Danfoss SystemStak DGM 5 Series Technical Information page 35

Knob Adjusters
DGMC
DGMC2 (dual type)
DGMR1
DGMX2
DGMC2
(crossport type)
DGMFN
Model C
DGMFN-5-X-P 68,9 (2.37)
DGMFN-5-Y-A 61,9 (2.44)
DGMR
H – Handknob
56,8 (2.24)
2 (5/6 4")
Hex key required
for adjustment
54,1 (2.13 )
2 (5/6 4")
Hex key required
for adjustment
"H" models
C
(max. ext.)
D
95 (3.74)
88 (3.46)
W – Screw with locknut
74,4 (2.93)
2 (5/64 ")
Hex key required
for adjustment
"H" models
"K" model s
(max. ext.)
Adjustment of valve setting is only possible while key is
inserted and turned to engage driving pin. When key is
removed, adjuster knob can be freely spun and does not
engage with setting mechanism.
"H" models
"K" models
(max. ext.)
Adjustment of valve setting is only possible while key is
inserted and turned to engage driving pin. When key is
removed, adjuster knob can be freely spun and does not
engage with setting mechanism.
"K" models
max. ext.
2 (5/6 4")
Hex key
required fo r
adjustment
Adjustment of valve setting is only possible while key is
inserted and turned to engage driving pin. When key is
removed, adjuster knob can be freely spun and does not
engage with setting mechanism.
65,6 (2.58 )
13 (1/2 ")
Wrench size
82,9 (3.26)
max. ext.
80,1 (3.15)
max. ext.
D
C – Cap over screw
4 (5/32 )
Hex key
Wrench size
45
(1.77)
For key
removal
45
(1.77)
For key
removal
45
(1.77)
For key
removal
68,5 (2.70 )
13 (1/2 ")
35
