C H A P T E R 5 – G E T T I N G
5.4.4.
The Voltech Server software is supplied with every AT5600. The use of the
Server software is required for handling and storage of test results and is
recommended for handling large numbers of different test programs.
Having created, saved, and tested the program TUTORIAL using the Editor, you
are now able to run it again on your AT Series Tester, but this time using the
Server. The procedure for transferring the program to the Server archive will
depend on where you have installed the Editor and Server programs.
Editor and Server on Separate PC's
In many situations, the Editor and Server would be installed on separate PC's (as
shown in the illustration on page 2.2.2). It is not common for a company to use a
Network drive to store test programs in one central location.
The *.ATP files can be easily moved using normal Windows Cut and Paste in
windows explorer from your PC to a network drive.
Editor and Server on the same PC
If the Server and Editor are installed on the same PC, the easiest way to transfer
the test program to the Server is to use the Save As menu in the Editor:
From the Top Level 'Part' menu, select 'Save As,'
At the dialogue box, type in the part name TUTORIAL, as before, but change the
directory to the one selected for program storage for the Server.
e.g., C:\AT3600\SERVER
AT5600 User Manual 98-119 issue 30
S T A R T E D

Transferring the Program to the Server

Page 71
