6130(F) Series
Mortise Exit Device
Installation Instructions
A. Verify Parts and Templates
1. Unpack and verify components received using the parts list and exploded view.
2. Read entire instructions before installing this device.
Important:
y Verify device is being installed on the correct door, as well as function, finish, and size.
y Use site survey to verify correct product ordered.
y This device is intended to be installed on new 24" (610mm) to 48" (1220mm) metal or wood, pre-drilled, free swinging doors only.
3. Follow all cautions, notes and warnings presented in these instructions.
4. All dimensions listed are in inches (") and millimeters (mm).

Tools Required

1/8"
Phillips Hex
Level Head Key
1-855-557-5078 Ext. 2 • www.accentra-assaabloy.com
Copyright © 2015, 2023, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in
whole or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Plastic Template
Tape
Measure Pencil Chisel
Plastic and Paper
Templates are included
Paper Templates
Drill and Bits
Safety Glasses
3
Tape Set Tool Flashlight
Rubber
Mallet
80-9460-6004-000 04/24
