- Page 1 Pre-installation Guide Flex-Pro 360/470/520/520 XP IMPORTANT Please follow the instructions in this guide when preparing the installation site prior to arrival and installation of the equipment. July 30th, 2024 Edition AC, Part No 10087685 English (en-us) Original version...
- Page 2 ( Blank ) Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024...
-
Page 3: About This Manual
About this manual About this manual This manual applies to the Flexo Processor Flex-Pro 360/470/520/520 XP. This manual is published by: Glunz & Jensen A/S Selandia Park 1 DK-4100 Ringsted Denmark Phone: +45 57 68 81 81 E-mail: gj@glunz-jensen.com Internet: www.glunz-jensen.com Copyright ©... -
Page 4: Table Of Contents
Space requirements Free space around the equipment Dimensions and connections Connection requirements Compressed air Exhaust connection Solvent connection Electrical requirements Main power outlet Power cable Electrical specifications Power supply requirements Power consumption Checklist Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024... -
Page 5: Introduction
The operator must observe and/or act according to the information in order to CAUTION avoid any mechanical or electrical damage to the equipment. The operator must observe and/or act according to the information in order to avoid any personal injury. WARNING July, 2024 Pre-installation Guide|Flex-Pro 360/470/520/520 XP... - Page 6 Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024...
-
Page 7: Transportation
3000 mm (118.1") 4350 mm (171.3") Width (W) 1900 mm (74.8") 2200 mm (86.6") 2300 mm (90.6") 2300 mm (90.6") Height (H) 1800 mm (70.9") 1800 mm (70.9") 1800 mm (70.9") 1800 mm (70.9") July, 2024 Pre-installation Guide|Flex-Pro 360/470/520/520 XP... -
Page 8: Weight
Check the Tilt watch and the Shock watch label that the red mark has not appeared and compare their serial numbers with those on the box label whether they match. Handling the crate The icons on the crate indicate how to handle the crate during transport and storage: Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024... -
Page 9: Lifting The Crate
It is only possible to lift the equipment off the pallet using a forklift truck or a pallet mover. CAUTION: Make sure to provide a forklift designed and adequate for lifting a crate of the size and weight as specified in this manual. July, 2024 Pre-installation Guide|Flex-Pro 360/470/520/520 XP... -
Page 10: Required Width Of Passage And Doorways
The Service Technician has to unpack the equipment. (82.7") (94.5") (98.4") (98.4") CAUTION: May require machine more than moving skates suitable for transport of very heavy equipment. 1950 2250 2350 2350 (76.8") (88.6") (92.5") (92.5") Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024... -
Page 11: Installation Requirements
The floor should have a variation in height of no more than 6 mm per meter (1/4” over 40” length). If in doubt about the floor loading, please consult a structural engineer. July, 2024 Pre-installation Guide|Flex-Pro 360/470/520/520 XP... -
Page 12: Space Requirements
Flex-Pro 360 6485 mm (255.3") 3247 mm (127.8") Flex-Pro 470 6953 mm (273.7") 3532 mm (139.1") Flex-Pro 520 7270 mm (286.2") 3648 mm (143.6") Flex-Pro 520 XP 8682 mm (339.6") 3648 mm (143.6") Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024... -
Page 13: Dimensions And Connections
Installation requirements Dimensions and connections Flex-Pro 360 July, 2024 Pre-installation Guide|Flex-Pro 360/470/520/520 XP... - Page 14 Installation requirements Flex-Pro 470 Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024...
- Page 15 Installation requirements Flex-Pro 520 July, 2024 Pre-installation Guide|Flex-Pro 360/470/520/520 XP...
- Page 16 Installation requirements Flex-Pro 520 XP Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024...
-
Page 17: Connection Requirements
CAUTION: Never lead solvent into a drain, as most solvents are strong pollutants. It is also illegal to empty these types of chemicals into the public sewer system. Under all circumstances local regulations applying to the treatment of chemical waste must be followed strictly. July, 2024 Pre-installation Guide|Flex-Pro 360/470/520/520 XP... -
Page 18: Electrical Requirements
Please be aware of double pole/neutral fusing. CAUTION: The conductors in the power supply cable should be of copper. Provide for additional cable protection, e.g. cable covers, if cable is exposed to heavier transport such as fork-lift trucks etc. Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024... -
Page 19: Electrical Specifications
300 mA. Power consumption Flex-Pro Flex-Pro Flex-Pro Flex-Pro 520 XP In operate, per phase 8500 W (29000 8500 W (29000 8500 W (29000 10000 W (34200 (±10%), max. BTU) BTU) BTU) BTU) July, 2024 Pre-installation Guide|Flex-Pro 360/470/520/520 XP... - Page 20 Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024...
-
Page 21: Checklist
Is there a house electrician available? Are there any known problems in the building where the equipment will be installed? If YES, please describe which: July, 2024 Pre-installation Guide|Flex-Pro 360/470/520/520 XP... - Page 22 Click on Login and then Create new account. Fill up the required fields and checkboxes. Then click on CREATE NEW ACCOUNT. After while the login information will be delivered to the specified e-mail. Pre-installation Guide Flex-Pro 360/470/520/520 XP July, 2024...
