SPX POWER TEAM 61253 Operating Instructions Manual

Electric two-stage hydraulic pump

Advertisement

Quick Links

SPX Corporation
5885 11th Street
Rockford, IL 61109-3699 USA
Internet Address:
http://www.powerteam.com
ELECTRIC TWO-STAGE HYDRAULIC PUMP
Read and carefully follow these instructions. Most problems with new equipment are caused by improper operation or
installation.
WARNING:
Hydraulic Hose
G
Before operating the pump, all hose connections must be tightened using the proper tools. Do not
overtighten. Connections need only be tightened securely and leak-free. Overtightening may cause
premature thread failure or may cause high pressure fittings to split at pressures lower than their rated
capacities.
G
Should a hydraulic hose ever rupture, burst, or need to be disconnected, immediately shut off the pump
and shift the control valve twice to release all pressure. Never attempt to grasp a leaking hose under
pressure with your hands. The force of escaping hydraulic fluid could cause serious injury.
G
Do not subject the hose to potential hazard such as fire, extreme heat or cold, sharp surfaces, or heavy
impact. Do not allow the hose to kink, twist, curl or bend so tightly that the oil flow within the hose is
blocked or reduced. Periodically inspect the hose for wear because any of these conditions can damage
the hose and may result in personal injury.
G
Do not use the hose to move attached equipment. Stress may damage the hose and cause personal
injury.
G
Hose material and coupler seals must be compatible with the hydraulic fluid used. Hoses also must not
come in contact with corrosive materials such as creosote-impregnated objects and some paints. Consult
the manufacturer before painting a hose. Never paint the couplers. Hose deterioration due to corrosive
materials may result in personal injury.
Pump
G
Do not exceed the PSI hydraulic pressure rating noted on the pump nameplate or tamper with the internal
high pressure relief valve. Creating pressure beyond rated capacities may result in personal injury.
G
Before replenishing the oil level, retract the system to prevent overfilling the pump reservoir. An overfill
may cause personal injury due to excess reservoir pressure created when the cylinders are retracted.
Cylinder
G
Do not exceed the rated capacities of the cylinder. Excess pressure may result in personal injury.
G
Do not set poorly-balanced or off-center loads on a cylinder. The load may tip and cause personal injury.
Power Supply (Electric)
G
Do not use an ungrounded (two-prong) extension cord with this unit.
G
Avoid any conditions that could create an electrical hazard.
G
Any electrical work must be done by a qualified electrician.
G
If the power cord is damaged or wiring is exposed, replace or repair immediately.
Litho in USA
Tech. Services: (800) 477-8326
Fax: (800) 765-8326
Order Entry: (800) 541-1418
Fax: (800) 288-7031
SAFETY PRECAUTIONS
To help avoid personal injury,
®
Parts List for &
Operating Instructions
for:
MODEL C
Form No. 102626
61253
61809
61253-50-220
61809-200
61698
Next
Page
Sheet No.
1 of 8
Rev. 3
Date: 17 Oct. 1997

Advertisement

loading
Need help?

Need help?

Do you have a question about the 61253 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SPX POWER TEAM 61253

  • Page 1 Operating Instructions SPX Corporation Tech. Services: (800) 477-8326 5885 11th Street Fax: (800) 765-8326 for: Rockford, IL 61109-3699 USA Order Entry: (800) 541-1418 Fax: (800) 288-7031 61253 61809 Internet Address: 61253-50-220 61809-200 http://www.powerteam.com 61698 MODEL C ELECTRIC TWO-STAGE HYDRAULIC PUMP Read and carefully follow these instructions.
  • Page 2: Operating Procedure

    Parts List and Operating Instructions, Form No. 102626, Back sheet 1 of 8 WARNING: Cont'd. Power Supply (Electric) Changing the voltage on this motor is a complicated and, if not done correctly, dangerous procedure. Consult the manufacturer for specific information before attempting any rewiring. Rewiring voids CSA approval.
  • Page 3: Preventive Maintenance

    Parts List and Operating Instructions Form No. 102626 PREVENTIVE MAINTENANCE WARNING: To help avoid personal injury, Disconnect the pump from the power source before performing maintenance or repair procedures. Repairs or maintenance must be performed in a dust-free area by a qualified technician. Bleeding Air from the System Upon initial start up or after prolonged use, air can accumulate within the hydraulic system.
  • Page 4: Troubleshooting Guide

    Parts List and Operating Instructions, Form No. 102626, Back sheet 2 of 8 TROUBLESHOOTING GUIDE IMPORTANT: Any repair work or troubleshooting should be performed by qualified personnel familiar with this equipment. Use the proper gauges and equipment when troubleshooting. NOTE: Depending on the pump version, it is often best to check for leaks by using a hand pump and applying pressure to the suspect area without the motor running.
  • Page 5 Parts List and Operating Instructions Form No. 102626 PROBLEM CAUSE SOLUTION Pump is not delivering oil or 1. Oil level too low. 1. Fill reservoir to within 2" of filler delivers only enough oil to plug with all cylinders retracted. advance cylinder(s) partially or 2.
  • Page 6: Hydraulic Schematic

    Parts List and Operating Instructions, Form No. 102626, Back sheet 3 of 8 PROBLEM CAUSE SOLUTION Automatic valve does not build 1. Pilot pressure is too low. 1. Increase pilot pressure. full pressure. 2. Defective or oversize seat on 2. Replace ball and seat. automatic valve.
  • Page 7 Parts List and Operating Instructions Form No. 102626 ELECTRICAL SCHEMATIC 115 V., 60 HZ. ELECTRICAL SCHEMATIC 220 V., 50 HZ. WARNING To help avoid personal injury, all electrical work must be done by a qualified electrician. North American & International Color Codes Conductors North American International...
  • Page 8: Cross Section View

    Parts List and Operating Instructions, Form No. 102626, Back sheet 4 of 8 To Parts CROSS SECTION VIEW List For Valve Assembly see form #100445 .001/.010 Clearance Required...
  • Page 9 Parts List and Operating Instructions Form No. 102626 Item Part Req’d Description 58129 Electric Motor (1/2 HP; For #61253 & #61698) 47137 Electric Motor (1/2 HP; For #61809 & #61809-200) 304920 Electric Motor (1/2 HP; For #61253-50-220) 200188 Warning Decal...
  • Page 10 Parts List and Operating Instructions, Form No. 102626, Back sheet 5 of 8 BOTTOM VIEW & SECTION A-A To Parts List SECTION A-A...
  • Page 11 Parts List and Operating Instructions Form No. 102626 Item Part Req’d Description 14440 Elbow Fitting (90°) 10258 Washer (13/16 x 3/8 x 1/16 Thk.) 213663 Flange Head Screw (Torque to 230/250 in. lbs.) 11461 Clamp Ring 10854 Soc. Hd. Cap Screw (1/4-20 x 1-3/4"...
  • Page 12 Parts List and Operating Instructions, Form No. 102626, Back sheet 6 of 8 TOP VIEW OF #61253 & 61809 "B" "B" 11, 12 .437 .562 < < COVER PLATE HANDLE SECTION B-B Item Part Req’d Description 304340 Handle 53350BK2 Cover Plate 10177 Rd.
  • Page 13 Parts List and Operating Instructions Form No. 102626 TOP VIEW OF #61253-50-220 & 61809-200 11, 12 .000 .120 COVER PLATE "B" "B" HANDLE 5, 6 SECTION B-B Control Box Assembly See Back sheet 7 of 8 Item Part Req’d Description...
  • Page 14 Parts List and Operating Instructions, Form No. 102626, Back sheet 7 of 8 CONTROL BOX FOR #61253-50-22 & #61809-200 POWER CORD GROUND (MUST BE ISOLATED BETWEEN NUTS AND CAN BE AT TOP OR BOTTOM 1, 2, 3 OF STACK.) GRD-1...
  • Page 15 Parts List and Operating Instructions Form No. 102626 TOP VIEW OF #61698 1, 2 6, 7, 8 "B" "B" Control Box Assembly See Back sheet 8 of 8 Item Part Req’d Description 20937 Filler/Vent Plug 200415 O-ring (Square section) 10177 Rd.
  • Page 16 Parts List and Operating Instructions, Form No. 102626, Back sheet 8 of 8 CONTROL BOX FOR #61698 Item Part Req’d Description 15468 Tapping Screw (#6; Inside motor cavity) 10975 Pan Head Screw (#8-32 X 5/16 Lg.) 19837 .16 ft. Heat Shrink 11362 Conduit Lockwasher 45040...
