SAFETY INSTRUCTIONS
• Regularly check nuts and bolts attaching the Rooftop Tent to your vehicle to make sure
fastenings are tight and in good condition.
• Remove the Rooftop Tent before using a commercial car wash.
• Do not use Rooftop Tent or storage bag to hoist, lift or support yourself.
• It is important when mounting to a vehicle, that all the mounting brackets supplied are
adequately spaced to support the weight of the Rooftop Tent.
• Products applied to a vehicle roof will alter vehicle handling. The manufacturer disclaims
all responsibility in relation to accidents due to improper use, incorrect maintenance, or
negligence in maintaining fastening hardware. It is recommended to not exceed 100km/h.
• This Rooftop Tent will increase the height of your vehicle. Measure the overall height and be
aware of height restrictions in car park buildings etc.
• If pitching in windy conditions it is advised to find a less exposed location. Park with the back
of the tent facing into the wind. Be aware of dropping branches and other potential hazards.
Collapse the tent in strong winds.
• Never drive with roof tent erected.
• Do not put anything on the top of the tent when it is installed.
• The load-bearing of the frame is no more than 300kg.
Filename: 5523_KC077-056 Tuatara Plateau Rooftop Tent Instructions
Dimensions: A5 Booklet
Colour: Black
TUATARA PLATEAU
ROOFTOP TENT
Model No. KC077-056
Advertisement
Table of Contents
Related Manuals for Kiwi Camping KC077-056
Summary of Contents for Kiwi Camping KC077-056
- Page 1 TUATARA PLATEAU ROOFTOP TENT Model No. KC077-056 SAFETY INSTRUCTIONS • Regularly check nuts and bolts attaching the Rooftop Tent to your vehicle to make sure fastenings are tight and in good condition. • Remove the Rooftop Tent before using a commercial car wash.
- Page 2 PARTS INCLUDED YOUR TUATARA PLATEAU ROOFTOP TENT INCLUDES: 1 x pre-assembled Rooftop Tent with ladder attached 4 x spacers 2 x storage bags 8 x M8 x 60 bolt sets (hexagon head bolt, nut and washer) 8 x M8 x 40 bolt sets (hexagon head bolt, nut and washer) 4 x mounting brackets 8 x slide plates 8 x M8 self-locking nuts...
- Page 3 ROOFTOP TENT INSTALLATION The Tuatara Plateau can be fitted to smaller vehicles as long as the fitted roof rack or crossbars support a dynamic weight load of 75kg or higher. We recommend using only permanent roof racks and crossbars. The distance between the car roof and the bottom of the roof rack should be no less than 3cm.
- Page 4 PITCHING INSTRUCTIONS Before opening your Tuatara Plateau Rooftop Tent, ensure that all eight bolts are fastened tight so that the tent does not move when opening. Unlock the three latches on the side of the hardshell. Holding down the button on the side of the latch, pull the latch forward and unhook the strap from under the body of the tent.
- Page 5 Locate the two pole mounts on the front side of the frame. Insert the two spring poles through the canvas slits and into the holes. Angle the poles toward the inside edge of the pole mounts. Insert the top of the poles into the eyelets at the top corners of the porch.
- Page 6 PACKING INSTRUCTIONS Ensure the Rooftop Tent is dry and clean inside and out before packing down so that mildew or mould does not build up. Make sure nothing heavy or bulky is left inside the Rooftop Tent before folding. If leaving a small amount of bedding in the Rooftop Tent, store it at the top.
- Page 7 CARE INSTRUCTIONS PLEASE READ ALL OF THE CARE INFORMATION AND INSTRUCTIONS INCLUDED WITH THIS ROOFTOP TENT BEFORE USING IT FOR THE FIRST TIME. THE BODY OF THE TUATARA PLATEAU IS RIPSTOP POLYESTER CANVAS AND THE FLY IS RIPSTOP POLYESTER. Never store your Rooftop Tent away damp. Should mildew spots appear, brush them off before they become attached.
- Page 8 17. Do not leave children unattended in or around this Rooftop Tent. WARRANTY INFORMATION The warranty period for this awning is found on the packaging and full details are on the Kiwi Camping website - www.kiwicamping.co.nz. The original purchaser of this product is offered a warranty if during this time period the product fails due to a fault in either materials or workmanship. Service under this warranty is available by returning the product, with your proof of purchase, to where it was purchased.
