Danfoss SystemStak DGM 5 Series Technical Information page 10

Installation Dimensions
DGMC2-5-AT-**-BT-**-30
Dual Relief
mm (inches)
See page 37 for optional adjustment devices.
See page 38 for interface dimensions.
"W " models
(1.89)
(max. ext.)
typ. both ends
30 both
(1.18) ends
11,5
(0.45)
11,7
(0.46)
33, 2
71,6
(1.31)
(2.82)
max.
Adjust pressure "B" port. Adjust
clockwise to increase pressure setting.
* External connection port thread type:
"S" models - SAE-4 O-ring boss port
(0.4375-20 UNF-2B thread).
"B" models - G 1/8 (1/8 BSPF) 15 in model code
10
4 mounting holes
36,5 (1.44) deep
for bolt extender s
(order separately)
48
BKE-6M-50M (M6 metric) or
BKE-4-50M (.2500-20 UNC).
Torque: 1 1,3-14,7 Nm
both
ends
ISO 4401-AC-05-4-A (NF P A D05)
Mounting surface
50
(1.97)
T
B
15, 3 both
(0.60) ends
6,9 (0.27) through
9,50 (0.37) counterbore
(100-130 lb. in. )
13, 5
(0.53)
153,9 (6.06 )
P
B A
T
A
External drain port *
(both ends).
Plugged for internal drain.
Adjust pressure "A" port. Adjus t
clockwise to increase pressure
setting.
• Back pressure in drain is added to this
setting for internal drain models only.
4 (5/32 ")
Hex key
50
(1.97)
13 (1/ 2 ")
Wrench size both ends
* Remote control port. Both end s
(" RC" models only)
* Remote control port. Both end s
(" RC" models only)
12,5 (0.49)
both ends
33, 2
(1.31)
69,5
(2.74)
