Kiwi Camping KC072-391 Pitching Instructions

Bellbird Tent
Model No. KC072-391
PITCHING INSTRUCTIONS
Your tent includes:
1 x STEEL centre pole (2500mm x 25mm)
2 x STEEL door poles (1950mm x 19mm)
1 x A bend
2 x end caps
26 x pegs
13 x ropes
1. Select a dry, level site and clear the ground of any sharp objects.
Remove the tent from its carry bay, untie fabric ties and unroll the
tent in your selected location.
2. Spread out the floor of the tent and peg out all points ensuring that
the tent is pulled taut. Unzip and open the door to make erecting
the tent easier.
To make sure the tent
stays in place, insert the
pegs into the ground at
a 45° angle.
3. Assemble the main/centre pole by interlocking the sections
together, ensuring that each end of the pole has an end cap.
Thread the pole through the main door. Place the top end cap
into the reinforced centre of the tent roof. Slowly walk the pole
into the centre of the tent while pushing up on the pole.
Stop when the pole is fully vertical and lever in to the centre of
the tent.
4. Inside the tent assemble the remaining poles into an A frame
for easier installation. Insert the top pin on the A frame and
bend through the eyelet at the top of the door opening.
Secure the A frame
leg ends into the
pockets on the tent
floor on either side of
the entrance.
5. Peg out all the guy ropes and ensure they are taut.
REVERSE THE PROCEDURE TO LOWER THE TENT
PACKING INSTRUCTIONS
Pack the poles and pegs into their bags. Evenly layout the fly
leaving the door open. Fold the tent floor from each end to the
centre. Fold again to the width of the tent bag. Place the tent pole
and peg bags at the end of your folded tent. Roll from back to
front, forcing all of the air out the front door. Roll into the tent bag
provided.
