ASSEMBLY INSTRUCTIONS
BRODY WING COUNTER STOOL
Please read below before assembly
Assemble the product on a flat, soft surface such as a carpet or cloth to prevent scratching
the finish.
Do not discard any content until assembly is complete to avoid accidentally discarding small
parts or hardware.
Take out all parts and hardware from box.
Failure to follow these instructions may cause the bolts to misalign during assembly.
DISCLAIMERS:
WHEN PROPERLY ASSEMBLED, THIS ITEM IS SAFE FOR INTENDED USE. SELLER IS NOT LIABLE
FOR ANY DAMAGES RESULTING FROM ITEM BEING IMPROPERLY ASSEMBLED AFTER PURCHASE.
BOLTS MAY LOOSEN DURING NORMAL EVERYDAY USE. THEY SHOULD BE INSPECTED AT LEAST
EVERY 3 MONTHS AND RE-TIGHTENED AS NEEDED TO PREVENT DAMAGE OR INJURY, AND
ENSURE STABILITY.
PEOPLE NEEDED
TOOLS REQUIRED (NOT INCLUDED)
PHILLIPS HEAD SCREW DRIVER
MADISON
300
lbs seat
WEIGHT LIMIT
10
Minutes
ESTIMATED TIME
RUBBER MALLET
R
Page 1 of 7
Advertisement
Related Manuals for Madison Park BRODY
Summary of Contents for Madison Park BRODY
- Page 1 ASSEMBLY INSTRUCTIONS MADISON BRODY WING COUNTER STOOL Please read below before assembly Assemble the product on a flat, soft surface such as a carpet or cloth to prevent scratching the finish. Do not discard any content until assembly is complete to avoid accidentally discarding small parts or hardware.
-
Page 2: Parts List
PARTS LIST CHAIR BACK 1 PC SEAT CUSHION LEFT STRETCHER RIGHT STRETCHER FRONT STRETCHER FRONT LEG 2 PCS HARDWARE LIST LONG BOLT Ø5/16" x 2" 6 PCS SHORT BOLT Ø5/16" x 1-1/2" 2 PCS LOCK WASHER 5/16" 8 PCS FLAT WASHER 5/16" 8 PCS ALLEN KEY 1 PC... - Page 3 STEP 1 LOCATE PARTS AND HARDWARE PER BELOW DRAWING HARDWARE LEG + STRETCHER LEG + STRETCHER BOX Page 3 of 7...
- Page 4 STEP 2 2 PCS 2 PCS 2 PCS 1 PC NOTE: DO NOT FULLY TIGHTEN BOLTS. STEP 3 2 PCS 2 PCS 2 PCS 1 PCS NOTE: DO NOT FULLY TIGHTEN BOLTS. Page 4 of 7...
- Page 5 STEP 4 2 PCS 2 PCS 2 PCS 1 PC NOTE: DO NOT FULLY TIGHTEN BOLTS. STEP 5 2 PCS 2 PCS 2 PCS 1 PC NOTE: DO NOT FULLY TIGHTEN BOLTS. Page 5 of 7...
- Page 6 STEP 6 6 PCS NOTE: TIGHTEN ALL SCREWS This face forward STEP 7 NOTE: PLEASE TIGHTEN ALL BOLTS. Page 6 of 7...
- Page 7 Care & Maintenance Do... Wipe up spills immediately. Dust and pick-up spills using a clean, non-colored, lint-free, dry cloth. Use mild non-abrasive soap and water. Don't... Do not put hot items directly on furniture surface. Do not clean furniture with harsh cleansers or polish. Do not place furniture in direct sunlight.
