Kondor Cabin Variation

Before you take your first trip, you should familiarize yourself well with the operation of the scooter
and with all operating elements. Take your time to test all functions and driving modes.
Interior Rearview Mirror
Windshield Wiper
Hand Brake
Headlight
Turn Signal
Front Bumper
Cabin Door
1. Turn the handle upwards (clockwise) to lock the door.
2. Turn the handle downwards (anticlockwise) to unlock the door.
3. Watch your head when getting into the scooter.
*Ensure your hands are away from any moving parts before activating or closing the door.
Cabin Side Window
1. Slide the window forwards to close it, backwards to open it.
2. Do not leave the windows open when the scooter is not in use.
*Rubber strips may be loose or offside after a period of usage,
you may need to adjust or replace the parts if the strip is not firmly
sealed. Please contact the dealer for assistance.
22" Captain Seat
Rear Mirror
Door Handle
Side Reflector
Rear Bumper
Figure 20
Lock
Open
Figure 21
