- Page 1 Eyeball Network Camera Quick Start Guide ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.1...
-
Page 2: Foreword
Quick Start Guide Foreword General This manual introduces the installation, functions and operations of network camera. Read carefully before using the device, and keep the manual safe for future reference. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided,... - Page 3 Quick Start Guide errors in the print. If there is any doubt or dispute, we reserve the right of final explanation. ● Upgrade the reader software or try other mainstream reader software if the manual (in PDF format) cannot be opened. ●...
-
Page 4: Important Safeguards And Warnings
Quick Start Guide Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, comply with the guidelines when using it. Transportation Requirements ●... - Page 5 Quick Start Guide against lightning. For outdoor scenarios, strictly comply with the lightning protection regulations. ● Ground the function earthing portion of the device to improve its reliability (certain models are not equipped with earthing holes). The device is a class I electrical appliance. Make sure that the power supply of the device is connected to a power socket with protective earthing.
- Page 6 Quick Start Guide ● Use the accessories suggested by the manufacturer. Installation and maintenance must be performed by qualified professionals. ● Do not directly touch the photosensitive CMOS. Use an air blower to clean the dust or dirt on the lens.
-
Page 7: Table Of Contents
Quick Start Guide Table of Contents Foreword ........................................I Important Safeguards and Warnings ............................III 1 Introduction ......................................1 1.1 Appearance ....................................1 1.2 Cable ........................................ 1 1.3 Connecting Alarm Input/Output ............................2 2 Network Configuration ..................................4 2.1 Initializing the Camera ................................4 2.2 Changing the Device IP Address ............................ -
Page 8: Introduction
Quick Start Guide 1 Introduction 1.1 Appearance This manual is available for the following appearances. Figure 1-1 Available appearances 1.2 Cable Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see FAQ manual. Figure 1-2 Cables Table 1-1 Cable information Port name... -
Page 9: Connecting Alarm Input/Output
Quick Start Guide Port name Description Connects to sound pickups to receive audio signals. Audio input Audio input is available on select models. Connects to speaker to output audio signals. Audio output Audio output is available on select models. Table 1-2 Description of Alarm I/O port Port Name Description ALARM_IN... - Page 10 Quick Start Guide maximum external pull-up level is 12 V, maximum port current is 300 mA, and the default output signal is high-level (external pull-up voltage). The default output signal switches to low- level when an alarm is triggered (As long as the operating current is below 300 mA, the output low-level voltage is lower than 0.8 V).
-
Page 11: Network Configuration
Quick Start Guide 2 Network Configuration Device initialization and IP setting can be finished with the ConfigTool or on webpage. For more information, see web operation manual. ● Device initialization is available on select models, and it is required at first-time use and after device is reset. -
Page 12: Changing The Device Ip Address
Quick Start Guide Step 3 Select Auto-check for updates as needed, and then click OK to initialize the device. If initialization failed, click to see more information. Click Finish. Step 4 2.2 Changing the Device IP Address ● You can change the IP address of one or more devices at a time. This section is based on changing IP addresses in batches. -
Page 13: Installation
Quick Start Guide 3 Installation 3.1 Packing List ● The tool required for the installation such as electric drill is not provided in the package. ● The operation manual and related tool information are contained in the disk or the QR code. Figure 3-1 Packing list 3.2 Dimensions Figure 3-2 Dimensions: Model A (mm [inch]) -
Page 14: Installing The Camera
Quick Start Guide Figure 3-3 Dimensions: Model B (mm [inch]) 3.3 Installing the Camera 3.3.1 Installation Methods Figure 3-4 Installation methods 3.3.2 (Optional) Installing the SD Card ● SD card slot is available on select models. ● Disconnect the power before installing or removing the SD card. Press and hold the reset button for 10 seconds to reset the device. -
Page 15: Attaching The Camera
Quick Start Guide Figure 3-5 Install the SD card 3.3.3 Attaching the Camera Make sure that the mounting surface is strong enough to hold at least three times the weight of the device and bracket. Figure 3-6 Cable going through the side cable tray... -
Page 16: Optional) Installing Waterproof Connector
Quick Start Guide Figure 3-7 Cable going through the mounting surface 3.3.4 (Optional) Installing Waterproof Connector This part is needed only when there is waterproof connector in the package and the device is used outdoors. Figure 3-8 Install waterproof connector... -
