Assa Abloy ACCENTRA 540F Series Installation Instructions Manual

540F & 580F
Exit Device Trim
Installation Instructions
For use with ASSA ABLOY ACCENTRA™
Series Exit Devices (Wood and Metal Doors)
LEVER TYPE
Key In Lever
Plain
Lever
*Field Prep: Cut tailpiece off, not to engage the device.
ABBREVIATION
PPHMS
PTHMS
WARNING
This product can expose you to lead which is known to the state of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65warnings.ca.gov.
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the
opening, and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific
situation. When retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated opening,
please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all
applicable codes and ratings.
1-855-557-5078 Ext. 2 • www.accentra-assaabloy.com
Copyright © 2019, 2023, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction
in whole or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
541F, 546F, 548F,
& 549F Series Trim
Non-Handed
Sectional Lever Trim
TRIM FUNCTION
541F/581F
546F/586F
548F/588F
549F/589F
PHILLIPS PAN HEAD MACHINE SCREW
PHILLIPS TRUSS HEAD MACHINE SCREW
DESCRIPTION
F03 (NL) Key retract bolt(s)
F08 Key locks/unlocks lever
Passage Lever retracts bolt(s)
F02 Dummy trim*
F02 Dummy trim
FASTENER DESCRIPTION
581F, 586F, 588F,
& 589F Series Trim
Non-Handed
REMARKS
Free wheeling lever
Free wheeling lever
Lever always active
Free wheeling lever
Rigid lever
80-8470-0541-000 04/24
