Thinkcar XHINKCAR CE EVD User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Quick Start Manual
1.1 Initial Use
The following settings should be made when you initially use the device.
1.1.1 Device Power On
After long pressing the power button, the screen displays as follows.
1.1.2 User Agreement
Please read all the terms and conditions of the User Agreement carefully and check the box "Agree to the above terms".
1.1.3 Create An Account
Enter your cell phone number to register an account. If you already own other products of THINKCAR and have registered, you can directly
use your existing account to log in.
1.1.4 Activate the Device
To activate THINKDIAG 3 by entering its serial number and activation code to bind the device to THINKDIAG 3. If the device is not
activated, you can also tap "Settings" on the homepage and select "My Devices -> Activate Device" to do so.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XHINKCAR CE EVD and is the answer not in the manual?

Questions and answers

Related Manuals for Thinkcar XHINKCAR CE EVD

Summary of Contents for Thinkcar XHINKCAR CE EVD

  • Page 1 Please read all the terms and conditions of the User Agreement carefully and check the box "Agree to the above terms". 1.1.3 Create An Account Enter your cell phone number to register an account. If you already own other products of THINKCAR and have registered, you can directly use your existing account to log in.

  • Page 2: Product Overview

    II. Product Overview THINKCAR CE EVD/EVD Pro is a multifunctional diagnostic device for diagnosis, detection and measurement of new energy vehicle faults. It integrates main features/funtions of full system intelligent diagnosis battery pack diagnosis, fast charging detection, electric control line current detection, voltage detection, circuit signal measurement and intelligent module expansion, covering a comprehensive range of models, and can provide users with fast inspection and fast repair diagnosis services.
  • Page 3 ① Power Key Press the button for 3 seconds to turn on the power; Press the button for more than 8 seconds to force the power off; Tap the button to hibernate or wake up. ②Type C port: Use to connect the included charger for charging. ③USB port: Use to connect USB devices or expansion function (optional) modules.
  • Page 4 THINKDIAG 3 Indicator 2.2 Accessories In order to facilitate users to make quick troubleshooting for battery packs, THINKCAR provides 15 commonly used diagnostic cables for battery packs, as detailed in the following list. 2.2.1 List Of Battery Pack Diagnostic Cables (Standard)

  • Page 5: Extension Modules

    2.3 Extension Modules The device supports modular expansion function, you can choose to purchase different modules according to different usage scenarios, see the expansion list below. 2.3.1 Installation And Use Method Functional Modules: THINK printer, THINK wireless tire pressure diagnostic module, THINK thermal imaging The expansion module can be installed on the back of the mainframe.

  • Page 6: Device Connection

    (1) Unscrew the backplane screws and remove the backplane of the mainframe. (2) Insert one side of the expansion module into the device card slot. (3) Press the side snap of the expansion module and snap it into the device. (4) Automatic identification of the device and connection when the device is switched on.

  • Page 7: Start Using

    Connection steps. (1) Connect the THINKDIAG 3 to one end of the fast charging gun diagnostic cable (2) Connect the DC connector of the DC 12V adapter to the DC port of the fast charging gun, and connect the AC end of the 12V adapter to the power outlet (3) The fast charging gun is connected to the vehicle's fast charging port, which is usually located under the vehicle's front bumper logo or at the fast charging logo port on the left/right side of the vehicle...
  • Page 8 3.1.1 Full Vehicle Intelligent Diagnosis The whole-vehicle intelligent diagnosis supports fault detection, analysis and diagnosis of up to nearly 100 brand models, and can provide comprehensive diagnostic data analysis capability and expert-level auto health detection capability, which can quickly solve the diagnosis and testing problems such as whole-system fault location and analysis of new energy vehicles. Including commonly used brands, TOP20 brands, and nearly 100 new energy brand models such as Audi, BMW and Porsche.
  • Page 9 Note: The interface will be different for different models, refer to the actual diagnosed vehicle. (1) Select the test method: After successful connection, the screen will enter the test item selection interface. A. Intelligent scan: The device scans the vehicle's electronic control unit and checks whether the electronic control unit is normal by means of an intuitive topology diagram.
  • Page 10 Note: Reading fault codes when servicing vehicle faults is only a small step in the whole diagnostic process. The vehicle fault code is only used as a reference and the parts cannot be replaced directly on the basis of the definition of the fault code given.

  • Page 11: Online Programming

    Damage to the related module may result. • Make sure the THINKCAR CE EVD Pro host is fully powered. • To ensure communication and program stability, connect the THINKCAR CE EVD Pro main unit and the THINKDIA 3 multi-function diagnostic box with a wired connection.

  • Page 12: Tire Pressure

    3.1.5 Tire Pressure THINKCAR CE EVD/EVD Pro with THINK Wireless Tire Pressure Diagnostic Module enables TPMS activation, programming and learning functions. (a) Activation: This function allows you to activate the sensor ID, wheel pressure, sensor frequency, tire temperature and battery status.
  • Page 13 (b) Programming: This feature can be used to program sensor data to a blank THINKCAR sensor to replace a sensor that is low on power and not functioning properly. A total of three sensor programming methods are available : automatic, manual and copy by activation.

  • Page 14: Voltage Detection

    * Indicates that THINKCAR's ADAS calibration tool is an optional tool. This feature is disabled by default on the device and users need to purchase the ADAS calibration tool from THINKCAR and then use the activation card to activate the feature before it can be used. It is mainly used to calibrate various cameras and radars for driver assistance systems, such as front cameras for lane departure warning systems, radar sensors for ACC (Adaptive Cruise Control) or cameras for adaptive headlights.

  • Page 15: Diagnostic List

    * Indicates features and accessories supported by THINKCAR CE EVD Pro. 3.1.9 Multimeter The device integrates the functions of a multimeter and can measure a wide range of electronic components and electrical parameters such as AC current, DC current, AC voltage, DC voltage, resistance, diode, on-off test, etc.

  • Page 16: Diagnostic Report

    The diagnostic reports for vehicles with unrecognized VIN codes are sorted and displayed, and the access screen is shown below. 3.3 Maintenance THINKCAR CE EVD/EVD Pro supports matching, coding, programming and 24 common maintenance services for electronic control units and control systems of new energy vehicles.
  • Page 17 3.3.1 Brake-pad Reset If the brake pad wears the brake pad sense line, the brake pad sense line sends a signal sense line to the on-board computer to replace the brake pad. After replacing the brake pad, you must reset the brake pad. Otherwise, the car alarms.
  • Page 18 opened and used normally. In addition, when replacing the ignition switch key, ignition switch, combination instrument panel, engine control unit (ECU), body control module (BCM) and remote control battery, the anti- theft key matching is required. 3.3.12 High-Voltage Battery Health Testing For high voltage battery diagnostics and status information detection.

  • Page 19: Diagnostic Feedback

    To deselect a software, Tap the checkbox in front of the software. 3.5 Others 3.5.1 THINKCAR Mall THINKCAR Mall is a store containing THINKCAR diagnostic products for purchase launched by THINKCAR Technology. Each product has detailed feature descriptions and also supports online purchase. 3.5.2 Diagnostic Feedback If you encounter unsolvable problems in diagnostics or diagnostic software issues, you can send your last 20 test records back to THINKCAR.

  • Page 20: Remote Assistance

    Diagnostic Feedback : Displays a list of diagnosed features and diagnosed models. Feedback History : Display the list of all models that have been fed back, Tap to view the processing progress of all submitted diagnostic feedback. Offline list : Tap to view the diagnostic feedback of failed uploads due to network problems. Once the network is restored, the system will automatically upload to the server side.

  • Page 21: Maintenance Records

    3.5.4 Repair Info 3.5.4.1 Video View the introduction of THINKCAR CE series new energy diagnostic products and updated video materials about new energy products. 3.5.5 Instruction Manual An electronic version of the manual is provided so that users can view a detailed description of the device's features, how to use it, and frequently asked questions.
  • Page 22 3.5.7 Modules Mainly through the expansion interface or USB interface on the back panel of the device, you can use different functions of the THINKCAR expansion modules in different maintenance scenarios. Such as printing paper reports, fill light in dark environment, powertrain and HVAC heat distribution, etc.

  • Page 23: Thermal Imaging

    Access the THINKCAR work light module through the interface on the back of the device, and enter the work light operation function interface from "Other -> Module -> Work Light", as shown in the figure below. 3.5.7.3 Thermal Imaging Access the THINKCAR thermal imaging module through the interface on the back of the device, and enter the operational interface of thermal imaging from "Other ->...
  • Page 24 3.6.1 My Device If there are multiple THINKDIAG 3 registered under the same THINKCAR CE EVD/EVD Pro account, use this item to select the corresponding THINKDIAG 3. 3.6.2 Automatic Upgrade The user can choose whether the device needs to be automatically upgraded with the software package while connected to the network.
  • Page 25 3.6.14.1 About Mainly device hardware configuration, system information, including running memory, space used/storage, OS version, check for updates, device hibernation time, and privacy policy. 3.6.14.2 Diagnostic Unit System Settings Sets the unit of mileage representation in diagnostic data and diagnostic reports. The default is metric system. 3.6.14.3 Timing Set the time representation, including 12-hour and 24-hour.

  • Page 26: Current Clamp

    4.3 Current clamp THINKCAR CE EVC101 current clamp (hereinafter referred to as current clamp) is a detection tool for measuring AC current, DC current and DC voltage of new energy vehicles. It needs to be used with THINKCAR CE EVD Pro diagnostic host device.

  • Page 27: Operation Method

    ① Jaws: Put the tested wire. ② Indicator of the DC current. ③ Fill light: When the light is dim. ④ Fill light button: Switch button of the fill light. ⑤ Zero button: Zero button for clearing the external electric field during measurement. ⑥...

  • Page 28: Insulation Resistance Tester

    4.4 *Insulation Resistance Tester THINKCAR CE EVC201 insulation tester (hereinafter referred to as insulation tester) is an instrument for measuring the insulation characteristics of power motors, power batteries, power cables, high-voltage switches, transformers and other components of new energy vehicles. Using high-performance embedded processor and real-time operating system, it has the characteristics of high degree of automation, strong anti- interference ability, and automatic calculation of absorption ratio and polarization index.

  • Page 29: Interface Diagram

    4.4.1 Interface Diagram ① EARTH port: grounding jack (single-ended black wire) ② GUARD port: protection jack (single-headed green wire) ③ LINE port: voltage output jack (double-headed red wire) ④ LCD screen: For the specific screen display logo, please refer to Chapter 4.4.2.2 "LCD Screen Display" ⑤...

  • Page 30: Lcd Screen Display

    To shut down, press and hold the [Power] button on the instrument for 3 seconds until the screen turns off. The instrument will automatically power off after 15 minutes of inactivity. Note: In order to protect personal safety when charging, the instrument will automatically shut down. 4.4.2.2 LCD screen display ①...
  • Page 31 (2) Insert the red test wire into the LINE port on the instrument, and insert the black test wire into the EARTH port on the instrument. (3) Connect the red and black alligator clips to the circuit under test. When measuring DC voltage, if the red test line is a negative voltage, the "-"...

  • Page 32: Insulation Resistance Measurement

    • Do not input voltage higher than 600V or 600Vrms. Measuring higher voltages risks damaging the instrument. • When measuring high voltage, pay special attention to avoid electric shock. • After completing all measurement operations, disconnect the test leads from the circuit under test and remove the test leads from the input terminals of the instrument.
  • Page 33 • Press【COMP】key to enter the measurement mode of insulation resistance comparison function, and the comparison measurement mark on the screen will light up. Press △ / ▽ key to select output voltage value, press ◁ / ▷ key to set comparison resistance value (10MΩ, 20MΩ, 30MΩ, 40MΩ, 50MΩ, 60MΩ, 70MΩ, 80MΩ, 90MΩ, 100MΩ, 200MΩ, 300MΩ, 400MΩ, 500MΩ, 600MΩ, 700MΩ, 800MΩ, 900MΩ, 1GΩ, 2GΩ, 3GΩ, 4GΩ, 5GΩ, 6GΩ, 7GΩ, 8GΩ, 9GΩ, 10GΩ, 20GΩ, 30GΩ, 40GΩ, 50GΩ, 60GΩ, 70GΩ, 80GΩ, 90GΩ, 1200GΩ, 400GΩ, 500GΩ, 600GΩ, 700GΩ, 800GΩ, 900GΩ).

  • Page 34: Common Shortcuts

    1. Q: Is it possible to use the same type of charger to charge the device? A: No, please use the charger that comes with it for charging. We are not responsible for any damage or financial loss caused by using adapters not provided by THINKCAR. 2.Q: How do I save power? A: Turn off the screen when you are not using the device.

  • Page 35: Warranty Terms

    This warranty applies only to users and distributors who purchase THINKCAR products through normal procedures. Within one year from the date of delivery, THINKCAR warrants its electronic products for damages caused by defects in materials or workmanship. Damages Damages to the equipment or components because of abuse,...
  • Page 36 • For tutorials on the use of the product, more questions and answers, and a specific list of models covered, please visit the official website. Follow us @ thinkcar global...
