digital select any zone to zoom in. In the non-original status, Zoom you can drag the zoom-in zone in specified range. Right click mouse to restore previous status.

  • Page 20: Original Size

    Dahua Network Camera Web 3.0 Operation Manual Figure 3-6 Click this button to display/hide image control interface. Click it to open picture setup interface. This interface is on the top right pane. Please refer to the following sheet for detailed information. Parameter Function Video...

  • Page 21: Width And Height Ratio

    Dahua Network Camera Web 3.0 Operation Manual 3.4.4 Width and Height Ratio Click it to restore original ratio or suitable window. 3.4.5 Fluency Adjustment There are three levels of fluency for you to select (Realtime, Normal, and Fluency). The default is normal.
  • Page 22 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Adjust the focal length of the lens by clicking or long pressing “+”“-”buttons. Zoom The speed is used to adjust the length of one step during single click. Adjust the sharpness of the lens by clicking or long pressing“+”、“-” buttons. Focus Step length is used to adjust the length of one step with one click.
  • Page 23 Dahua Network Camera Web 3.0 Operation Manual parameter Note Installation Mode Three modes which are ceiling mount, wall mount and ground mount. It represents the display mode of the current image (default supports original image mode), the display modes may be different according to different installation modes.
  • Page 24 Dahua Network Camera Web 3.0 Operation Manual parameter Note Original image + 8 independent sub images, both the sub image and the subbox in the original image support zoom and movement. The original image also supports changing starting point by rotation From left right...
  • Page 25 Dahua Network Camera Web 3.0 Operation Manual  1P+3: Original picture and three trigger track windows, it can adjust the location and size of three trigger track windows on the original picture.  1P+5: Original picture and five trigger track windows, it can adjust the location and size of five trigger track windows on the original picture.

  • Page 26: Ptz Control

    Dahua Network Camera Web 3.0 Operation Manual 4 PTZ Control Here you can view direction keys, speed, zoom, focus, iris, preset, tour, scan, pattern, aux on, off and PTZ setup button. Note Before PTZ operation, please make sure you have properly set PTZ protocol. (Please refer to Ch 5.5.3). Currently only IPC-HFXXXX series and –PT series products can support PTZ function.

  • Page 27: Scan

    Dahua Network Camera Web 3.0 Operation Manual Figure 4-2 PTZ setting interface is shown as in Figure 4-3. Here you can set scan, preset, tour, pattern, assistant function and light and wiper plus view coordinate. Figure 4-3 4.1 Scan Scan interface is shown in Figure 4-4.

  • Page 28: Preset

    Dahua Network Camera Web 3.0 Operation Manual Figure 4-4 Steps to scan are: Step 1. Click on Set button, display icon. Step 2. Move via direction key to select left, click on Set Left to set left border of camera Step 3.

  • Page 29: Pattern

    Dahua Network Camera Web 3.0 Operation Manual Tour interface is shown in Figure 4-6. Figure 4-6 Steps to tour are: Step 1. In tour box, input tour path value. Step 2. Click on Add. Range of tour relates to PTZ protocol. Step 3.

  • Page 30: Assistant

    Dahua Network Camera Web 3.0 Operation Manual Click “Stop Rec” to complete the setting of a pattern path. Step 4 Click “Start” and it will start pattern according to the pattern path which has been set; click “Stop” and the pattern ends. 4.5 Assistant Assistant interface is shown in Figure 4-8.

  • Page 31: Playback

    Dahua Network Camera Web 3.0 Operation Manual 5 Playback Web client playback supports video playback and picture playback. Note: Before playback, user shall set storage management as in Ch. 5.4. 5.1 Playback Figure 5-1 The playback interface is shown as in Figure 5-1 There are four sections: ...

  • Page 32: Function Of Play

    Dahua Network Camera Web 3.0 Operation Manual 5.1.1 Function of Play Figure 5-2 Figure 5-3 The function of play is shown as in Figure 5-2 Figure 5-3 Parameter Function When you see this button, it means pause or not played record. Click on this ①...

  • Page 33: Playback File

    Dahua Network Camera Web 3.0 Operation Manual 5.1.2 Playback File Figure 5-4 In calendar, blue date represents data currently has video record or snapshot. See Figure 5-4 Parameter Function Select “dav”, as video playback.  File Type Select “jpg” as picture playback. ...
  • Page 34 Dahua Network Camera Web 3.0 Operation Manual Figure 5-6 Parameter Function It means records within searched start time and end time on the date. Search Download There are two formats: dav, mp4. Format...

  • Page 35: Playback Cut

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function  click the download button and download file to path in Ch. 5.1.2.5. Download  System does not support download and playback at the same time. Click on back button to go to calendar interface. Back 5.1.3 Playback Cut Note:...

  • Page 36: Assistant Function

    Dahua Network Camera Web 3.0 Operation Manual Figure 5-9 Parameter Function Click on it, means video in past 24 hours. 24 hours Click on it, means video in past 2 hours. 2 hours Click on it, means video in past 1 hour. 1 hour Click on it, means video in past 30 min.

  • Page 37: Play

    Dahua Network Camera Web 3.0 Operation Manual Figure 5-11 Figure 5-11 5.2.1 Play Figure 5-12 Default icon is and it means pause or not played picture. Click on play button to switch to normal play status. Icon become Click on it to pause. 5.2.2 Playback File...
  • Page 38 Dahua Network Camera Web 3.0 Operation Manual Figure 5-13 Step 1. Click on file list , select snapshot file of the date. Step 2. Double click on file in list, to play this snapshot. Parameter Function It means all snapshot files within the start time and end time of selected date. Search...

  • Page 39: Snapshot Type

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function Click the download button to open snapshot file or directly download to local Download according to the browser types. Click the back button to return to calendar interface and re-select time. Back Figure 5-14 5.2.3 Snapshot Type...
  • Page 40 Dahua Network Camera Web 3.0 Operation Manual After checking snapshot file type, in file list only display file of selected type. Users can also select the Figure 5-15 snapshot type to be displayed via the dropdown box above the file list. See Figure 5-15...

  • Page 41: Setup

    Dahua Network Camera Web 3.0 Operation Manual 6 Setup Web client setup support camera, network, time, storage, system and system info view. 6.1 Camera The camera setting includes conditions, profile management, zoom and focus. 6.1.1 Conditions Note: The camera parameter may be different according to different models, please refer to the actual product for more details.
  • Page 42 Dahua Network Camera Web 3.0 Operation Manual Parameter Note It is to adjust the image overall brightness via linear adjustment mode. Brightness The larger the number is, the brighter the picture is, and on the contrary it is opposite. The picture get blurry easily when the value is set too big. It is to adjust the picture contrast.
  • Page 43 Dahua Network Camera Web 3.0 Operation Manual 6.1.1.2 Exposure Step 1 Select “Setup > Camera > Conditions > Exposure”. The system will display the “Exposure” interface Figure 6-2 which is shown in Figure 6-2 Step 2 It is to set the exposure parameter, please refer to the following sheet for more details. Parameter Note ...
  • Page 44 Dahua Network Camera Web 3.0 Operation Manual Parameter Note It is the camera exposure mode. Note:  When “Anti-flicker” is “Outdor”, the “exposure mode” can be set as “gain priority” or “shutter priority” mode.  Different devices have different exposure modes; please refer to the actual interface.
  • Page 45 Dahua Network Camera Web 3.0 Operation Manual Step 3 Click “Save” to complete the parameter config of camera exposure. 6.1.1.3 Backlight Backlight mode can be divided into BLC, WDR and HLS. BLC: it can avoid cucoloris phenomenon of the darker area in the backlight environment. WDR: It can suppress the overbright area and compensate darker area by enabling WDR, which can make the overall image clear.
  • Page 46 Dahua Network Camera Web 3.0 Operation Manual  When selecting “Customized” mode, the system can realize exposure upon the selected area after it set customized area, which is to make the image of the selected area reach appropriate brightness.  When the “Mode”...
  • Page 47 Dahua Network Camera Web 3.0 Operation Manual  When the “Mode” is set as “Auto”, the system can auto compensate white balance upon different color temperatures, which is to make the image color normal.  When the “Mode” is set as “Natural”, the system can auto compensate white balance to the scene without artificial light, which is to make the image color normal.
  • Page 48 Dahua Network Camera Web 3.0 Operation Manual Step 2 Set day & night parameter; please refer to the following sheet for more details. Parameter Note It is to set the camera image displayed as color or black & white mode. Note: The setting of “Day/Night Mode”...
  • Page 49 Dahua Network Camera Web 3.0 Operation Manual Figure 6-6 Step 2 It is to set defog mode according to the actual scene.  When the “Mode” is set as “Manual”, it is to manually set intensity and air light mode, the system will adjust the image definition according to the intensity and air light mode which have been set previously.
  • Page 50 Dahua Network Camera Web 3.0 Operation Manual Figure 6-7 Step 2 It is to set IR light mode according to the actual scene.  When the “Mode” is set as “Manual”, it can manually set the brightness of IR light; the system will realize light compensation to the image according to the IR light intensity.
  • Page 51 Dahua Network Camera Web 3.0 Operation Manual 6.1.1.8 Profile Management Step 1 Select “Setup > Camera > Conditions > Profile Management” and the system will display the interface of “Profile Management”. Step 2 Set profile management.  When the “Profile Management” is set as “Normal”, the system will monitor according to the normal config.
  • Page 52 Dahua Network Camera Web 3.0 Operation Manual Figure 6-10 Step 3 Click “Save” to complete the settings of profile management. Note: Click “Default” to restore the device to default config; click “Refresh” to check the latest config file of the device.

  • Page 53: Video

    Dahua Network Camera Web 3.0 Operation Manual Step 2 Adjust the focal length of the lens. After it is zoomed, set “Speed” and press “+”, “-“or drag the sliding block directly to adjust. Step 3 Adjust the lens definition. After it is focused, set “Speed” and press “+”, “-“or drag the sliding block directly to adjust. Note: ...
  • Page 54 Dahua Network Camera Web 3.0 Operation Manual Figure 6-13 (Fisheye) Step 2 Set video bit stream, please refer to the following sheet for more details about the parameters. Parameter Function It will display the parameter when the device is fisheye. There are three installation modes for fisheye which are ceiling, wall mount and ground installation, please select installation mode according to the actual...
  • Page 55 Dahua Network Camera Web 3.0 Operation Manual Parameter Function It will display the parameter when the device is fisheye. The system will begin to switch after record mode is switched, it will prompt saved successfully after it is switched successfully. The record mode will change according to the different installation modes.
  • Page 56 Dahua Network Camera Web 3.0 Operation Manual Parameter Function There are five options: H.264 (main profile standard, Encode mode H.264H (high profile standard), H.264B (Baseline Profile), H.265 (main profile standard) and MJPEG encode.  The H.264, H.264H both are H264 bit stream. H.264 is the Main Profile encode and you need to enable the sub stream function in your camera and set the resolution as CIF.
  • Page 57 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Select “Watermark Setting” and enable watermark Watermark Settings function. After the watermark function is enabled, you can check if the video is tampered via verifying watermark character. Watermark Character It is the character of watermark verification; it is Digital CCTV by default.
  • Page 58 Dahua Network Camera Web 3.0 Operation Manual 3. Select the needed resolution and clip the needed image on the interface, which is shown in Figure 5-15. 4. Click “Save”. You can check the clipped video in the preview interface (the sub stream 2 preview Figure 6-15 interface only displays the clipped area), which is shown in Figure 6-15...
  • Page 59 Dahua Network Camera Web 3.0 Operation Manual Figure 6-16 Please refer to the following sheet for detailed information. Parameter Function There are two modes: general (schedule) and Event (activation). Snapshot type Image size It is the same as the resolution of main stream. It is to set the image quality.
  • Page 60 Dahua Network Camera Web 3.0 Operation Manual Figure 6-18 Figure 6-19...
  • Page 61 Dahua Network Camera Web 3.0 Operation Manual Figure 6-20 Figure 6-21...
  • Page 62 Dahua Network Camera Web 3.0 Operation Manual Figure 6-22 Please refer to the following sheet for detailed information. Parameter Function  Here you can privacy mask the specified video in the Privacy Masking monitor video.  System max supports 4 privacy mask zones. ...
  • Page 63 Dahua Network Camera Web 3.0 Operation Manual  Check “Enable” to display the counting statistics data in Counting the video monitoring window; check “Disable” not to display.  There are enter number and leave number for statistics type and left align and right align for OSD info. ...
  • Page 64 Dahua Network Camera Web 3.0 Operation Manual Figure 6-24 Parameters Note Check “Enable”, then it will display the ROI in the video monitoring window; Enable Check “Disable”, then it won‟t display.  Set the image quality of ROI, ranging from 1～6, default is 6. Note: Image Quality...

  • Page 65: Audio

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-25 6.1.3 Audio Please note some series devices do not support audio function. 6.1.3.1 Audio Figure 6-26 The audio interface is shown as below. See Figure 6-26 Please refer to the following sheet for detailed information.
  • Page 66 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Enable You can enable audio only when video is enabled. After selecting the “Enable” of main stream or sub stream, the network transmission stream is the audio/video composite stream, otherwise it only includes video image. Encode mode The encode mode of the main stream and extra stream include G.711A, G.711Mu, G.726 and ACC.

  • Page 67: Network

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-27 Figure 6-28 Audio management currently supports PCM format to record and PCM, wav two forms to upload，and can select an audio file for the audio alarm linkage. The way to download the web alarm playback audio file into local is as follows: in the “choice”...
  • Page 68 Dahua Network Camera Web 3.0 Operation Manual Figure 6-29 Please refer to the following sheet for detailed information. Parameter Function Host Name It is to set current host device name. It max supports 15 characters. Ethernet Card Please select the Ethernet port. Default is wired. Please note you can modify the default Ethernet card if there is more than one card.
  • Page 69 Dahua Network Camera Web 3.0 Operation Manual Enable You can use ARP/Ping command to modify or set the device IP ARP/Ping set address if you know the device MAC address. device IP Before the operation, please make sure the network camera address service.

  • Page 70: Connection

    Dahua Network Camera Web 3.0 Operation Manual 6.2.2 Connection Connection 6.2.2.1 Figure 6-31 The connection interface is shown as in Figure 6-31 Please refer to the following sheet for detailed information. Parameter Function It is the max Web connection for the same device. The value ranges from 1 connection to 20.
  • Page 71 Dahua Network Camera Web 3.0 Operation Manual  RTSP port The default value is 554. Please leave blank if use default. User uses QuickTime or VLC can play the following formats. BlackBerry can play too.  Real-time monitoring URL format, please require real-time RTSP media server, require channel no., bit stream type in URL.

  • Page 72: Pppoe

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-32 6.2.3 PPPoE Figure 6-33 The PPPoE interface is shown as in Enter the PPPoE username and password which are provided by ISP (Internet Service Provider), and click “Enable”. The network camera will automatically establish network connection in the mode of PPPoE after it is enabled;...

  • Page 73: Ddns

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-33 6.2.4 DDNS Figure 6-34 The DDNS interface is shown as in The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
  • Page 74 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Server Type You can select DDNS protocol from the dropdown list: CN99 DDNS, NO-IP DDNS, Dyndns DDNS, and Dahua DDNS. The default is Dahua DDNS. Server Address DDNS server IP address CN99 DDNS Server address: www.3322.org NO-IP DDNS...

  • Page 75: Ip Filter

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function Server Type You can select CN99 DDNS protocol Under CN99 DDNS the default server address is “www.3322.org” Server Address Domain Name Self-defined domain name Username The user name you input to log in the server. Password The password you input to log in the server The refresh period of the connection between the device IP and the server, default...
  • Page 76 Dahua Network Camera Web 3.0 Operation Manual Figure 6-37 Please refer to the following sheet for detailed information. Parameter Function Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. Anonymity For the server which supports the anonymity email function, it won‟t display the information of the sender.

  • Page 77: Upnp

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function The send interval ranges from 0 to 3600 seconds. 0 means Interval there is no interval. Please note system will not send out the email immediately when the alarm occurs. When the alarm, motion detection or the abnormity event activates the email, system sends out the email according to the interval you specified here.

  • Page 78: Snmp

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-38 6.2.8 SNMP Figure 6-39 Figure 6-40 The SNMP interface is shown as in The SNMP allows the communication between the network management work station software and the proxy of the managed device. Please install the software such as MG MibBrowser 8.0c software or establish the SNMP service before you use this function.
  • Page 79 Dahua Network Camera Web 3.0 Operation Manual Parameter Function  SNMP Version Check SNMP v1, device only process v1 info.  Check SNMP v2, device only process v2 info.  Check SNMP v3, can set username, password and encryption method. Server calibrate corresponding username, password and encryption method too access device and v1/v2 are unavailable.

  • Page 80: Bonjour

    Dahua Network Camera Web 3.0 Operation Manual Check SNMP v3 version and SNMP port, read community, write community, Trap address, Trap port are same with SNMP v1 and SNMP v2 versions. Only when SNMP version is SNMP v3, users need to configure parameter in chart.

  • Page 81: Multicast

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-41 6.2.10 Multicast Figure 6-42 The multicast interface is shown as in Multicast is a transmission mode of data packet. When there is multiple-host to receive the same data packet, multiple-cast is the best option to reduce the broad width and the CPU load. The source host can just send out one data to transit.
  • Page 82 Dahua Network Camera Web 3.0 Operation Manual Note: This function is only for series with 4G module. 4G is a mobile communication system which makes wireless communication integrates with Internet and multimedia communication. 6.2.11.1 Dialing Setting Figure 6-43 Parameter Function Wireless Net Type Auto, WCDMA, FDD-LTE optional, you can select according to the operator.

  • Page 83: Wifi

    Dahua Network Camera Web 3.0 Operation Manual Time Range It is the time period to set dial-up. It can activate the function via message to enable/disable dial-up function if it is beyond the time period. IP Address It will display the acquired IP after the dial-up is successful via 4G.
  • Page 84 Dahua Network Camera Web 3.0 Operation Manual Note: Some series devices don‟t support WIFI and WPS function. WPS function is supported by the devices with WPS button. 6.2.12.1 WIFI WIFI info can show the name, status, IP information of the Current Hot Spot. Usually please “Refresh” WIFI work information after reconnection to ensure the real-time display of the work status, because it often takes some time to connect WIFI Hot Spot, which depends on the network signal strength.
  • Page 85 Dahua Network Camera Web 3.0 Operation Manual Figure 6-46 Click “Add SSID” when need to add a wireless network manually pop out an interface in Step 3 the figure below, and enter network ID in the dialog box. Figure 6-47 Step 4 Double click on one can pop out the signal intensity and authentication of the hot spot.
  • Page 86 Dahua Network Camera Web 3.0 Operation Manual Figure 6-48 PIN Number and SSID are both acquired from the router, please “refresh” the work information of WIFI to ensure the real-time display of work state after filling in correctly. 6.2.13 802.1x 802.1x (port based network access control protocol) supports manual selection of authentication method to control if device connected to LAN can join the LAN.

  • Page 87: Qos

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function Authentication PEAP (protected EAP protocol). Username It needs the username to login, which is authenticated by the server. Password Please input password here. 6.2.14 QoS Figure 6-50 The QoS interface is shown as below. See Qos (Quality of Service) is network security mechanism.

  • Page 88: Https

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function Command The value ranges from 0 to 63. The router or the switcher can provide different service for various data packets. Enable Check it to enable QoS. Wireless QoS 6.2.15 HTTPs In the HTTPs setting interface, users can make PC log in normally via HTTPs by creating certificate or uploading signed certificate, which is to guarantee the security of communication data and provide safeguard for user information and device security with reliable and stable technical means.
  • Page 89 Dahua Network Camera Web 3.0 Operation Manual Figure 6-52 3. Fill in corresponding “Country”, “Province” and some other information; click “Create” after filling in. It will show the prompt of “Create Successfully”, which means the server certificate has been successfully created. Note: Make sure the “IP or domain name”...
  • Page 90 Dahua Network Camera Web 3.0 Operation Manual Figure 6-53 5. Click “Download”. It will pop out the dialog box of “Save as”, save the file into the computer.
  • Page 91 Dahua Network Camera Web 3.0 Operation Manual Figure 6-54 6. Double click the downloaded icon of “RootCert.cer”. The system will display the information interface of “Certificate”, which is shown in Figure 5-55. Figure 6-55 7. Click “Install Certificate” and it will pop out the interface of “Certificate Import Wizard”, which is Figure 6-56 shown in...
  • Page 92 Dahua Network Camera Web 3.0 Operation Manual Figure 6-56 8. Click “Next”. Select “Trusted Root Certification Authorities”, which is shown in Figure 6-57...
  • Page 93 Dahua Network Camera Web 3.0 Operation Manual Figure 6-57 9. Click “Next”. The system will display the interface of “Completing the Certificate Import Wizard”, Figure 6-58 which is shown in...
  • Page 94 Dahua Network Camera Web 3.0 Operation Manual Figure 6-58 10. Click “Finish”, and it will pop out the dialog box of “Security Warning”, which is shown in Figure 6-59...
  • Page 95 Dahua Network Camera Web 3.0 Operation Manual Figure 6-59 11. Click “Yes”. It will pop out the dialog box of “Import Successful”, click “Ok” to complete downloading Figure 6-60 certificate, which is shown in Figure 6-60  Please refer to the following steps if you select “Install Signed Certificate”. 1.
  • Page 96 Dahua Network Camera Web 3.0 Operation Manual Figure 6-61 2. Select signed certificate and certificate key path respectively via “Browse”, click “Upload”. 3. Install root certificate, please refer to step 6~11 for more details. 4. Check “Enable HTTPs”, click “Save”. The system will display the dialog box of “Need to reboot the device”, and then the config is valid.

  • Page 97: Event

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-63 Note: “xx.xx.xx.xx” is corresponding to your IP or domain name. 6.3 Event 6.3.1 Video detection 6.3.1.1 Motion Detection Step 1 Select “Setup > Event > Video Detection > Motion Detection‟ and the system will display the interface of “Motion Detection”...
  • Page 98 Dahua Network Camera Web 3.0 Operation Manual Figure 6-64 Step 2 Select “Enable” to enable motion detection function. Step 3 Set motion detection area.
  • Page 99 Dahua Network Camera Web 3.0 Operation Manual Click “Setup” and the system will pop out the interface of “Setting Area”, which is shown in Figure 6-65 Figure 6-65 2. Set area name, it is to set valid area of motion detection according to the actual situation, and it can set the value of sensitivity and threshold respectively.
  • Page 100 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Note: Working Period It is to set the alarm period, it can enable alarm event only during the period range which has been set. 1. Click “Setup” and the system will pop out the interface of “Working Period”.
  • Page 101 Dahua Network Camera Web 3.0 Operation Manual Parameter Function  Here you can set PTZ movement when alarm occurs. Such as go to preset x when there is an alarm.  The event type includes: preset, tour and pattern. You need to check the box here so that system can backup motion detection Snapshot snapshot file.
  • Page 102 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Note: Working Period It is to set the alarm period, it can enable alarm event only during the period range which has been set. 1. Click “Setup” and the system will pop out the interface of “Working Period”.
  • Page 103 Dahua Network Camera Web 3.0 Operation Manual Figure 6-67 Step 2 Check “Enable” to enable the function of scene changing. Step 3 It is to set the parameters of scene changing, please refer to the following sheet for more details. Parameter Function Note:...

  • Page 104: Audio Detection

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function If you enabled this function, System can send out email to alert you when Send Email alarm occurs and ends. User can set email address in Network>SMTP.  Here you can set PTZ movement when alarm occurs. Such as go to preset x when there is an alarm.
  • Page 105 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Select “Enable Input Abnormal” and it will trigger alarm when it detects Enable input abnormal audio input abnormity. Select “Enable Intensity Change” and it will trigger alarm when it detects Enable intensity change that audio intensity change exceeds the threshold.

  • Page 106: Smart Plan

    Dahua Network Camera Web 3.0 Operation Manual Step 3 Click “Save” to complete the setup of audio detection. 6.3.3 Smart Plan Smart plan is the master switch for intelligent analysis such as “Face Detection”, “Heat Map”, “IVS”, “People Counting” and so on, the corresponding intelligent functions can be valid after smart plan is enabled.
  • Page 107 Dahua Network Camera Web 3.0 Operation Manual  Try to lower the complexity of the monitoring scene analysis if it is possible; it is not advised to use IVS functions in the environment where the targets are dense and light change is very frequent. ...
  • Page 108 Dahua Network Camera Web 3.0 Operation Manual Click “Draw Rule” to draw tripwire in the monitoring scene, click the right mouse button to complete tripwire setting. Step 4 Click “Draw Target” to draw the size model of filtered target in the video image. Step 5 It is to set the parameters of tripwire, please refer to the following sheet for more details.
  • Page 109 Dahua Network Camera Web 3.0 Operation Manual Step 5 Click “Save” to complete the setup of tripwire. 6.3.4.2 Intrusion Intrusion includes cross and appears.  Cross means that it will trigger alarm when the target enters or exits the area. ...
  • Page 110 Dahua Network Camera Web 3.0 Operation Manual Click “Draw Rule” to draw an area in the monitoring image. Step 4 Click “Draw Target” to draw the size model of filtered target in the video image. Step 5 It is to set the parameters of intrusion, please refer the following sheet for more details. Parameter Function Select “Object tracking”...
  • Page 111 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Select “Snapshot” and the system will auto trigger alarm and snapshot when Snapshot alarm occurs. Step 5 Click “Save” to complete the setup of intrusion. 6.3.4.3 Abandoned Object Abandoned object means the system will trigger alarm if the abandoned object in the monitoring scene exceeds the time which has been set by the users.
  • Page 112 Dahua Network Camera Web 3.0 Operation Manual Figure 6-72 Step 3 Click “Draw Rule” to draw an area in the monitoring area. Step 4 Click “Draw Target” to draw the size model of filtered target in the video image. Step 5 It is to set the parameter of abandoned object, please refer to the following sheet for more details.
  • Page 113 Dahua Network Camera Web 3.0 Operation Manual Missing object means the system will trigger alarm if it exceeds certain amount of time after the target is taken away from the original scene. The system can make statistics of the still areas in the foreground area and distinguish if it is missing object or abandoned object according to the similarity between foreground and background, it will trigger alarm when it exceeds the time which is set by users.

  • Page 114: Face Detection

    Dahua Network Camera Web 3.0 Operation Manual Step 5 It is to set the parameters of missing object, please refer to the following sheet for more details. Parameter Function Note: Working Period It is to set the alarm period, it can enable alarm event only during the period range which has been set.
  • Page 115 Dahua Network Camera Web 3.0 Operation Manual Figure 6-74 Step 2 Select “Enable” to enable face detection function. Step 3 Click “Draw Target” to draw the size model of target filter in the video image. Step 4 It is to set the parameters of face detection, please refer to the following sheet for more details. Parameter Function Note:...

  • Page 116: People Counting

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function Relay out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when alarm occurs. System can delay the alarm output for specified time after alarm ended. Alarm Delay If you enabled this function, System can send out email to alert you when Send Email...
  • Page 117 Dahua Network Camera Web 3.0 Operation Manual Step 3 Click “Draw Rule” to draw an area in the monitoring image. Step 4 Click “Draw Target” to draw the size model of filtered target in the video image. Step 5 It is to set the parameters of entrance and exit, please refer to the following sheet for more details. Parameter Function Select “Enable OSD”...

  • Page 118: Heat Map

    Dahua Network Camera Web 3.0 Operation Manual Click “Save” to complete the setup of people counting. 6.3.6.2 Report It is to generate a form of report according to the number statistics. Step 1 Select “Setup > Event > People Counting > Report “and the system will display the interface of “Report‟, Figure 6-76 which is shown in Figure 6-76...
  • Page 119 Dahua Network Camera Web 3.0 Operation Manual It is the density statistics of moving object that can generate report, the color range is from blue to red, blue means the min heat value and red means the max heat value. Mirroring, view angle change and heat map original data will be cleared.
  • Page 120 Dahua Network Camera Web 3.0 Operation Manual Figure 6-78 2. It is to set working period according to the following methods:  You can input time numerical value or press the left mouse button to drag on the setup interface to set.

  • Page 121: Alarm

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-79 Step 2 It is to set begin time and end time. Step 3 Click “Search” to complete report statistics, click “Export” to export the statistics report. 6.3.8 Alarm Please note some series products do not support this function. 5.3.2.1 PIR alarm Figure 6-80 The alarm activation interface PIR alarm is shown as in...
  • Page 122 Dahua Network Camera Web 3.0 Operation Manual Figure 6-80 Please refer to the following sheet for detailed information. Parameter Function Enable After enabled, relay activation will work. Check it and enable the PIR alarm.  This function becomes activated in the specified periods. Working ...
  • Page 123 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Enable alarm activation function. You need to select alarm output Relay out port so that system can activate corresponding alarm device when alarm occurs. System can delay the alarm output for specified time after alarm Alarm delay ended.
  • Page 124 Dahua Network Camera Web 3.0 Operation Manual Parameter Function Check it and set PTZ movement when alarm occurs. Such as go to preset x when there is an alarm. The event type includes: preset, tour and pattern and so on. 6.3.8.2 Flash Set Figure 6-82 Parameter...

  • Page 125: Abnormity

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-83 parameter Function Enable Check it and enable audio detection. It will trigger alarm and set up a series of linkage when volume exceeds the set Threshold threshold. 6.3.9 Abnormity Abnormity includes No SD Card, Capacity Warning, SD Card Error, Disconnection, IP Conflict and Unauthorized Access.
  • Page 126 Dahua Network Camera Web 3.0 Operation Manual Figure 6-84 Figure 6-85...
  • Page 127 Dahua Network Camera Web 3.0 Operation Manual Figure 6-86 Please refer to the following sheet for detailed information. Parameter Function Check to alarm when SD card is abnormal. Enable Check to enable relay-out alarm. Relay-out Relay out The alarm output can delay for the specified time after alarm stops. The delay value ranges from 10s to 300s.

  • Page 128: Storage Management

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-87 When login password keep been wrong for a few times, unauthorized access alarm occurs. This operation is similar to SD card error. Allow login error times as when it exceeds this limit, user account will be locked.
  • Page 129 Dahua Network Camera Web 3.0 Operation Manual Figure 6-89 Step 2. From Monday to Sunday select record time, click on setup on the right, see Figure 6-90.  Set period according to actual need. There are six periods available each day. ...
  • Page 130 Dahua Network Camera Web 3.0 Operation Manual Figure 6-91 Step 4. In record schedule interface, click on OK. System prompts it is successfully saved. 6.4.1.2 Snapshot Schedule Snapshot setup as: Figure 6-92 Step 1. Click on Snapshot Schedule tab, see Figure 6-92 Figure 6-93 Step 2.
  • Page 131 Dahua Network Camera Web 3.0 Operation Manual  By checking or unchecking, user can add or delete three types of snapshot schedule: General, Motion and Alarm. Note: Period setup can be done by dragging in snapshot schedule interface while not releasing left mouse.

  • Page 132: Destination

    Dahua Network Camera Web 3.0 Operation Manual 6.4.1.3 Holiday Schedule Holiday schedule can set specific date as holiday. Figure 6-95 Step 1. Click on Holiday Schedule tab, see Figure 6-95 Step 2. Select date to set as holiday. The selected date will be highlighted in yellow. Step 3.
  • Page 133 Dahua Network Camera Web 3.0 Operation Manual Figure 6-96 Please refer to the following sheet for detailed information. Parameter Function Event It includes: scheduled, motion detect and alarm. Type Local It saved in the SD card. It saved in the FTP server. It saved in NAS disk.
  • Page 134 Dahua Network Camera Web 3.0 Operation Manual 6.4.2.3 FTP Figure 6-98 The FTP interface is shown as in You need to check the box to enable the FTP function. When network disconnect occurred or there is malfunction. Emergency storage can save the record/snapshot picture to the local SD card. Click the test button to check if the FTP server can be connected for test.

  • Page 135: Record Control

    Dahua Network Camera Web 3.0 Operation Manual 6.4.3 Record control Figure 6-100 The record control interface is shown as in Figure 6-100 Please refer to the following sheet for detailed information. Parameter Function Here you can select file size within 1min~120min. Default setup is 8 Pack minutes.
  • Page 136 Dahua Network Camera Web 3.0 Operation Manual Figure 6-101 Please refer to the following sheet for detailed information. Parameter Function It is to set device name. Device Note: Different devices have different names. Name Video This is to display video standard such as PAL. Standard Language You can select the language from the dropdown list.
  • Page 137 Dahua Network Camera Web 3.0 Operation Manual Figure 6-102 Please refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list. Date format There are two options: 24-H and 12-H. Time Format The time zone of the device.

  • Page 138: Account

    Dahua Network Camera Web 3.0 Operation Manual 6.5.2 Account  For user name and user group, the max length is 31 characters, which can be made up of digit, letter, underline, hyphen, dot and @.  Password can be 0~32 characters in number and letter only. User can modify other user‟s password.
  • Page 139 Dahua Network Camera Web 3.0 Operation Manual Please note the user rights shall not exceed the group right setup. For convenient setup, please make sure the general user has the lower rights setup than the admin. Figure 6-104 Modify user Figure 6-105 It is to modify the user property, belonging group, password and rights.
  • Page 140 Dahua Network Camera Web 3.0 Operation Manual Figure 6-105 6.5.2.2 Group The group management interface can add/remove group, modify group password and etc. Figure 6-106 The interface is shown as in Figure 6-106 Figure 6-107 Add group: It is to add group and set its corresponding rights. See...

  • Page 141: Ptz

    Dahua Network Camera Web 3.0 Operation Manual Please input the group name and then check the box to select the corresponding rights. It includes: preview, playback, record control, PTZ control and etc. Figure 6-107 Modify group Figure 6-108 Click the modify group button, you can see an interface is shown as in Here you can modify group information such as remarks and rights.

  • Page 142: Default

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-109 The PTZ settings interface is shown as in Figure 6-109 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Set corresponding dome address. Default value is 1. Address Please note your setup here shall comply with your dome address;...

  • Page 143: Import/Export

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-110 6.5.5 Import/Export Figure 6-111 The interface is shown as in Figure 6-111 Please refer to the following sheet for detailed information. Parameter Function It is to import the local setup files to the system. Import It is to export the corresponding system setup to your local PC.

  • Page 144: Auto Maintenance

    Dahua Network Camera Web 3.0 Operation Manual Figure 6-112 Parameter Function Learn Bind remote control or wireless alarm with equipment. Clear Unbind remote control with equipment. Start arm after the time you choose, disarm comes into effect immediately. Note: With disarm status, all the following alarms won‟t trigger: motion detect alarm, Arm/Disarm masking alarm, local alarm, PIR alarm, wireless alarm.

  • Page 145: Upgrade

    Dahua Network Camera Web 3.0 Operation Manual Parameter Function Auto Reboot Check it and set auto reboot time. Auto Delete Old Check it and set period within 1~31 days. Files 6.5.7 Upgrade Figure 6-114 The upgrade interface is shown as in Please select the upgrade file (file extension is “.bin”) and then click the update button to begin firmware update.

  • Page 146: Log

    Dahua Network Camera Web 3.0 Operation Manual 6.6.2 Log Figure 6-116 Here you can view system log. See Figure 6-116 Please refer to the following sheet for log parameter information. Parameter Function Set the start time of the requested log. (The earliest time is 2000/1/1) Start time Set the end time of the requested log.
  • Page 147 Dahua Network Camera Web 3.0 Operation Manual Figure 6-117...

  • Page 148: Alarm

    Dahua Network Camera Web 3.0 Operation Manual 7 Alarm Please note some series product does not support this function. Figure 7-1 Click alarm function, you can see an interface is shown as in Here you can set device alarm type and alarm sound setup. Figure 7-1 Please refer to the following sheet for detailed information.
  • Page 149 Dahua Network Camera Web 3.0 Operation Manual Type Parameter Function Operation Prompt When alarm is triggered, there will be s inmain menu of alarm interface and system automatically records alarm info. The icon disappears when user click on alarm menu bar. Note: If alarm interface is displayed, when alarm is triggered, there will be no image prompt, but alarm...

  • Page 150: Log Out

    Dahua Network Camera Web 3.0 Operation Manual 8 Log out Figure 8-1 Click log out button, system goes back to log in interface. See Figure 8-1 Note  This manual is for reference only. Slight difference may be found in user interface. ...
