Innova L00773 Quick Start Manual

EN
 L 00773-BUILT-INFORMWORKKITFORRIGHTHANDSIDEAIR
Warnings
This instruction is an integral part of the booklet of the

appliance on which the kit is installed. Please consult
this booklet for general warnings and fundamental
safety rules.
For a rapid and right assembly of the components fol-

low carefully the sequences described in the various
sections.
Installation kit for built-in box for lateral air ventilation DX
L00773 - Built-in formwork for corner installation with
right-hand exit
Use this kit to divert air laterally to a perimeter wall when
you intend to place the air conditioner on an interior wall.
Installation arrangement
Preliminary warnings
ensure that:

• the wall supports the weight of the appliance
• the section of floor or wall does not contain piping or
electrical lines
Preparation of the wall
To install the unit, prepare the wall for housing the metal
casing.
Width
Height
Depth
OUTLET
1008 mm
506 mm
165 mm
N420071B - Rev.00 - 09/2024
All the operations must be performed by qualified per-

sonnel using the required Personal Protective equip-
ment.
It is necessary, for right functioning of the device, that

during the whole installation phase the working space
remains clean.
Regularly clear away waste offcuts, debris or dirt.

The kit consist of:
• a formwork for the side air outlet
• cable electrical connections
This kit is compatible with the only DC Inverter versions.

• the functionality of load-bearing elements is not com-
promised
• the supporting surface is perfectly levelled
• there are no obstructions nearby that could compro-
mise the inlet and outlet airflow
• air flow is not directed towards by-standers
1
