- Page 1 Bolt 2-3/8 Screw M4 x 1-1/2 Page 1 of 4...
- Page 2 Assembly Procedure : Step 1.Attach legs ( P2 ) to Seat ( P1 ) by using 2 Bolts ( H1 ) , 2 Spring Washers ( H2 ) & 2 Flat Washers ( H3 ) . Do not tighten bolts on this step. Step 2.
- Page 3 Step 3. Insert one of front stretcher ( P3 ) into hole on leg ( P2 ) . Loosely attach other leg ( P2 ) to seat ( P1 ) and front stretcher ( P3 ). Do not tighten bolts on this step. Step 4.
- Page 4 Step 5. Use Screw ( H4 ) to fasten front stretcher ( P3 ) and side stretchers ( P4 ) to legs. Use screw driver to fix the screws. Tighten all bolts with allen key. Leg Level Guidance Before tightening all bolts , turn over the chair so it sits on legs , and adjust the legs to level the chair. Then tighten all the bolts.
