- Page 1 Installation and Commissioning Manual DH Network Camera (4MP WizMind Dual-Lens Network Camera) ( HDW8441XP-3D) Installation and Configuration Instruction Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0...
-
Page 2: Foreword
Foreword This manual introduces the installation and commissioning of 4-MP WizMind Dual-Lens Network Camera (hereinafter referred to as "the camera”), to effectively use the people counting function. Some parameters and functions are not described in details. For details, see the user's manual and other supporting documents. - Page 3 the electronic version and the paper version. All designs and software are subject to change without prior written notice. Product updates might result in some differences appearing between the actual product and the manual. Please contact customer service for the latest program and supplementary documentation. There might be errors in the print or deviations in the description of the functions, operations and ...
-
Page 4: Table Of Contents
Installation and Commissioning Manual Table of Contents Foreword ............................II 1 Overview ............................1 Introduction ............................1 Model Selection ............................1 2 Site Survey and Installation ......................3 People Counting ............................. 3 2.1.1 Site Requirements ........................3 2.1.2 Scenario ............................3 2.1.3 Installation Method ........................ -
Page 5: Overview
The following table is for reference only. For latest product models, see market promotion materials. Table 1-1 Select models External Internal Model Appearance Name Feature Model DH-IPC- DH-IPC-HDW8441XP-3D- With adaptive height Dahua 4-MP HDW8441X-3D 0200B function, the camera can WizMind Dual- be adapted to the Lens Network... - Page 6 External Internal Model Appearance Name Feature Model Lens Network Easily switches AI Camera resources among people counting, IVS, and face detection. With the built-in GPU IPC- chip, the camera supports IPC-HDW8441XP- HDW8441X deep learning algorithms. 3D-0280B Adopts high-performance starlight 4-MP 1/3-inch CMOS image sensor to ensure high image definition in low...
-
Page 7: Site Survey And Installation
Site Survey and Installation People Counting This section introduces people counting of HDW8441 series. 2.1.1 Site Requirements The following requirements must be met before using AI functions. Table 2-1 Site requirements Type Requirements Remarks The lighting on the site must ensure that the people in the image are clearly visible, and the heads and shoulders are... - Page 8 People counting (tripwire) in ceiling mount scenarios From left to right: An indoor passage, an entrance and exit, and a security screening passage. People counting (tripwire) in inclined mount scenarios From left to right: An indoor passage, and an entrance and exit. Area people counting in ceiling mount scenarios From left to right: A bank self-service area, and a duty area.
-
Page 9: Installation Method
2.1.2.2 Non-Recommended Scenarios Too high installation (overlooking from high altitude) 2.1.3 Installation Method The camera only supports ceiling mount, but you can adjust the lens angle to make it inclined. Ceiling mount 2.1.4 Installation Height You can adjust the installation height according to the actual scenarios. We recommend you install the camera at a height of 2.5 m to 5 m above the ground. -
Page 10: Arming Data
2.1.6 Arming Data When adopting ceiling mount (90°), the arming area is a rectangle. When adopting inclined mount (30° to 80°), the arming area is a trapezoid. In inclined mount, the minimum arming length requires that the feet are in the image, and the ... - Page 11 Inclined mount (side view) When using people counting rules, position 2 is the minimum length point (the feet are in the image). When the pixels of entire monitoring image meet the algorithm requirements, the maximum length point is position 4. Otherwise, the maximum length point is position 3 where the pixels of the head and shoulders meet the algorithm requirements.
-
Page 12: Face Detection/Ivs
Min. Min. Max. Max. Focal Installation Installation Arming Arming Arming Arming Model Length Angle (°) Height (m) Length Width Length Width (mm) 0.56 2.41 5.61 0.89 3.48 5.82 30° 1.25 4.44 6.04 1.61 6.06 1.93 6.52 5.83 HDW8441X P-3D-0200B -0.06 2.55 2.17 5.66... -
Page 13: Commissioning And Configuration
Commissioning and Configuration Preparation Before the commissioning and configuration, ensure that the following operations have been completed. For details, see the user’s manual. Make sure the camera is connected to the power supply and starts normally. Make sure the camera is initialized and the basic configuration is completed. ... - Page 14 Configure a smart plan. Enable People Counting, and then select Next. Enable people counting Click People Counting tab. Click Add Rule, and then select People Counting rule. The added rules will be displayed in the list. Click the text box under Name to edit the ...
- Page 15 Configure people counting (tripwire) Configure people counting (tripwire) parameters. Table 3-1 Description of people counting (tripwire) parameters Rule Parameter Description Counts the number of people entering in the Enter No. direction A-->B. When the number exceeds the configured value, an alarm is triggered. Counts the number of people entering in the Exit No.
- Page 16 The global configuration of IVS is completed. For details, see “3.2.1.4 Global Configuration”. Procedures On the homepage, select AI > AI Config > Smart Plan. Configure a smart plan. Enable People Counting, and then select Next. Enable people counting Click People Counting tab. Click Add Rule, and then select Area People Counting rule.
- Page 17 Configure area people counting Configure parameters of area people counting. Table 3-2 Parameter description of area people counting Rule Parameter Description Area People Counting Enable the area people counting function. Inside No Configure the number of people in the people counting region.
- Page 18 Prerequisite The global configuration of IVS is completed. For details, see "3.2.1.4 Global Configuration". Procedures On the homepage, select AI > AI Config > Smart Plan. Configure a smart plan. Enable People Counting, and then select Next. Enable people counting Click the Queuing tab.
- Page 19 Queuing Configure queuing parameters. Table 3-3 Description of queuing parameters Parameter Description Queue People No. Alarm Enable the queue people No. alarm function. Queue People No. Configure the number of people queuing in the detection region. When the people count reaches the configured value, an alarm is triggered.
- Page 20 Click the Global Config tab. Configure calibration. Automatic calibration: click Calibration Ground, set the calibration area, click OK, and then the value calculated by the algorithm will be automatically entered in the corresponding columns. Calibration ground: In the automatic calibration mode, the default calibration box is in ...
- Page 21 Procedures On the homepage, select Report > Report > People Counting. Configure a smart plan Configure search conditions. Configure search conditions for people counting (tripwire) Configure search conditions for area people counting Configure search conditions for queuing Table 3-4 Configure search conditions Parameter Description Select the rule as needed, and then you need to select the statistics type...
- Page 22 Parameter Description When selecting rule as Area People Counting, and statistics type as People No., you need to configure this parameter. Queue Time The report displays the number of people whose stay time is shorter than Queuing Time and is equal or longer than Queuing Time. Set the period for the report.
- Page 23 Area people counting (stay time) Queuing Related Operations Select the report form Click to display the report in line chart; click to display the report in bar chart. Select the statistics type on the upper-right corner The statistics result of unselected types will not be displayed. Export reports ...
-
Page 24: Faq
No Alarm is Triggered When Detecting an Alarm Event Problem After drawing the rules, the camera does not perform detection when a person enters or exits the detection area. Possible Reasons The function is not enabled. The controls are not working properly. ... - Page 25 Possible Reasons Manual operation (in most cases). Device errors. Solutions Make sure that the program is the latest baseline version. Check the stored videos, find the expiration period, and then export the logs. Find the configuration logs saved in the corresponding period and record the corresponding IP address.
