Installation Dimensions - Danfoss SystemStak DGM 5 Series Technical Information

Installation Dimensions

DGMC-5-PT Single Relief
mm (inches)
See page 37 for optional adjustment devices.
See page 38 for interface dimensions.
4 mounting holes
6,90 (0.27) through
9,50 (0.37) counterbore
36,5 (1.44) deep for bolt extenders (order separately)
BKE-6M-50M (M6 metric) or BKE-4-50M (.2500-20 UNC).
Torque: 1 1,3-14,7 Nm
(100-130 lb. in.)
50
(1.97)
14 (0.55)
23
(0.91)
B
T
B
Gage port. External connection
port thread type: (see table )
External connection port threads
"S" models - SAE-4 O-ring boss port
(0.4375-20 UNF-2B thread).
"B" models - G 1/8 (1/8 BSPF)
8
13,5 (0.53 )
ISO 4401-AC-05-4-A (NFP A D05)
Mounting surface
144,1 (5.67) max .
50
(1.97)
P
A
T
A
External drain port. External
connection port thread (see table )
"W " models
48
(max. ext. )
(1.89)
25
(.98)
11,5
(0.45)
13 (1/2 ")
Wrench size
11,7
(0.46)
33, 2
71, 6
(1.31)
(2.82)
max.
69, 5
(2.74)
1,8
(0.46)
Adjust clockwise to increase pressure
setting.
Note: Back pressure in drain is added to this
setting for internal drain models only.
3rd angle
projection
Remote control port .
(" RC" models only )
External connection port
thread type (see table)
11,8
(0.46)
38
(1.5)
4 (5/32 ")
Hex key
External drain port.
Plugged for internal drain.
External connection port
thread type (see table)
