3.4 Technical data

iSCANX4C-1-P:
iSCANX4C-1-Q:
• maximum input voltage
• maximum input current
• maximum input power
• maximum internal
inductance
• maximum internal
capacitance

If using a power supply other than iSCANPSX:

• maximum input voltage
• maximum input current
• maximum input power
• maximum internal
inductance
• maximum internal
capacitance
Note: The input voltage into the handheld scanner itself is reduced
by the associated connection cable ISCANX4C-CAB5 or 6 to 4.9V.
• maximum input voltage
• maximum input current
• maximum input power
• maximum internal
inductance
• maximum internal
capacitance
8
Ui 4.9 V
li 480 mA
Pi 1.25 W
Li negligible
Ci 141 µF
Ui 5.6 V
li 480 mA
Pi 1.25 W
Li negligible
Ci 46 µF
Ui 5.6 V
li 1180 mA
Pi 4,5 W
Li negligible
Ci 373 µF
