All functions are available in the main menu. If you look for a specific function, you
can use the menu overview to navigate fast to the desired function.

Menu Overview

Calibration required
Perform
Measurement
Info
Sensor
Statistics
Device
Contact
Event and error log
Besides the standard design of the screens, there are two types of screens which
need special attention by the user. When the user requests irreversible actions, a
turquoise attention screen appears (see Figure 7). Any error will be displayed in
red (see Figure 8) and includes the header "Error", an exclamation mark, a short
failure description, if available a short application for action and an error code.
Figure 7- Attention! Screen
10
Ready
Counter
Extras
Version
Calibration value log
Main Menu
Counter Preset
Memory
Stand-By
Limits
Control 2
Counter Preset
Figure 8- Error screen
Device Settings
Limits Maintenance
Control 1 Range Violation
Samples
Tray Sample
Control 1 Control 2
STAT
