SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, OPC UA Server
and DeviceNet Slave.
By Pressing the "Set Communication" button from the main window for SW67B36 (Fig. 2) the
window "Set Communication" appears (Fig. 3).
The means of the fields for "Ethernet Connection" are:
In the field "Device Name
defined;
If the field "Obtain an IP Address Automatically (DHCP for Cable
checked, DHCP for LAN connection is enabled;
If the field "Enable DNS" is checked, DNS protocol is enabled;
In the field "Primary DNS" the IP Address of the primary DNS server is defined;
In the field "Secondary
The means of the fields for "OPC UA Server" are:
In the field "IP Address" the IP address for OPC UA side of the converter is defined;
In the field "SubNet Mask" the SubNet Mask for OPC UA side of the converter is defined;
In the field "Gateway" the default gateway of the net is defined. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out of the
net;
In the field "Port" the port of OPC UA Server is defined.
The means of the fields for "DeviceNet Slave" are:
In the "ID Device" field the Gateway address of the DeviceNet is defined.
In the "Baudrate" field the DeviceNet baud rate is defined;
In the field "Number Byte
defined (at maximum it is possible to use 455 byte);
In the field "Number Byte
455 byte).
ADFweb.com Srl – IT31010 – Mareno – Treviso
(Hostname)" the Hostname to assign to the converter is
DNS" the IP Address of the secondary DNS server is defined.
IN" the number of byte from the DeviceNet to the gateway is
OUT" the number of byte from the gateway to the DeviceNet is defined (at maximum it is possible to use
User Manual OPC UA Server / DeviceNet Slave
Document code: MN67B36_ENG
Connection)" is
Figure 3: "Set Communication" window
