Danfoss SystemStak DGM 5 Series Technical Information page 9

Installation Dimensions
DGMC-5-BT Single Relief
mm (inches)
4 (5/3 2")
Hex key
11,5
(0.45)
15,3
(0.60)
External drain port *
Plugged for internal drain.
* External connection port thread type:
"S" models - SAE-4 O-ring boss port
(0.4375-20 UNF-2B thread).
"B" models - G 1/8 (1/8 BSPF)
See page 37 for optional adjustment devices.
See page 38 for interface dimensions.
DGMC-5-AT Single Relief
50
(1.97)
13,5 (0.53)
ISO 4401-AC-05-4-A (NFP A D05) Mounting surface
Adjust pressure "A " port. Adjust clockwise to increase pressure setting.
T
B
External drain port *. Plugged for internal drain .
"W " models
(max. ext.)
30
(1.18)
11,5
(0.45)
12,5 (0.49 )
Remote control port. *
(" RC" models only )
11,7 (0.46)
33,2
71,6
(1.31)
(2.82)
max.
69,5
(2.74)
Adjust pressure "B" port. Adjust clockwise to increase pressure setting.
4 mounting holes
(See page 8 for specifications)
141 (5.55 )
50 (1.97 )
P
B A
T
A
48 (1.89 )
13 (1/2 ")
ISO 4401-AC-05-4-A (NFP A D05)
Wrench size
Mounting surfac e
T
B
• Back pressure in drain is added to this setting for
internal drain models only.
"W " models
48 (1.89 )
(max. ext. )
30
(1.18)
13 (1/2 ")
Wrench size
11,7 (0.46)
33, 2
(1.31)
(2.74)
15,3 (0.60 )
4 mounting holes
(See page 8 for
specifications)
141 (5.55)
37 (1.46 )
P
B A
T
A
4 (5/3 2") Hex key
11,5
(0.45)
12, 5
External drain port *
(0.49)
Remote control port *
("RC " models only )
71, 6
(2.82)
max.
69, 5
50
(1.97)
13,5 (0.53 )
11,5
(0.45)
9
