I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Fusion CPU Extender Accessory
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
FCA103
Advertisement
Related Manuals for CHIEF FCA103
Summary of Contents for CHIEF FCA103
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Fusion CPU Extender Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCA103...
-
Page 2: Installation Instructions
Fusion mount being attached. The maximum weight that can be installed onto the FCA103 shelf is 30 lbs (13.6 kg). CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the corresponding instructions. - Page 3 Installation Instructions FCA103 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 4: Tools Required For Installation
FCA103 Installation Instructions TOOLS REQUIRED FOR INSTALLATION concrete only 7/32" (5.5mm) Wood Stud 5/16" (7.9mm) Concrete PARTS C (1) [shelf bracket] A (1) [left wall bracket] B (1) [right wall bracket] D (4) E (1) H (1) G (4) F (1) 5/16-18 x 5/8"... - Page 5 FCA103 shelf is 30 lbs (13.6 kg). any other plumbing before cutting, drilling, or installing fasteners. The FCA103 can be installed to either wood studs or a concrete wall. The minimum distance between fasteners must be 16" Drill one 7/32" (5.5mm) pilot hole in each stud.
- Page 6 INSTALLING THE FCA103 INTO UNDERRATED OR DAMAGED CONCRETE CAN LEAD TO SERIOUS INJURY OR DAMAGE TO PRODUCT! When installing into concrete, only install the FCA103 into concrete (B)* 7 11 at least 8" in depth or into 8"x8"x16" concrete blocks! Never install the FCA103 into cracked, chipped or flaking concrete.
- Page 7 (See Figure 6) Installing Fusion Mount to FCA103 Use four 5/16-18 x 5/8" hex head bolts (D) and four 5/16" washers (G) to secure Fusion rail mount to brackets (A and B).
- Page 8 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a products division Asia Pacific A Room 24F, Block D, Lily YinDu International Building of Milestone AV Technologies LuoGang, BuJi Town, Shenzhen, CHINA.
