Flex-i-Pro 360/470/520/520 XP
IMPORTANT
Please follow the instructions in this guide when preparing the installation site prior to arrival and
installation of the equipment.
April 1st, 2019
Edition AA, Part No 10087685
English (en-us) Original version

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flex-i-Pro 360 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Glunz & Jensen Flex-i-Pro 360

  • Page 1 Pre-installation Guide Flex-i-Pro 360/470/520/520 XP IMPORTANT Please follow the instructions in this guide when preparing the installation site prior to arrival and installation of the equipment. April 1st, 2019 Edition AA, Part No 10087685 English (en-us) Original version...
  • Page 2 ( Blank ) Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 3: About This Manual

    About this manual About this manual This manual applies to the Flexo Processor Flex-i-Pro 360 / 470 / 520 / 520 XP. This manual is published by: Glunz & Jensen A/S Lindholm Havnevej 29 5800 Nyborg Denmark Phone: +45 57 68 81 81 E-mail: gj@glunz-jensen.com...
  • Page 4: Table Of Contents

    Dimensions and connections Connection requirements Compressed air Exhaust connection Solvent connection Electrical requirements Main power outlet Power cable Electrical specifications Power supply requirements Power consumption Flex-i-Pro Checklist Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 5: Introduction

    CAUTION avoid any mechanical or electrical damage to the equipment. The operator must observe and/or act according to the information in order to WARNING avoid any personal injury. April, 2019 Pre-installation Guide|Flex-i-Pro 360 / 470 / 520 / 520 XP...
  • Page 6 Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 7: Transportation

    Width (W) 1900 mm (74.8") 2200 mm (86.6") 2300 mm (90.6") 2300 mm (90.6") Height (H) 1800 mm (70.9") 1800 mm (70.9") 1800 mm (70.9") 1800 mm (70.9") April, 2019 Pre-installation Guide|Flex-i-Pro 360 / 470 / 520 / 520 XP...
  • Page 8: Weight

    Report any damage of the crate to the shipping company and notify the insurance agent, if appropriate, before the mishandled package is opened. Handling the crate The icons on the crate indicate how to handle the crate during transport and storage: Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 9: Lifting The Crate

    It is only possible to lift the equipment off the pallet using a forklift truck or a pallet mover. CAUTION: Make sure to provide a forklift designed and adequate for lifting a crate of the size and weight as specified in this manual. April, 2019 Pre-installation Guide|Flex-i-Pro 360 / 470 / 520 / 520 XP...
  • Page 10: Required Width Of Passage And Doorways

    (82.7") (94.5") (98.4") (98.4") CAUTION: May require machine more than moving skates suitable for transport of very heavy equipment. 1950 2250 2350 2350 (76.8") (88.6") (92.5") (92.5") Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 11: Installation Requirements

    The floor should have a variation in height of no more than 6 mm per meter (1/4” over 40” length). If in doubt about the floor loading, please consult a structural engineer. April, 2019 Pre-installation Guide|Flex-i-Pro 360 / 470 / 520 / 520 XP...
  • Page 12: Space Requirements

    3247 mm (127.8") Flex-i-Pro 470 6953 mm (273.7") 3532 mm (139.1") Flex-i-Pro 520 7270 mm (286.2") 3648 mm (143.6") Flex-i-Pro 520 XP 8682 mm (339.6") 3648 mm (143.6") Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 13: Dimensions And Connections

    Installation requirements Dimensions and connections Flex-i-Pro 360 April, 2019 Pre-installation Guide|Flex-i-Pro 360 / 470 / 520 / 520 XP...
  • Page 14 Installation requirements Flex-i-Pro 470 Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 15 Installation requirements Flex-i-Pro 520 April, 2019 Pre-installation Guide|Flex-i-Pro 360 / 470 / 520 / 520 XP...
  • Page 16 Installation requirements Flex-i-Pro 520 XP Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 17: Connection Requirements

    CAUTION: Never lead solvent into a drain, as most solvents are strong pollutants. It is also illegal to empty these types of chemicals into the public sewer system. Under all circumstances local regulations applying to the treatment of chemical waste must be followed strictly. April, 2019 Pre-installation Guide|Flex-i-Pro 360 / 470 / 520 / 520 XP...
  • Page 18: Electrical Requirements

    The conductors in the power supply cable should be of copper. Provide for additional cable protection, e.g. cable covers, if cable is exposed to heavier transport such as fork-lift trucks etc. Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 19: Electrical Specifications

    Flex-i-Pro Flex-i-Pro Flex-i-Pro Flex-i-Pro 520 XP In operate, per phase 8500 W (29000 8500 W (29000 8500 W (29000 10000 W (34200 (±10%), max. BTU) BTU) BTU) BTU) April, 2019 Pre-installation Guide|Flex-i-Pro 360 / 470 / 520 / 520 XP...
  • Page 20 Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
  • Page 21: Checklist

    Is there a house electrician available? Are there any known problems in the building where the equipment will be installed? If YES, please describe which: April, 2019 Pre-installation Guide|Flex-i-Pro 360 / 470 / 520 / 520 XP...
  • Page 22 Click on Login and then Create new account. Fill up the required fields and checkboxes. Then click on CREATE NEW ACCOUNT. After while the login information will be delivered to the specified e-mail. Pre-installation Guide Flex-i-Pro 360 / 470 / 520 / 520 XP April, 2019...
