Page 2
Connect the THINKCHECK M70 with your vehicle through the OBDII port Usually, the OBD port is located under the dashboard, above the pedal on the driver’s side. The five locations shown in the picture are common OBDII port locations. Turn on the THINKCHECK M70 After connecting with the car, the screen will display as shown in the picture.
Functions Description The THINKCHECK M70 main unit has the following 8 functions: 1. Scan: Read/clear enhanced manufacturer trouble codes, read/graph enhanced live data for ABS+SRS+ECM+TCM+BCM+AC+IC. 2. OBD: Support 10 modes. 3. Maintenance & Service: Four free options service resets from total 28 resets.
Page 4
You can do some basic set up on this page. Include Wi-Fi, screen brightness, language, time zone, and so on. Feedback: You can feedback the diagnostic software/app bugs to us for analysis and improvements. Screenshots: Turn on this switch to take a screen capture. Screen floating window: Turn on this switch to record the screen operation video.
THINKCHECK are authorized to make any confirmation, notice or promise related to THINKCHECK products. Service Line: 1-833-692-2766 Customer Service Email: support@thinkcarus.com Official Website: www.thinkcarus.com Products tutorial, videos, FAQ and coverage list are available on Thinkcar official website. Follow us on @thinkcar.official @ObdThinkcar...
Page 6
THINKCAR THINKCHECK M70 Manual de inicio rápido...
Page 7
Conecte el THINKCHECK M70 con su vehículo a través del puerto OBDII Por lo general, el puerto OBD se encuentra debajo del tablero de instrumentos, un pedal en el lado del conductor. Las cinco ubicaciones que se muestran en la ilustración son ubicaciones de puertos OBDII comunes.
Page 8
Descripciones La computadora host THINKCHECK M70 tiene las siguientes 8 funciones: 1. Escanear: Lectura / borrado avanzado del código de falla del fabricante, lectura / gráfica de datos en tiempo real mejorada para ABS + SRS + ECM + TCM + BCM + AC + IC 2.
Puede realizar una configuración básica en esta página. Incluido Wi-Fi, brillo de la pantalla, idioma, zona horaria, etc. Feedback: le permite enviarnos sus comentarios sobre los errores del software / aplicación de diagnóstico para analizarlos y mejorarlos. Capturas de pantalla: active este interruptor para realizar una captura de pantalla. Ventana de flojo de pantalla: active este interruptor para grabar el vídeo de funcionamiento de la pantalla.
Page 10
Términos de garantia Esta garantía se aplica únicamente a los usuarios y distribuidores que compren productos THINKCHECK INC www.thinkcarus.com THINKCHECK M70 mediante procedimientos normales. En el plazo de un año a partir de la fecha de entrega, THINKCHECK garantiza sus productos electrónicos por daños causados por defectos de materiales o mano de obra.
