- Page 1 D’ANGLE SERIES Assembly and operating manual Models: D’Angle XL...
-
Page 2: Kit Contents
Kit contents Part name Quantity Fig. D’Angle Bracket 1 pc. D’Angle horizontal beam 2 pc. Sabaj IR Remote 1 pc. IR-EYE receiver 1 pc. Drilling Template 1 pc. 24V AC adapter 1 pc. www.rtv.sabaj.pl... -
Page 3: Set Contents
Size 8 large - 2 pc. size 3; 5 Allen keys 1 set. Plastic spacers (12,5mm) 4 pcs. Plastic spacers (10mm) 4 pcs. Velcro tapeA 2 pcs. Required additional tools: Tool name Fig. Cross screwdriver Drill driver Drill (suitable for screws) helpdesk@sabaj.pl... - Page 4 Assembly and operating manual Assembly 1. Apply the template, drill holes in the ceiling and mount the screws (fig. 1). (fig. 1) www.rtv.sabaj.pl...
- Page 5 Fig.2 – Center of mass too far. Lifting heavier loads can be difficult or impossible. Hang D’Angle on the ceiling screws and tighten them. NOTE: You will notice more than four holes for wall installation. Additional holes are added only for a sturdier installation or for necessary placement changes. helpdesk@sabaj.pl...
- Page 6 It is crucial to firmly secure the beams to prevent the screen from falling. (fig. 4) Connecting the mount Connect the AC power adapter and IR receiver to corresponding sockets, like shown on pictures below. (fig. 5) www.rtv.sabaj.pl...
-
Page 7: Control Panel Description
Press RC-SET button (You will hear intermittent beeper signal) and press the Down button. You will see this symbol on the display. The down position has been set. Press & hold SETUP button for about 2 seconds until the red SETUP led is off. The controller is now in normal operation mode. helpdesk@sabaj.pl... - Page 8 The IR-Multicode system allows you to use any infrared remote control from most popular TV screen manufacturers using RC-5 Code. Every Sabaj controller can store 1 set of Infrared remote presets. This means that by programming new presets, you will delete the old ones. You can program the remote control with which you control your TV.
- Page 9 SABAJGROUP. The active RJ-45 socket enables you to use accessories for control through push-buttons, home automation systems, or smartphones. For more information, please visit the Sabaj website. NOTE: Only the original SABAJGROUP accessories will work with your control box. If you attempt to modify or connect any other devices via the RJ-45 port, you might damage the control box and you will lose the warranty for doing so.
- Page 10 Assembly and operating manual UP button memory approved ---------- DOWN button memory approved --------- www.rtv.sabaj.pl...
