6130(F) Series
Mortise Exit Device
Installation Instructions
Plastic Template
Prepare
mounting holes as follows:
1. Use plastic template provided and position on door and frame.
Align vertical and horizontal reference centerlines on door with
notches on template (see Figure 4b).
2. Tape template to door face. Mark door per template.
3. If trim is used, locate templates packed with trim. Position
templates and mark holes per trim instructions.
A
Horizontal
C L
B
Reference
A
1-855-557-5078 Ext. 2 • www.accentra-assaabloy.com
Copyright © 2015, 2023, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in
whole or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Figure 4b: Prepare Door and Frame with Templates
C L
Vertical Reference
Table 1: Door and Frame Preparation
Hole Door/Frame
Metal
Reinforced
A
All Others
B All
4. Drill and tap only those holes needed for the device being
installed (see Table 1).
5. Ensure that the latch assembly lever hole is predrilled to
accommodate latch lever.
6. Check by inserting lock into door, adjust front for door edge
(beveled or flat, see "D. Check Mortise Lock Handing" on page 5).
Inside Door Surface
6130(F)
Fastener
Drill: #7(Ø 0.201")
1/4-20 PPHMS
1/4-20 SNB Drill: Ø 3/8" thru
— OB 1/2" x 1-9/16"
7
Vertical Reference Notch
6130(F)
Vertical Reference Notch
Preparation
Tap: 1/4-20
Against Door Surface
Plastic Template
Horizontal
Reference
Notch
Latch Assembly
Lever Hole
