7666-4015-01
Di200f/Di251f/Di351f Network Application
Network Connection and Setup
Quick Guide
(Read This Manual First)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Di200f and is the answer not in the manual?

Questions and answers

Related Manuals for Minolta Di200f

Summary of Contents for Minolta Di200f

  • Page 1 Return to SubMenu 7666-4015-01 Di200f/Di251f/Di351f Network Application Network Connection and Setup Quick Guide (Read This Manual First)

  • Page 2: Table Of Contents

    Network Application Network Connection and Setup Quick Guide (Read This Manual First) Flow of Operations Before Connection and Setup ........1 This chapter describes what you need to know beforehand such as cautions. Characteristics of the Network Functions..... 4 This chapter describes the network application functions and their operations. Setting up the Network ..........
  • Page 4 Trademarks Microsoft ® and its logo, Windows ® , Windows NT ® , and MS-DOS ® are the registered trademarks of Microsoft Corporation in the United States and other countries. Ethernet ® is the registered trademark of Xerox Corporation. Adobe and Acrobat are the trademarks of Adobe Systems Incorporated.

  • Page 6: Before Connection And Setup

    6. Notwithstanding the provisions stipulated in articles 4 and 5 above, Minolta shall not be liable for any damages resulting from the operation of this product.

  • Page 7: Fcc Part 15-Radio Frequency Devices

    FCC Part 15-Radio Frequency Devices This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interface, and (2) this device must accept any interface received, including an interface that may cause undesired operation. WARNING This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 8 (4) Content of the utility disk Scanner Files related to IP Scanner. Electronic manual for the network application functions. Manual To browse this, Acrobat Reader is required. Acroread Application to browse electronic manuals. Contains setup.exe for setup. Root Start this file for setup. (5) Electronic manual The manual for the network application functions is stored in the [Manual] folder on the CD- ROM as an electronic manual (in PDF format).

  • Page 9: Characteristics Of The Network Functions

    Characteristics of the Network Functions One-Touch Document E-mail (Internet Facsimile Function) The image data that has been read is attached to the e-mail and transmitted to a PC or Internet Facsimile terminal via the Internet or intranet. You only need to specify an e-mail address similar to the case where you specify a telephone (fax) number when sending a document by facsimile.
  • Page 10 E-mail RX-FAX Distribution E-mail RX-FAX Distribution Image data received from a facsimile unit through a general subscriber line is attached to an e-mail and transferred to a PC. The facsimile document can be received as an e-mail from your PC. Register the unit accounts in advance, and set F CODE and corresponding E-mail addresses to which documents are to be transferred.
  • Page 11 One-Touch Network File TX (One-Touch Filing Function) One-Touch Network File TX (One-Touch Filing Function) Transmit the image data of the read document to your PC and save it in the predetermined folder. You can simply press the One-Touch key to save the paper document as an electronic file even in an environment without a mail server.
  • Page 12 Network File Scanner (IP Scanner) Network File Scanner (IP Scanner) Transmit the image data of the read document to your PC, create the folder of the scanner key name, and save it. When you perform scanning, you can register a key (destination of the scanned image and scan settings) from the PC and press the key displayed on the product to easily save the paper document as an electronic file.
  • Page 13 MFP Agent MFP Agent You can check the mail transmission/print status and alarm status such as loaded paper of the main unit, from your PC using a browser. The MFP Agent screen consists of the operation screen for general accounts and operation screen for administrators.

  • Page 14: Setting Up The Network

    Setting up the Network Restrictions for the Network functions due to the network environment The available network functions are restricted based on the LAN environment to which this product is connected. Setup the network according to the environment and functions you want to use. Function Name E-mail Server Environment IP Address...
  • Page 15 Restrictions for the Network functions due to the network environment LAN environment with a mail server User PC NOTE NOTE • Set the IP address of this product to static. • Enter the IP address correctly. The product does not operate properly if you enter the IP address of the example.
  • Page 16 Restrictions for the Network functions due to the network environment LAN environment without a mail server User PC NOTE NOTE • Set the IP address of this product to static. • Enter the IP address correctly. The product does not operate properly if you enter the IP address of the example.
  • Page 17 Displaying the Network Setup Screen Displaying the Network Setting Screen Press <Utility> on the Operation panel. Touch [Admin. Management]. (You may need to enter the Administrator Code.) Utility Exit Meter Copy Input Count Job Recall User Admin. Report Management Management On Line Test Print Memory...
  • Page 18 Displaying the Network Setup Screen Setup [Set1] through [Set6] and touch [Enter]. Network Cancel Enter Setting Set 3 Set 4 Set 5 Set 6 Set 1 Set 2 Input IP Address to setup network IP Address 192.168.100.200 255.255.255.0 Sub-net Mask 192.168.100.30 Gateway it.xyz.com...
  • Page 19 List of Network Setting Items List of Network Setting Items [Set 1] Menu [Set 4] Menu Network Network Cancel Enter Cancel Enter Setting Setting Set 3 Set 4 Set 5 Set 6 Set 1 Set 2 Set 1 Set 2 Set 3 Set 4 Set 5...
  • Page 20 List of Network Setting Items Setting Item Action Needed IP Address Specify the IP address of this product. Sub-net Mask Specify as required (required for server connection via router). Gateway Specify as required (required for server connection via router). Self-domain Name Specify the domain name of this product.
  • Page 21 List of Network Settings by Function List of Network Settings by Function The following table indicates the network setting items for each function. For information on how to setup, refer to Chapter 2 "Network Configuration" of the Network Application Operator’s Manual (electronic manual). For information on each function, refer to "Characteristics of the Network Functions"...
  • Page 22 List of Network Settings by Function : Required : Enabled : Required for Some Environments : Disabled for the Item Function Network File Scanner MFP Agent Setting from MFP Agent (IP Scanner) Setting Item Set1 IP Address Sub-net Mask Gateway Self-domain Name Set2 DNS Setting...
  • Page 23 Setting up the mail server, etc. Setting up the mail server, etc. To use the network application functions of this product, you must configure the settings according to the network environment to which the product is connected. Before you start setup of the product, ask the network administrator to set up the items required for the product.
  • Page 24 Setting up the mail server, etc. Setting a sub-net mask A sub-net mask consists of a network part and a sub-net part. In setting a sub-net mask, use the value shown in the table below for the network part of the sub-net mask, depending on the IP address.

  • Page 25: Connecting To The Lan

    Connecting to the LAN This product communicates using TCP/IP protocols via the LAN. Therefore, connection with a LAN using a LAN cable is necessary. To connect with a LAN, use a LAN cable (Fast Ethernet 100BASE-TX cable). Connecting a LAN cable Connect one end of a LAN cable to the inlet port (NETWORK) on the back panel of the product and the other end to a hub.
  • Page 26 Connecting a LAN cable To use the unit with the NIC board (optional) of the printer Different IP addresses are required for the NIC board and the network application functions. The NIC board is installed in the right side of the back of the product. For more information on the NIC board, refer to the manual attached to the NIC board.

  • Page 27: Installing Utilities

    Installing Utilities To use the network application functions, you need to install the utilities on the PC according to your computer environment (OS). Before operation This section describes how to install IP Scanner. Utility Disk The Utility Disk provided with this product contains IP Scanner for Windows Me, Windows 98/95, Windows 2000, and Windows NT 4.0.
  • Page 28 Installing IP Scanner (Windows Me, 98/95, 2000, and NT 4.0) Installing IP Scanner To use the scanner function (IP Scanner), install IP Scanner to your PC according to your computer environment (OS). Do not install IP Scanner to a computer used as a mail server or a computer where a NOTE NOTE mail server is installed.

  • Page 29: Installation Starts

    Installing IP Scanner (Windows Me, 98/95, 2000, and NT 4.0) Check the display and click [Next >]. Check the folder in which IP Scanner is installed, and click [Next >]. To change the installation folder, click ADD. ADD. [Browse] and select the folder to install IP Scanner.
  • Page 30 Installing IP Scanner (Windows Me, 98/95, 2000, and NT 4.0) Click [Finish]. ADD. ADD. A screen may prompt you to reboot the system. When you do so, the installation is complete. In the [DiALTA] Installer screen, click [Close]. Reboot your PC. ADD.
  • Page 31 Uninstalling IP Scanner (Windows Me, 98/95, 2000, and NT 4.0) Uninstalling IP Scanner (Windows Me, 98/95, 2000, and NT 4.0) Select [Start], [Settings], and then [Control Panel] to open the Control Panel. Open [Add/Remove Programs]. For Windows Me, 98/95, and NT 4.0, select [IP Scanner] and click [Add/Remove].

  • Page 32: Checking Operations

    Checking Operations To check that the LAN connection and network settings are properly set up, check the operations. If it does not operate successfully, check the LAN cable connection and network settings again. Refer to Chapter 10 Troubleshooting of Network Application Operator’s Manual (electronic manual).

  • Page 33: Related Manuals

    Related Manuals This chapter lists the attached manuals of this product. Utility Disk Network Application Operator’s Manual (Network.pdf) This manual describes how to operate and setup the network application functions. It is stored in the Manual folder on the CD-ROM as an electronic manual (in PDF format).
  • Page 34 Attached to the product Di200f/Di251f/Di351f Operator’s Manual This manual describes cautions for safe use of this product, how to operate the copy/fax functions, how to load paper, how to handle paper jams, and daily maintenance.
  • Page 35 ND-22734(E) Any contents here in may not be reproduced or modified without permission of Minolta. March 2001 ISSUE 1 The contents may be subject to change without prior notice. © Minolta Co., Ltd. 2001...
