C H A P T E R 1 3 – T E S T
13.5.1.
Description
Continuity
DC Resistance
DC Resistance Match
Inductance (Series circuit)
Inductance (Parallel circuit)
Inductance Match
Inductance with Bias (Series)
Inductance with Bias (Parallel)
Impedance with Bias
Inductance with Bias Series (DC1000)
Inductance with Bias Parallel (DC1000)
Impedance with Bias
Quality Factor
Dissipation Factor
Equivalent Series Resistance
Equivalent Parallel Resistance
Impedance
Impedance Phase Angle
Leakage Inductance
Inter-winding Capacitance
Inter-winding Capacitance Match
Turns Ratio and Phasing by Voltage
Turns Ratio and Phasing by Inductance
Low open Circuit Voltage
Inter-winding Phase
Insertion Loss
Return Loss
Longitude Balance
General Longitude Balance
Frequency Response
Magnetizing Current
Open Circuit Voltage
Wattage
Stress Wattage
Magnetizing Current (AC Interface)
Open Circuit Voltage (AC Interface)
Wattage (AC Interface)
Stress Wattage (AC Interface)
Leakage Current
Insulation Resistance
Hi-Pot (DC)
Hi-Pot (AC)
Surge Stress
Output to User Port
Power Factor
Wait
AT5600 User Manual 98-119 issue 30
F I X T U R E S
Compensation Summary – Available Tests
TEST
Mnemonic
CTY
R
R2
LS
LP
L2
LSB
LPB
ZB
LSBX
LPBX
(DC1000) ZBX
QL
D
RLS
RLP
Z
ANGL
LL
C
C2
TR
TRL
LVOC
PHAS
ILOS
RLOS
LBAL
GBAL
RESP
MAGI
VOC
WATT
STRW
MAGX
VOCX
WATX
STRX
ILK
IR
HPDC
HPAC
SURG
OUT
PWRF
WAIT
COMPENSATION AVAILABLE?
S/C O/C
Yes
No
Yes No
Yes No
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes No
Yes Yes
Yes Yes
Yes No
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
No Yes
No Yes
No Yes
No Yes
No No
No No
No No
No No
No Yes
No Yes
No Yes
No Yes
No No
N/a N/a
No No
No No
Load
(User
choice)
n/a
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
N/a
Yes
N/a
