  • Page 1 SW230 PORTABLE SPOT WELDER OPERATING INSTRUCTIONS www.strata.co.nz...
  • Page 2 SW230 Congratulations on your new Strata product! The Strata range from Euroquip uses latest technology design and engineering to produce welding products that combine market leading value and features with durability. Designed for discerning operators who seek professional results and product quality without the price tag of a full professional setup.
  • Page 3: Table Of Contents

    SW230 Contents 1. Product Features...........4 2. Product Specifications..........5 3. Installation Of Welder...........6 4. Welding..............6 5. Welding Defects...........6 6. Product Operation..........7 7. Welding Arm Replacement & Adjustment....7 8. Care & Maintenance..........8 9. General Safety............9 10. Warranty............13 www.strata.co.nz...
  • Page 4: Product Features

    4. Thermally Isolated Handle: The handle is crafted from thermally isolated materials, enhancing safety and comfort during extended use. 5. Thermal Protection: Equipped with thermal protection to prevent overheating, ensuring both the safety of the operator and the longevity of the machine. www.strata.co.nz...
  • Page 5: Product Specifications

    SW230 2. Product Specifications 220-230V Input voltage 50/60Hz Input Current Output Current 6300-8900A Output voltage 1-2V 1.0+1.0+1.0/2.0+2.0 Maximum welding thickness Load sustained rate Size 450X200X100 mm Packing size 500X300X150 mm Stand-alone 10kg/With Packaging 15kg Weight www.strata.co.nz...
  • Page 6: Installation Of Welder

    Hold the sheet metal together & gently lower the lever to hold it securely in place between the electrodes, where you would like the weld. Push the lever all the way down to start the welding process. www.strata.co.nz...
  • Page 7: Product Operation

    5. Fine-Tuning Pressure: - Pressure Adjustment: Adjust the internal hex screws within the pressure arm to modify the welding electrode pressure. This adjustment is crucial for achieving the best welding results, especially in high yield point and high-stress scenarios. www.strata.co.nz...
  • Page 8: Care & Maintenance

    Only experts must carry out repairing of electrical appliances, otherwise considerable danger for the user may result. Use only genuine replacement part. Do not use modified or non-genuine parts. www.strata.co.nz...
  • Page 9: Important Safety Information

    NOTE, used to address practices not related to per- Electromagnetic fields in close proximity to a sonal injury. heart pacemaker could cause interference, or failure of the pacemaker. The use of a Welder is NOT RECOMMENDED for pacemaker wearers. Consult your doctor. www.strata.co.nz...
  • Page 10: Personal Safety

    This enables better control of ment. Anyone not having extensive training in weld- the power tool in unexpected situations. ing and cutting practices should not attempt to weld. www.strata.co.nz...
  • Page 11: Noise Can Damage Hearing

    3. Enclose the work area with portable fire resistant protection. screens. Protect combustible walls, ceilings, 3. Insulate yourself from the work and the ground floors, etc., from sparks and heat with fire re- using dry insulating mats or covers. sistant covers. www.strata.co.nz...
  • Page 12 . s r 11. Do not touch the electrode while in contact with the holder in water to cool it or lay it down on the the work (ground) circuit. www.strata.co.nz...
  • Page 13: Warranty

    Should any issue be found to be a combination of a war- ranty failure and a non-warranty issue, the repair cost com- ponent to rectify and repair the non-warranty failure is the customers’ full responsibility. www.strata.co.nz...
  • Page 14 SW230 Notes www.strata.co.nz...
  • Page 15 SW230 Notes www.strata.co.nz...
  • Page 16 Congratulations on your new STRATA product. We are proud to have you as our customer and will strive to provide you with the best service and reliability in the industry. This product is backed by our extensive warranty. To locate your nearest distributor or service agency visit www.strata.co.nz, or email us at...
