Abilize ranger Instruction Booklet page 19

HS-828
SETTING- USER DEFINE
1.Make sure the scooter (key) is off.
2.Press and hold both [
Keep holding the buttons until the LCD screen is on.
3.Press [ MODE ] button to select the
modes you want to set up.
Exit /Save the setting :
•Setup mode will automatically quit after 15secs without pressing any button. Scooter
will save the setting and return to operation mode.
Buzzer Volume setup (Figure 16) :
•Low battery warning sound is controlled by the controller.
Figure 16
Unit setup (Figure 17) :
Figure 17
LCD panel backlight (Figure 18) :
] [ ] then turn on the key.
Set up
last page
Figure 18
Instruction Booklet
MODE
Figure 15
Page
Item Description
1/5
Hazard Warning volume
2/5
Indicator warning volume
3/5 Reverse warning volume
4/5 Low battery warning volume
5/5 Horn volume
Item Description
1/4 Clock 24 , 12
2/4 Speed km/h , mph
3/4 Odo km , hrs
4/4 Temp C , F
o o
Save/Exit/
Next Setup
Increase
Decrease
next page
Initial value
3
3
3
off
5
Initial value
24
km/h
km
C
o
19
