AV SURROUND RECEIVER
AVR-1712
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for Denon AVR-1712

Summary of Contents for Denon AVR-1712

  • Page 1 AV SURROUND RECEIVER AVR-1712 Owner’s Manual...

  • Page 2: Safety Precautions

    Install in accordance with the manufacturer’s instructions. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. approved by DENON may void your authority, granted by the FCC, to use Do not install near any heat sources such as radiators, heat registers, the product.

  • Page 3: Notes On Use

    n CAUTIONS ON INSTALLATION NOTES ON USE WARNINGS • Avoid high temperatures. Allow for sufficient heat dispersion when installed in a rack. • Handle the power cord carefully. Hold the plug when unplugging the cord. • Keep the unit free from moisture, water, and dust. • Unplug the power cord when not using the unit for long periods of time.

  • Page 4: Table Of Contents

    Getting started Thank you for purchasing this DENON product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading them, be sure to keep them for future reference. Contents Accessories Advanced version ·······························································31 Getting started ··············································································1 Speaker installation/connection (Advanced connection) ·······32...

  • Page 5: Features

    Features Cautions on handling • Before turning the power on Fully discrete, identical quality and power for all 6-HDMI inputs and 1-output Check once again that all connections are correct and that there are 7 channels (125 W x 7ch) The unit is equipped with 6 HDMI input connectors for connecting no problems with the connection cables.

  • Page 6: Basic Version

    Basic version Basic version Here, we explain the connections and basic operation methods for this unit. F Connections vpage 4 F Settings vpage 13 F Playback (Basic operation) vpage 20 F Selecting a listening mode (Surround mode) vpage 27 vpage 7, vpage 7, Connection Connection – vpage 21 Playback Playback...

  • Page 7: Connections

    Connections Important information • Make connections as follows before using this unit. Select an Relationship between video signals and monitor output appropriate connection type according to the devices to be connected. • You may need to make some settings on this unit depending GFlow of video signals for MAIN ZONEH on the connection method.
  • Page 8 Important information Examples of screen display • Menu screen • Status display screen When the input source is When the volume is adjusted. switched. Menu Audio Adjust Surr.Parameter Information Tone Setup Wizard AudysseySettings System Setup Manual EQ Input Setup RESTORER Audio Delay [Auto] Master Volume -55.5dB...

  • Page 9: Connecting An Hdmi-Compatible Device

    Connecting an HDMI-compatible device You can connect up to seven HDMI-compatible devices (6-inputs/1-output) to the unit. About 3D function HDMI function This unit supports input and output of 3D (3 dimensional) video signals of HDMI 1.4a. This unit supports the following HDMI functions: To play back 3D video, you need a TV and player that provide support for the HDMI1.4a 3D function and • 3D a pair of 3D glasses.
  • Page 10 Connecting an HDMI-compatible device Cables used for connections Audio and video cable (sold separately) • When this unit is connected to other devices with HDMI cables, connect this unit and TV also with an HDMI cable. HDMI cable • When connecting a device that supports Deep Color, please use a “High Speed HDMI cable” or “High Speed HDMI cable with Ethernet”.

  • Page 11: Connecting A

    Connecting a TV • Select the connector to use and connect the device. • For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 6). VIDEO AUDIO COMPONENT VIDEO VIDEO OPTICAL To listen to TV audio through this device, use the optical digital connection. NOTE The optical connection is not required when a TV compatible with the ARC function (Audio Return Channel HDMI 1.4a standard function) is connected to this unit via an HDMI connection.

  • Page 12: Connecting A Blu-Ray Disc Player/Dvd Player

    Connecting a Blu-ray Disc player/DVD player Connecting a set-top box (Satellite tuner/Cable TV) • You can enjoy video and audio from a Blu-ray Disc or DVD. • You can watch satellite or cable TV. • Select the connector to use and connect the device. • Select the connector to use and connect the device.

  • Page 13: Connecting A Digital Camcorder

    • For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 6). • For a control dock for iPod, use ASD-1R, ASD-11R, ASD-3N, ASD-3W, ASD-51N or ASD-51W made by DENON (sold separately). Cables used for connections • For instructions on the control dock for iPod settings, refer to the control dock for iPod’s operating instructions.

  • Page 14: Connecting An Antenna

    Connecting an antenna Connecting a CD player • Connect the FM antenna or AM loop antenna supplied with the unit n AM loop antenna assembly • You can enjoy CD sound. to enjoy listening to radio broadcasts. • Select the connector to use and connect the device. Put the stand section • After connecting the antenna and receiving a broadcast signal Stand...

  • Page 15: Connecting An External Control Device

    Connecting an external control device REMOTE CONTROL jacks If this unit is installed in a location that is out of range of the signal from the remote control unit, you can still operate the unit and the devices connected to it by using a commercially available IR receiver. You can also use it to remotely control ZONE2 (another room).

  • Page 16: Settings

    Settings Here, we explain “Audyssey ® Auto Setup”, which allows you to Set up speakers (Audyssey ® Auto Setup) automatically make the optimal settings for your speakers. n Set up speakers (Audyssey ® Auto Setup) The acoustic characteristics of the connected speakers and (vpage 13) About setup microphone placement listening room are measured and the optimum settings are made...
  • Page 17 Set up speakers (Audyssey ® Auto Setup) Set up the microphone Set up the subwoofer Set up the remote control unit Mount the setup microphone on a tripod or stand If using a subwoofer capable of the following n Set up the zone mode and place it in the main listening position.
  • Page 18 Set up speakers (Audyssey ® Auto Setup) STEP 2 STEP 1 Preparation Detect & Measure (Main) • In STEP 2, you will perform measurements at the main listening Connect the setup microphone to the SETUP MIC to select “Auto Setup Start” and then press position.
  • Page 19 Set up speakers (Audyssey ® Auto Setup) STEP 4 STEP 2 (Continued) STEP 3 Detect & Measure (Main) Measure (2nd – 8th) Calculate • In STEP 3, you will perform measurements at multiple positions (two NOTE On the screen, use to select “Next → to eight positions) other than the main listening position.
  • Page 20 Set up speakers (Audyssey ® Auto Setup) STEP 5 STEP 6 Finish Check Store Unplug the setup microphone from the unit’s SETUP ENTER to select the item you Select “Store” and then press MIC jack. want to check, and then press Save the measurement results.

  • Page 21: Error Messages

    Set up speakers (Audyssey ® Auto Setup) Error messages NOTE • An error message is displayed if Audyssey ® Auto Setup could not be completed due to speaker placement, the measurement environment, etc. If this happens, check the relevant items, be sure to take the necessary measures, then perform Audyssey ®...
  • Page 22 Set up speakers (Audyssey ® Auto Setup) Parameter Check This function enables you to check the measurement results and equalizer characteristics after Audyssey ® Auto Setup. to select “Parameter Check” and then press ENTER Auto Setup Parameter Check Auto Setup Sp.

  • Page 23: Playback (Basic Operation)

    Playback (Basic operation) n Using the “Source Select” menu Important information Settings (vpage 13) Switch the remote control unit to the (MAIN ZONE) mode when performing this operation (vpage 74 “Operating AV devices”). Before starting playback, make the connections between the different If the remote control unit is in (ZONE2) mode, the “Source n Selecting the input source (vpage 20)

  • Page 24: Playing A Blu-Ray Disc Player/Dvd Player

    Important information Playing a CD player Playing a Blu-ray Disc player/DVD Adjusting the master volume player The following describes the procedure for playing CD player. M df to adjust the volume. Prepare for playback. The following describes the procedure for playing Blu-ray Disc player/ Turn on the power of the subwoofer DVD player.

  • Page 25: Playing An Ipod

    Playing an iPod ® If you use a separately sold DENON control dock for iPod (ASD-1R, ASD-11R, ASD-3N, ASD-3W, ASD-51N or ASD-51W), you will be able • In “Browse mode”, the iPod display is as to play back videos, photos, music, and other content on the iPod.
  • Page 26 When an iPod equipped with a video function is connected to a Remote mode Operation buttons Function DENON ASD-11R, ASD-3N, ASD-3W, ASD-51N and ASD-51W MENU Amp menu This unit can play back on a TV screen photos and data stored on an control dock for iPod, image files can be played in the Browse iPod equipped with a slide show or video function.
  • Page 27 Playing an iPod iPod play function iPod 1 on the main unit is pressed when a control dock for iPod is connected, the iPod starts playback. Press iPod 1 • This unit’s input source switches to “DOCK”. • iPod playback starts.

  • Page 28: Tuning In Radio Stations

    Tuning in radio stations n Presetting radio stations (Manual preset) Default settings Listening to FM/AM broadcasts Your favorite broadcast stations can be preset so that you can tune Block (A – G) TUNER Press to switch the input them in easily. Up to 56 stations can be preset. Default Settings source to “TUNER”.
  • Page 29 Tuning in radio stations n Listening to preset stations n Direct frequency tuning n Tuner (FM/AM) operation You can enter the receiving frequency directly to tune in. Operation buttons Function SHIFT Press to select the memory CH +, – Preset channel selection block (A to G).

  • Page 30: Selecting A Listening Mode (Surround Mode)

    Selecting a listening mode (Surround mode) This unit can play input audio signals in multi-channel surround mode n Listening mode or in stereo mode. MOVIE MUSIC GAME DIRECT • The following listening modes can be selected using the , and buttons. Select a listening mode suitable for the playback contents (cinema, • Adjust the sound field effect with the menu “Surr.Parameter”...
  • Page 31 Selecting a listening mode z1 2-channel also includes analog input. Operation Operation Input signal Listening mode Input signal Listening mode z2 This mode plays back 2-channel source in 5.1 or 7.1-channel button button playback. It cannot be selected when headphones are used, or STEREO STEREO when only front speakers are used.
  • Page 32 Selecting a listening mode n Description of listening mode types Dolby listening mode DTS listening mode Listening mode type Description Listening mode type Description DOLBY PLgx This mode can be selected when a Dolby Pro Logic gx decoder is used to DTS NEO:6 This mode can be selected when a DTS NEO:6 decoder is used to play back 2-channel source in 6.1/7.1-channel surround sound including the surround...
  • Page 33 Selecting a listening mode DENON original listening mode Direct listening mode Listening mode type Description Listening mode type Description MULTI CH STEREO This mode is for enjoying stereo sound from all speakers. DIRECT Sound recorded in source is played as is.

  • Page 34: Advanced Version

    Advanced version Advanced version Here, we explain functions and operations that let you make better use of this unit. F Speaker installation/connection (Advanced connection) vpage 32 F Playback (Advanced operation) vpage 41 F Playback in ZONE2 (Separate room) vpage 45 F How to make detailed settings vpage 47 F Operating the connected devices by remote control unit vpage 74...

  • Page 35: Speaker Installation/Connection (Advanced Connection)

    Speaker installation/connection (Advanced connection) Here we describe the installation, connection and Install setup methods for speakers other than 5.1-channel speakers. For the installation, connection and setup When 7.1ch (Surround back speaker) installed methods for 5.1-channel speakers, see C page 4 This unit is compatible with Dolby Pro Logic gz (vpage ...
  • Page 36 Install When 7.1ch (Front height speaker) installed When 6.1ch (Surround back speaker) installed When Front A/B speakers installed FL(B) FL(A) FR(A) FR(B) Listening position Listening position Listening position z1 22˚ – 30˚ z2 22˚ – 45˚ z3 90˚ – 110˚ GSpeaker abbreviationsH z1 22˚...

  • Page 37: Connect

    Connect C page 6 “Connecting the • For the method of connecting 5.1-channel speakers, see speakers”. • For the method of connecting the TV, see C page 3 “Connect this unit to the television using an HDMI cable (sold separately)”. 7.1-channel (Surround back speaker) connection The illustration on the right shows a connection example for performing 7.1-channel playback using the surround back speakers.
  • Page 38 Connect 7.1-channel (Front height speaker) connection The illustration on the right shows a connection example for performing 7.1-channel playback using the front height speakers. If you connect the surround back and front height speakers before you start playback, the audio is played back by automatically switching the speakers in accordance with the surround mode or input signals.
  • Page 39 Connect 6.1-channel (Surround back speaker) connection If using only one surround back speaker (with a 6.1-channel connection), connect to the “L” side of the SURR. BACK/AMP ASSIGN terminal. For speaker settings in this case, see “When 6.1ch (Surround back speaker) installed” (vpage 33). To perform 6.1-channel playback using the surround back speaker, set “Amp Assign”...
  • Page 40 Connect Front A/B connection 2.1-channel connection You can connect a second set of speakers to this unit and use them for playback. In this case, set “Amp Assign” to “Front B” in steps 3 and 4 for “Set up “Amp Assign”” (vpage 39). FL(B) FL(A) FR(A)
  • Page 41 Connect Bi-Amp connection You can use the front speakers via the bi-amp connection. A bi-amp connection is to connect separate amplifiers to the tweeter terminals and woofer terminals of speakers compatible with the bi-amp function. This prevents the back electromotive force (returned force without output) of the woofer sent to the tweeter, which affects the sound quality of the tweeter, and you can enjoy playback with higher-quality sound.

  • Page 42: Set Up Speakers

    Set up speakers around items indicate the settings. Here we describe how to set up speakers other than 5.1-channel speakers. For the method of setting up 5.1-channel speakers, see C page 4 “Setup wizard”. First install and connect the speakers to this unit. Before Auto Setup measurement, the settings shown below can be made.
  • Page 43 Set up speakers select Press to select a front speaker. Set up “Channel Select” configuration of the connected to select “Channel Select”, and then press speakers. Select this to use front speaker A. ENTER Select this to use front speaker B. Audyssey Auto Setup Select this to use front speakers A and B simultaneously.

  • Page 44: Playback (Advanced Operation)

    Playback (Advanced operation) Convenient functions Settings (vpage 13) HDMI control function n Setting procedure Playback (Basic operation) (vpage 20) Set the HDMI output connector corresponding with If you connect the unit and an HDMI control function compatible TV or the HDMI control function. player with an HDMI cable and then enable the HDMI control function Selecting a listening mode (Surround mode) setting on each device, the devices will be able to control each other.
  • Page 45 Convenient functions Sleep timer function NOTE • When “HDMI Control” is set to “ON”, it consumes more The power automatically goes into standby once the set time has standby power. elapsed. • The HDMI control function controls operations of a TV that is This is convenient for playing sources while going to sleep.

  • Page 46: Adjusting The Volume Of The Speakers

    Convenient functions Adjusting the volume of the speakers n Adjusting the volume of groups of speakers Use o p to adjust the volume. (Fader function) You can adjust the channel level either according to the playback This function lets you adjust (fade) the sound all at once from the sources or to suit your taste, as described below.

  • Page 47: Various Memory Functions

    Convenient functions Quick select function n Recalling the settings Various memory functions QUICK SELECT Press at which the All of the settings in step 1 can be memorized together. By memorizing n Personal memory plus function frequently used settings, you can quickly access and enjoy a playback settings you want to call out are saved.

  • Page 48: Playback In Zone2 (Separate Room)

    Playback in ZONE2 (Separate room) • You can operate this unit so as to enjoy audio in a room (ZONE2) Playback other than the MAIN ZONE (room where the unit is located). • You can simultaneously play back the same source in both the MAIN Press ZONE SELECT to switch the...

  • Page 49: Quick Select Function

    Quick select function Sleep timer function It is also possible to save four settings for ZONE2. This is useful when you want to sleep while listening in ZONE2. n Recalling the settings n Saving the settings Press ZONE SELECT to switch the zone mode to (ZONE2).

  • Page 50: How To Make Detailed Settings

    How to make detailed settings Menu map For menu operation, connect a TV to this unit and display the menu on the TV screen. For menu operations, see the following page. Setting items Detailed items Description Page Audio Adjust Surr.Parameter Adjusts surround sound parameters.

  • Page 51: Examples Of Menu Screen Displays

    Examples of menu screen displays Typical examples are described below. GExample 2H Audyssey ® Auto Setup screen GExample 1H Menu selection screen (Top menu) (with illustration) Menu Audyssey Auto Setup MultEQ XT Audio Adjust Surr.Parameter Information Tone Preparation Setup Wizard AudysseySettings Set the following items System Setup...

  • Page 52: Examples Of Menu And Front Display

    Examples of menu and front display Below we describe typical examples of displays on the TV screen and on the set’s display window. Menu display Front display Description Top menu display MENU q Press to display the menu screen. Menu w TV screen: Displays the selected line.

  • Page 53: Inputting Characters

    Inputting characters Keyboard screen You can change the names as desired using the Using the keyboard screen “Preset Name” (vpage 69), “Rename” (vpage 72), “Zone Rename” (vpage 66), “Quick Sel.Name” (vpage 66). Display the screen for inputting n Display of a keyboard input screen For inputting characters, there are three methods, as shown below.
  • Page 54 (vpage 47 Example: For changing the input source from “DVD” to “DENON” “Menu map”). Repeat steps 3 and 4 to change the name then press q Place the cursor at “V”.

  • Page 55: Audio Adjust

    Audio Adjust The sound being played in the surround mode can be adjusted to your liking. Items that can be set with the “Audio Adjust” procedure The items (parameters) that can be adjusted depend on the signal being input and the currently set surround mode.
  • Page 56 Audio Adjust Surr.Parameter Setting items Setting details Default settings are underlined. –10dB – 0dB Adjust surround sound parameters. It may not be possible to set this item depending on the input signal Adjust the low-frequency For proper playback of the different sources, we recommend setting (vpage 87 “Surround modes and surround parameters”).
  • Page 57 Audio Adjust Setting items Setting details Setting items Setting details n For 2-channel sources Height Gain Low : Reduce the front height channel volume. S.Back Control front height Middle : Front height channel sound is output with standard sound Sets the method of ON : The surround back channel is used.
  • Page 58 Audio Adjust Tone Audyssey Settings Default settings are underlined. Set Audyssey MultEQ ® XT, Audyssey Dynamic EQ ® and Audyssey Dynamic Volume ® . These can be Adjust the tonal quality of the sound. selected after Audyssey ® Auto Setup has been performed. For additional information on Audyssey Setting items Setting details technology, please see page 92.
  • Page 59 Audio Adjust Setting items Setting details Setting items Setting details Dynamic EQ ® ON : Use Dynamic EQ ® . Dynamic Volume ® Midnight : Most adjustment to loudest and softest sounds. OFF : Do not use Dynamic EQ ® . Solve the problem of Solve the problem of large Evening : Medium adjustment to loudest and softest sound.

  • Page 60: Audio Delay

    Audio Adjust Manual EQ RESTORER Default settings are underlined. Compressed audio formats such as MP3, WMA (Windows Media Audio) and MPEG-4 AAC reduce the Use the graphic equalizer to adjust the tone of each speaker. “Manual EQ” can be set when “MultEQ ® XT” setting (vpage 55) is “Manual”. amount of data by eliminating signal components that are hard for the human ear to hear.

  • Page 61: Information

    Information Show information about receiver settings, input signals, etc. Items Setting details Items Setting details Status n MAIN ZONE Analog/PCM 2ch / Digital 2ch / Digital 5.1ch / Multi ch Auto Surround Show information about Show information about This item shows information about settings for MAIN ZONE. current settings.

  • Page 62: System Setup

    System Setup Set when changing Audyssey ® Auto Setup settings, or when changing the audio, video, display Items that can be set with the “System Setup” procedure or other settings. • If you change the speaker settings after performing Audyssey ® Auto Setup, it will not be possible to set Audyssey MultEQ ®...
  • Page 63 System Setup Setting items Setting details Speaker Setup Default settings are underlined. Speaker Config. Subwoofer : Set the presence of a subwoofer. (Continued) • Yes : Use a subwoofer. Perform when setting the speakers manually or when changing settings made in Audyssey ® Auto Setup. • No : Select when a subwoofer is not connected.
  • Page 64 System Setup Setting items Setting details Setting items Setting details Speaker Config. F.Height : Set the presence and size of the front height speakers. Distance Unit : Set the unit of distance. (Continued) • Large : Use a large speaker that can adequately play back low Set distance from listening • Feet / Meters frequencies.
  • Page 65 System Setup Setting items Setting details Setting items Setting details Channel Level Test Tone Start : Output test tone. Crossover Freq. Crossover : Set the crossover frequency. Set the volume of the test • Front L / F.Height L / Center / F.Height R / Front R / Surround R / Set the maximum frequency • 40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz / tone to be the same when it...

  • Page 66: Hdmi Setup

    System Setup Setting items Setting details HDMI Setup Default settings are underlined. Standby Source Last : This item is set at the last-used input source. Sets the HDMI input source HDMI1 / HDMI2 / HDMI3 / HDMI4 / HDMI5 / HDMI6 : Put the respective Make settings for HDMI video/audio output.
  • Page 67 System Setup Setting items Setting details Audio Setup Default settings are underlined. 2ch Direct/Stereo Distance FL / Distance FR : Select the speaker. (Continued) • 0.0ft – 60.0ft (12.0ft) / 0.00m – 18.00m (3.60m) : Set the distance to Make settings for audio playback. the speaker.
  • Page 68 System Setup ZONE2 Setup Option Setup Default settings are underlined. Default settings are underlined. Set the audio to play back with multi-zone (ZONE2). Make various other settings. “ZONE2 Setup” is displayed when “ZONE2” is selected with “Amp Assign”. Setting items Setting details Setting items Setting details...
  • Page 69 System Setup Setting items Setting details Setting items Setting details Screensaver : Make screensaver settings. Tuner : Set the tuner screen display time when the input source is Make the settings related to • ON : The screensaver is activated during menu (Continued) “Tuner”.
  • Page 70 System Setup Language Default settings are underlined. Set the language for display on the menu screen. Setting details English / Español “Language” can also be set by the following procedure. However, the menu screen is not displayed. 1. Press and hold the main unit’s 2 and 9 for at least 3 seconds. “V.Format:<NTSC>”...

  • Page 71: Input Setup

    Input Setup Perform settings related to input source playback. Items that can be set with the “Input Setup” procedure • You do not have to change the settings to use the unit. Make settings when needed. Menu operation Auto Preset (vpage 69) Press ZONE SELECT to switch the zone mode to...

  • Page 72: Auto Preset

    Input Setup Auto Preset Preset Name Use the auto preset function to program radio stations. Assign name to a preset memory. Setting items Setting details Setting items Setting details A / B / C / D / E / F / G Start Block If an FM station cannot be preset automatically, select the desired...

  • Page 73: Input Assign

    Input Setup Input Assign Setting items Setting details HDMI HDMI 1 / HDMI 2 / HDMI 3 / HDMI 4 / HDMI 5 / HDMI 6 Examples of “Input Assign” menu screen displays Set this to change the HDMI None : Do not assign an HDMI input connector to the selected input input connectors assigned source.
  • Page 74 Input Setup Video Setting items Setting details Default settings are underlined. COMPONENT COMP (Component video) 1, 2 (Component video) None : Do not assign a component video input connector to the selected Set the source video. Set this to change the input source.
  • Page 75 Input Setup Input Mode (Audio) Rename Default settings are underlined. The input modes available for selection may vary depending on the input source. Change the display name of the selected input source. Setting items Setting details Setting items Setting details Input Mode Auto : Automatically detect input signal and perform playback.

  • Page 76: Playback Mode

    One : A file being played is played repeatedly. mode. OFF : Repeat playback mode is canceled. DOCK Shuffle n When DENON control dock for iPod ASD-1R or ASD-11R is Make settings for shuffle connected mode. Songs : All files are played in shuffle playback mode.

  • Page 77: Operating The Connected Devices By Remote Control Unit

    Operating the connected devices by remote control unit Registering the supplied preset codes in the remote control unit Press the input source select button (vpage 20). NOTE enables you to operate devices made by other manufacturers. • The input source for the zone selected in step 1 is switched. If the mode of the remote control unit is set to other than AMP- • The operation mode of the remote control unit is switched as operation mode, press...

  • Page 78: Registering Preset Codes

    AMP- Category Brand Preset code select button operation mode. ZONE/DEVICE Z ZONE/DEVICE X Blu-ray Disc player DENON 32258 For switching power of each device on or off. Press MENU uio p ENTER RETURN B Satellite set top box...
  • Page 79 Then press ENTER Press the buttons with an interval less than 10 seconds. RemoteSetupGuide RemoteSetupGuide RemoteSetupGuide Device Device [1/4] Please select the Brand Denon Brand Denon first letter of the Code 30490[1/3] Code 30490[1/3] brand name 1.Press[INPUT SOURCE]. 1.Press[INPUT SOURCE].

  • Page 80: Operating Devices

    Registering preset codes Operating devices Either of the screens below is displayed. The supplied remote control unit can control a device other than this n CD player / CD recorder operation unit. Operation buttons Function Press the input source select uio p Cursor operation button to which the preset...
  • Page 81 Operating devices n DVD recorder / Personal video recorder (PVR) / Video n TV operation n Set top box for satellite (SAT) / Cable (CBL) / cassette recorder (VCR) operation IP TV operation Operation buttons Function CH +, – Switch channels (up/down) Operation buttons Function Operation buttons...

  • Page 82: Specifying The Zone Used With The Main Remote Control Unit

    Specifying the zone used with the Resetting the remote control unit main remote control unit Settings for the remote control unit are returned to the default values. ZONE SELECT When the button is pressed, only the set zone can be Press and hold ZONE/DEVICE Z operated with the remote control unit.

  • Page 83: Information

    Information Information Here, we list various information related to this unit. Please refer to this information as needed. F Part names and functions vpage 81 F Other information vpage 86 F Troubleshooting vpage 94 F Specifications vpage 97 F Index vpage 98...

  • Page 84: Part Names And Functions

    Part names and functions Front panel For buttons not explained here, see the page indicated in parentheses ( ). Q8 Q9 iPod system buttons ························································· (23, 96) Power operation button Master volume indicator (ON/STANDBY) ································································· • Stop button (2) Display ······················································································ (82) Turns power to this unit on and off (standby).

  • Page 85: Display

    Display Audyssey ® indicators Decoder indicators RESTORER indicator Light up as follows, depending on the setting of “MultEQ ® XT”, These light when the respective decoders are operating. This lights when the RESTORER mode is selected (vpage 57). 55), “Dynamic EQ ® ” (vpage ...

  • Page 86: Rear Panel

    Rear panel See the page indicated in parentheses ( ). FM/AM antenna terminals ····················································· (11) HDMI connectors ··························································· 3, 7) NOTE Analog audio connectors ·············································· (9, 10, 11) Digital audio connectors ······················································· (8, 9) Do not touch the inner pins of the connectors on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

  • Page 87: Remote Control Unit

    Remote control unit For buttons not explained here, see the page indicated in parentheses ( ). ZONE SELECT button ·························· (45, 74) SOURCE SELECT button ··························· (20) Zone mode indicators ································ (74) Master volume control buttons (M df) ················································· (21, 45) Input source select buttons ·················...
  • Page 88 Remote control unit Inserting the batteries Operating range of the remote control unit Point the remote control unit at the remote sensor when operating it. q Slide the rear lid in the w Load the two batteries properly direction of the arrow and as indicated by the marks in remove it.

  • Page 89: Other Information

    Other information Trademark information n Trademark information (vpage 86) This product uses the following technologies: n Surround (vpage 87) n Relationship between video signals and monitor output (vpage 91) n Explanation of terms (vpage 92) HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

  • Page 90: Surround

    Surround This unit is equipped with a digital signal processing circuit that lets you play program sources in the surround mode to achieve the same sense of presence as in a movie theater. Surround modes and surround parameters This table shows the speakers that can be used in each surround mode and the surround parameters adjustable in each surround mode. Symbols in the table S This indicates the audio output channels or surround parameters that can be set.
  • Page 91 Surround Surr.Parameter (vpage 53) Audyssey Settings z17 (vpage 55) NEO:6 Music PRO LOGIC g/gx Music mode only mode only Tone RESTORER PLgz Height AFDM Surround mode (vpage 27) Height Gain S.Back Subwoofer Dynamic Dynamic EQ ® (vpage 55) MultEQ ® XT Volume ® (vpage 57) (vpage 54) (vpage 54) (vpage 54)
  • Page 92 Surround n Types of input signals, and corresponding surround modes This table shows the input signal that can be played in each surround mode. Check the audio signal of the input source then select the surround mode. Symbols in the table F This indicates the default surround mode.
  • Page 93 Surround Input signal types and formats DTS-HD DOLBY DOLBY DIGITAL NOTE Surround mode (vpage 27) DTS-HD DTS-HD High DTS ES DTS ES DOLBY DIGITAL ANALOG DOLBY DOLBY DOLBY DIGITAL DOLBY DIGITAL DOLBY DIGITAL Master Resolution DSCRT MTRX DTS 96/24 EX (With no (multi ch) (2ch) EXPRESS...

  • Page 94: Relationship Between Video Signals And Monitor Output

    Relationship between video signals and monitor output Input connector Output connector Menu displayed HDMI COMPONENT S-VIDEO VIDEO HDMI COMPONENT VIDEO HDMI COMPONENT VIDEO Only the menu is displayed S <VIDEO> Only the menu is displayed A (VIDEO) S <S-VIDEO> Only the menu is displayed A (S-VIDEO) S <COMPONENT>...

  • Page 95: Explanation Of Terms

    Explanation of terms Dolby Digital Dolby Pro Logic gz DTS 96/24 Dolby Digital is a multi-channel digital signal format Dolby Pro Logic gz introduces a new dimension to DTS 96/24 is a digital audio format enabling high Adobe RGB color, Adobe YCC601 color developed by Dolby Laboratories.
  • Page 96 Explanation of terms DTS-HD Master Audio MP3 (MPEG Audio Layer-3) DTS-HD Master Audio is a lossless audio format This is an internationally standardized audio data x.v.Color created by Digital Theater System (DTS). This compression scheme, using the “MPEG-1” video This function lets HDTVs display colors more format provides the facility to support up to 8 audio compression standard.

  • Page 97: Troubleshooting

    • This unit amplifier circuit has failed. Turn off the power and please – No picture appears. • Check the TV connection. power, the power contact the DENON service adviser. • Set the TV input correctly. indicator is blinking red in intervals of approximately 0.5 seconds.
  • Page 98 GAudioH Symptom Cause/Solution Page Symptom Cause/Solution Page Dolby TrueHD, DTS- • Make HDMI connections. Audio is not output. • Check the connections for all devices. HD, Dolby Digital Plus audio is not 7, 8, 9, output. 10, 11, 12 • Check the speaker connections and configurations. • Check that “Speaker Config.” – “Center” or “Surround” is set Dolby PLg mode or 34, 35, 36, to other than “None”.

  • Page 99: Resetting The Microprocessor

    GiPodH Resetting the microprocessor Symptom Cause/Solution Page Perform this procedure if the display is abnormal or if operations cannot be performed. The file names • Characters that cannot be displayed are used. This is not a – When the microprocessor is reset, all the settings are reset to their default values. are not displayed malfunction.

  • Page 100: Specifications

    Specifications n Audio section n Tuner section [FM] [AM] • Power amplifier (Note: μV at 75 Ω, 0 dBf = 1 x 10 –15 Rated output: Front: Receiving Range: 87.5 MHz – 107.9 MHz 520 kHz – 1710 kHz 90 W + 90 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.) Usable Sensitivity: 1.2 μV (12.8 dBf) 18 μV...
  • Page 101 Connection Index Antenna ··························································· 11 Effect Level ························································ 53 MAIN ZONE ······················································· 93 Blu-ray Disc player ········································· 7, 9 v Numerics EQ Customize ···················································· 64 Manual EQ ························································· 57 Cable TV····························································· 9 Error messages (Auto Setup) ····························· 18 Master volume ··················································· 66 2.1-channel ·························································...
  • Page 102 Rch Level ··························································· 65 Video ·································································· 71 Rear panel ·························································· 83 Video Mode ························································ 71 Reference Offset ··············································· 56 Video Select ······················································· 71 Remote control setting ································ 14, 39 Volume Control ·················································· 65 Remote control unit ····································· 74, 84 Volume Display ·················································· 65 Inserting the batteries······································...
  • Page 103 Dimensions Unit : in. (mm) 17 1/8 (435.0) Weight : 22 lbs 7.8 oz (10.2 kg)
  • Page 104 D&M Holdings Inc. 3520 10050 000D...
