- Page 1 Pellet Stove LINE PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE The instruction manual is an integral part of the product...
-
Page 2: Table Of Contents
For information regarding operation, please refer to the manual " OPERATING INSTRUCTIONS ". ■ ■ For the restrictions, limitations and exclusions please refer to the warranty included with the product. In line with its policy of constant product improvement and renewal, the manufacturer may make changes without notice. -
Page 3: General Information
T.A.C. (authorized technical assistance centre). - Gruppo Piazzetta S.r.l. cannot be held liable for situations of This appliance is not for use by persons (in- risk, defects, damage, product malfunctioning or for damage... -
Page 4: Product Information
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE Installation may also include a series of operations to be carried out correctly by enabled personnel and for which system com- Do not stand or place objects which are not patibility must be guaranteed: heat-resistant within the prescribed minimum - connection to the air intake safety distance. -
Page 5: Part Identification
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE PART IDENTIFICATION 15 Pellet delivery hole Humidifier 16 Combustion chamber Door 17 Pellet hopper grille Ceramic glass 18 Pellet hopper cover Door handle 19 Appliance control panel Metal structure 20 Electrical power cable Hot air outlet Ash catcher 21 Smoke chamber Grate deflector... -
Page 6: Safety Devices
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE Electrical safety: SAFETY DEVICES the appliance is protected by fuses in the event of a power surge. The appliance is equipped with the following safety and check Firebox door opening sensor: devices which stop the stove from operating if any faults occur. if the firebox door is opened during operation, an acoustic alarm If any safety warnings or alarms are activated, please consult the signal is activated. -
Page 7: Product Identification Data
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE PRODUCT IDENTIFICATION DATA CHARACTERISTICS Each product is identified in the following way: Cladding: - IDENTIFICATION DATA PLATE (1) with the model (A) and ap- - majolica pliance performance specifications Structure: - SERIAL NUMBER PLATE (2) with the serial number of the ap- - in steel pliance (B) Firebox:... -
Page 8: Technical Data
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE TECHNICAL DATA Model LINE Product type SP131-01 Unit of meas- at nominal at reduced Description urement heat output heat output Fuel natural pure wood pellets Heat Output 9,19 3,50 Hourly fuel consumption kg/h 2,200 0,800... -
Page 9: Sizes
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE (values in cm) SIZES Line Fig. 5 74,5 8 cm 7.5 cm 6 cm A Smoke outlet Combustive air duct Ducting outlet standard position DT2002842_H072117UK0_01... -
Page 10: Fuel
Gruppo Piazzetta S.r.l.. compliance with the requirements of class A1 (EN 17225-2). Using pellets that are out of date or not in conformity ■... -
Page 11: General Information Regarding The System
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE GENERAL INFORMATION The existence of more than one appliance is only per- REGARDING THE SYSTEM mitted if allowed by the regulations and manufacturer of each individual appliance. Below is some general information regarding the system, appli- If the existence of more than one appliance is permit- ■... -
Page 12: Fresh Air Intake
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE In brief, remember that the chimney: FRESH AIR INTAKE - must be in compliance with regulations, equipped with CE marking and be made respecting all safety requirements In order to operate normally, each appliance must be provided - must be suitable for the specific operating conditions of the with the air needed for combustion. -
Page 13: Chimney Terminal
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE The connection for the combustion product outlet must comply with local regulations. In Italy and other European countries combustion ■ ■ products must be discharged through the roof and it is forbidden to discharge combustion products directly on the wall or towards closed spaces even if in the open air. - Page 14 PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE Additional requirements for the flue pipe To ensure correct product operation, where not specified under items " TECHNICAL DATA " and " CONNECTION TO THE SMOKE OUTLET ", the connection to the flue pipe must have the follow- ing characteristics: maximum length of the flue pipe (a)
-
Page 15: Preparation For Installing
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE PREPARATION FOR INSTALLING HANDLING In order to prevent any accidents or damage to the product, please follow the recommendations below. - Unpacking and installation must be carried out by at least two people - the product must always be moved and handled with suitable equipment in full compliance with current safety regulations - the packaged product must be kept in the position according to the directions shown by the diagrams and signs on the pack... -
Page 16: Installation Kit And Accessories
Fig. 13 DT2032225-4 air into a designated room. In this EXCLUSIVE system PATENTED by Gruppo Piazzetta S.r.l., heat produced by the firebox is distributed from bottom-up with- in the room by means of one or more than one fan. This solution has the significant advantage of even temperature distribution. - Page 17 PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE 6.3.2 Hot air outlet in other directions During installation, it is possible to divert and duct the hot air so The maximum total length indicated in the section that it is distributed in different parts of the same room or adjoin- "...
- Page 18 PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE Hot air outlet also ducted into a second room 6.3.4 Ducting indications For effective channelled heat distribution, you must: - coat the pipe with a 2 cm thick insulating sheath (e.g. mineral fibre, ceramic fibre, rock fibre) in order to limit heat loss and to ensure an adequately high air temperature - ensure the insulating sheath has a specific weight equal to or greater than 50 kg/m³...
-
Page 19: Combustion Air Connection
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE The appliance is equipped as standard with the smoke outlet (1). Where there is flammable flooring, the hot air outlet vents must be placed at a distance of at least 200 mm from the floor. Fig. -
Page 20: Electrical Connections
Power cable socket Additional requirements for the flue pipe Gruppo Piazzetta S.r.l. supplies pipes and bends for the flue pipe, Only the power supply connection can be carried out all of which are approved and specifically sized for the smoke out- by the user. -
Page 21: Start-Up And Operating Test
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE 6.6.3 External environment thermostat The appliance allows for connection to an external thermostat Find out the cost of these operations from the special- (not supplied as standard). This allows operation to be deter- ised technician. mined on the basis of the room temperature detected by the Refer to the manual "... -
Page 22: Cleaning And Maintenance
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE 400 ml After installation, cleaning and maintenance work: restore and replace all worn or damaged parts with ■ ■ original spare parts restore all initial connections together with the normal ■ ■ operating conditions of the appliance and the system carry out a start-up and operating test to check that ■... -
Page 23: Recommended Interval
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE The following interventions are included in maintenance: 10.3 CLEANING THE PAINTED METAL PARTS - checking the components for wear and ensuring they are inte- gral and operate correctly When cleaning the painted metal parts, use a soft cloth mois- - checking there is no dirt, dust, deposits or obstructions tened with water. -
Page 24: Disposal Of Ashes
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE Proceed as follows: - remove the grate deflector(1) The glass should be cleaned when cold using ammo- - release the grate (2) from its housing nia-based non-corrosive degreasing agents (for exam- - remove all ash and any deposits which may have formed, mak- ple, do not use solvents). -
Page 25: Cleaning The Smoke Chamber
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE - turn the cams (3) forwards in order to release the back panel (4) Proceed as follows: - lift the back panel slightly to release it from the slots(5) - remove the left panel following indications provided in the CLADDING instructions - remove the screws (1) which secure the smoke chamber cover - use a vacuum cleaner to remove any ash and carbon deposits... -
Page 26: Cleaning The Room Fan
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE Use a vacuum cleaner or compressed air cleaner for Recommended cleaning frequency: refer to the section this. " SCHEDULED MAINTENANCE ". Please refer to and carefully read the section " FLUE Recommended cleaning frequency: refer to the section ■... -
Page 27: When Not In Use
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE ELECTRONIC BOARD FUSE Unscrew the fuse box plug (1) located on the electronic board Excessive humidity and a long period of inactivity may and replace the fuse with a similar one. cause the formation of rust on some of the unpainted Type of fuse: F4AL250V parts inside the product. -
Page 28: Reference Standards
PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE 12 REFERENCE STANDARDS Country of application: The European Union EN 14785 Residential space heating appliances fired by wood pellets - Requirements and test methods EN 60335-1 Household and similar electrical appliances. Safety - Part 1: General requirements EN 60335-2-102 Household and similar electrical appliances. - Page 29 PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE DT2002842_H072117UK0_01...
- Page 30 PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE DT2002842_H072117UK0_01...
- Page 31 PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE DT2002842_H072117UK0_01...
- Page 32 Via Montello, 22 31011 Casella d’Asolo (TV) - ITALY Tel. +39.04235271 - Fax +39.042355178 www.piazzetta.it e-mail:infopiazzetta@piazzetta.it...
