- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Fusion Universal CPU Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCA112...
-
Page 2: Important Safety Instructions
Exceeding the weight capacity can result in WARNING: serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components located on the FCA112 does not exceed 15 lbs (6.8 kg). - Page 3 Installation Instructions FCA112 DIMENSIONS A DJUSTA BLE DEPTH BRA C KETS M A X DEPTH 1.63" [41.4] (M A X DEPTH 2.00" [50.8] IF USED W ITH TILT M O UNT A ND DISPLA Y IS TILTED) 51.3 2.02 38.1 1.50...
-
Page 4: Tools Required For Installation
FCA112 Installation Instructions LEGEND By Hand Phillips Screwdriver A mano Destornillador Phillips Von Hand Kreuzschlitzschraubendreher Com a mão Chave de fendas Phillips A mano Cacciavite a stella Met de hand Kruiskopschroevendraaier À la main Tournevis à pointe cruciforme TOOLS REQUIRED FOR INSTALLATION... - Page 5 Installation Instructions FCA112 INSTALLATION The FCA112 may be used to support a surge adapter NOTE: or other components that don’t exceed the weight capacity of the FCA112. Put hook and loop squares (C) together so there are 4 squares of hook and loop.
- Page 6 FCA112 Installation Instructions Tighten the Phillips pan machine screws to complete installation of the FCA112 bracket. (See Figure 4) Figure 4...
- Page 7 Installation Instructions FCA112...
- Page 8 A Franklinstraat 14, 6003 DK Weert, Netherlands Europe P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies Asia Pacific 18-24 Shan Mei Street...
