Danfoss SystemStak DGM 5 Series Technical Information page 28

Installation Dimensions
DGMFN-5-Y Dual Flow Control
mm (inches)
"W " models (max. ext.)
typ. both ends
4 (5/32 ") Hex key
Rotate clockwise to
decrease flow in
port "B "
50
(1.97)
13 (1/2 ")
Wrench size
both end s
69,5
(2.74)
See page 37 for optional adjustment devices.
See page 38 for interface dimensions.
DGMFN-5-X Dual Flow Control
mm (inches)
"W " models (max. ext. )
typ. both ends
4 (5/32 ") Hex key
Rotate clockwise to
decrease flow in
port "B "
50
(1.97)
20
(0.79)
13 (1/2 ")
Wrench size
both ends
69,5
(2.74)
28
52,7
(2.07)
30
(1.18)
33, 2
(1.31)
52,7
(2.07)
33, 2
(1.31)
4 mounting holes (See page 27
for specifications)
13, 5
(0.53)
128 (5.04 )
P
B A
T
T
A
B
4 mounting holes (See page 27
for specifications)
13, 5
(0.53)
128 (5.04)
P
B A
T
T
A
B
ISO 4401-AC-05-4-A (NFP A D05)
Mounting surface
Rotate clockwise to
decrease flow in
port "A"
11,7
37
(0.46)
(1.46)
ISO 4401-AC-05-4-A (NFP A D05)
Mounting surface
11,7
37
(0.46)
(1.46)
71, 6
(2.82)
max.
Rotate clockwise to
decrease flow in
port "A"
71, 6
(2.82)
max.
