Solax T-BAT SYS-HV User Manual

Triple power lithium-ion battery 50ah

Hide thumbs

Table Of Contents

Quick Links

Download this manual

SolaX Power Network Technology (Zhejiang) Co., Ltd.

Add.: No. 288, Shizhu Road, Tonglu Economic Development Zone, Tonglu City,

Zhejiang Province, 310000 P.R. CHINA

Tel.: +86 (0) 571-56260011

E-mail: info@solaxpower.com

No part of this document may be reproduced or transmitted in any form or by any means without

prior written consent of SolaX Power Technology (Zhejiang) Co., Ltd. (hereinafter referred to as

SolaX). SolaX reserves the right of final interpretation.

320101004910

Triple Power Lithium-ion Battery

50Ah

User Manual

Table of Contents

Need help?

Do you have a question about the T-BAT SYS-HV and is the answer not in the manual?

Questions and answers

Summary of Contents for Solax T-BAT SYS-HV

Page 1 No part of this document may be reproduced or transmitted in any form or by any means without Tel.: +86 (0) 571-56260011 prior written consent of SolaX Power Technology (Zhejiang) Co., Ltd. (hereinafter referred to as SolaX). SolaX reserves the right of final interpretation.
Page 2: Change History
CHANGE HISTORY Changes between document versions are cumulative. The latest version contains all updates made in previous versions. Version 10 (Aug. 31, 2023) Updated 2.1.2 Explanation of Symbols (deleted a caution) Updated 3.3 Speci cation (changed the storage temperature range and model) Updated 8 Maintenance (changed the storage temperature range) Version 09 (Nov.
Page 3: Table Of Contents
3.1.2 APPEARANCE......................8 MAINTENANCE ............................BASIC FEATURES....................3.2.1 FEATURES........................10 DISCLAIMER ..............................3.2.2 CERTIFICATIONS....................10 WARRANTY REGISTRATION FORM SPECIFICATIONS....................11 3.3.1 T-BAT SYS-HV CONFIGURATION LIST............ 11 3.3.2 PERFORMANCE....................11 .......................12 INSTALLATION INSTALLATION PREREQUISITES...............12 SAFETY GEAR....................... 12 TOOLS........................13 INSTALLATION..................... 13 4.4.1 CHECK FOR TRANSPORT DAMAGE............ 13 4.4.2 UNPACKING......................
Page 4: Note On This Manual Scope Of Validity
This manual is an integral part of T-BAT Series. It describes the assembly, installation, commissioning, maintenance and failure of the product. Please read it carefully before operating. T-BAT SYS-HV T-BAT H 5.8 / T-BAT H 5.8 V2 T-BAT PACK-HV HV11550 / HV11550 V2 NOTE: There are 4 models for T-BAT system, including BMS and battery packs.
Page 5: Safety
The inverter complies with the requirements of the applicable Explanation Symbol T-BAT SYS-HV can only be used in the household energy eld. It is not allowed to CSA guidelines be used in other industries, such as the medical equipment industry and 272687 automotive application industry.
Page 6: Response To Emergency Situations
Response to Emergency Situations 2.2.1 Leaking Batteries TUV mark for IEC62619 If the battery leaks electrolyte which is corrosive, avoid contact with the leaking liquid or gas. Direct contact may lead to skin irritation or chemical burns. If one is exposed to the leaked substance, do these actions: The battery system should be disposed of at a proper facility Accidental inhalation of harmful substances:Evacuate people from the for environmentally safe recycling.
Page 7: Qualified Installer
WARNING! 3.1.1 Demension and Weight A battery management system (BMS) is an electronic system that manages a All operations of T-BAT SYS-HV relating to electrical connection and rechargeable battery. installation must be carried out by quali ed personnel. Battery is a type of electrical battery which can be charged, discharged into a load.
Page 8: Appearance
3. Product Introduction 3. Product Introduction 3.1.2 Appearance Section view of HV11550 / HV11550 V2 Ÿ Section view of T-BAT H 5.8 / T-BAT H 5.8 V2 Ÿ Ⅰ Ⅴ Ⅵ Ⅰ’ Ⅱ’ Ⅵ’ Ⅶ’ XPLUG YPLUG BAT- BAT+ YPLUG Ⅴ’...
Page 9: Basic Features
3. Product Introduction 3. Product Introduction Basic Features Speci cations 3.2.1 Features The T-BAT SYS-HV is one of the advanced energy storage systems on the market 3.3.1 T-BAT SYS-HV Con guration List today, incorporating state-of-the-art technology, high reliability, and convenient Energy Voltage...
Page 10: Installation
4. Installation 4. Installation Installation Tools These tools are required to install the T-BAT system. Installation Prerequisites Before installation, make sure that the installation site meets the following conditions: • The building is designed with resistance to earthquakes; • The location is far away from the sea, to avoid sea water and humid air; Torque Screwdriver Phillips Screwdriver Hexagon Wrench...
Page 11: Accessories
Ring terminal (for grounding) Documents Document Note: 1. The above-mentioned accessories are only for one battery module. SolaX will provide corresponding accessories according to the number of battery modules. 2. The mark “*” indicates that the connector connecting to inverter on the charging...
Page 12: Battery Installation Steps
4. Installation 4. Installation 4.4.4 Battery Installation Steps There are two installation ways, wall mounting and oor mounting. I. Wall mounting It is recommended to keep a distance of 350 mm between two battery packs. Such a distance must be between 320 mm and 380 mm. Steps (for T-BAT H 5.8 (T-BAT H 5.8 V2) or HV11550 (HV11550 V2)): Make sure the wall is strong enough to withstand the weight of battery.
Page 13 4. Installation 4. Installation II. Floor mounting Steps (for T-BAT H 5.8 (T-BAT H 5.8 V2) or HV11550 (HV11550 V2)), please refer to the steps for wall mounting on page 16. Note: It is recommended to keep a distance of 350 mm between two battery packs.
Page 14: Cable Connection
4. Installation 4. Installation Cable Connection For T-BAT H 5.8/T-BAT H 5.8 V2 + 1~3 battery packs: 1. Connect “-” (V for T-BAT H 5.8 (T-BAT H 5.8 V2) or VI' for HV11550 (HV11550 V2)) 4.5.1 Connecting Power Cables between Battery Packs on the right side to “+”...
Page 15: Connecting Power Cables To Inverter
4. Installation 4. Installation 4.5.2 Connecting Power Cables to Inverter Ø Connecting Charging Cables between Inverter and T-BAT System: 1. Connect the the positive cable (+) (A) and negative cable (-) (B) to the This step is going to connect power cables between inverter and T-BAT system. BAT+ and BAT- respectively as shown in the following gure.
Page 16 4. Installation 4. Installation Disassembling Power cable (on BAT+, BAT-, “+”, XPLUG port) Ø Ø Disassembling Power Cable (on ”-”, YPLUG port) Disassemble the power cable by plugging the slot type screwdriver or the Power Disassemble the power line by plugging the Power cable disassembling tool(L) cable disassemble tool(L) to the terminal groove of the power cable.
Page 17: Connecting Bms Communication Cable
4. Installation 4. Installation 4.5.4 Connecting RS485 Communication Cable 4.5.3 Connecting BMS Communication Cable For T-BAT H 5.8/T-BAT H 5.8 V2: It is required for the BMS to communicate with the inverter for proper operation. There's no need to use RS485 communicaton cable. 1.
Page 18: Connecting Ground Wire
4. Installation 4. Installation 4.5.6 Overall Installation 4.5.5 Connecting Ground Wire It is recommended to protect the cables with corrugated pipe. The terminal point for GND connection is on the side of grooves as shown below: For T-BAT H 5.8/T-BAT H 5.8 V2: Cable size: 10AWG.
Page 19: Overview Of Installation
4. Installation 4. Installation For T-BAT H 5.8/T-BAT H 5.8 V2 + 1~3 battery packs: Overview of Installation 1. Connect the cables at one end of the T-BAT H 5.8/T-BAT H 5.8 V2 or Hv11550/HV11550 V2. The following diagram is a completed T-BAT system installation with 2.
Page 20: Commissioning
5. Commissioning 5. Commissioning Commissioning Commissioning Con guing Batery System NOTE! The DIP switch is used to con gue the number of battey packs which are When powering on the BMS, the system will start self-testing. If the communicating to inverter. The detailed con guration inomation is shown as buzzer bips, it means DIP con guration fault or communication failue follows: occurs.
Page 21: Status Indicators
5. Commissioning 5. Commissioning Status Indicators Commissioning Steps The LED indicators on the front panel of the battery pack are showing the If all the battery packs are installed, follow these steps to put it in operation. operating status. 1. Remove the upper cover board of T-BAT H 5.8/T-BAT H 5.8 V2; 2.
Page 22: Battery Pack
6. Troubleshooting 5. Commissioning 5.3.2 Battery Pack Troubleshooting Troubleshooting Check the indicators on the front to determine the state of the T-BAT system. A warning state is triggered by a condition, for example, when voltage or temperature is beyond the designed limitations. The T-BAT system's BMS periodically reports its operating state to the inverter.
Page 23 BMS_CapMismatch_Fau battery packs are company directly for servicing. Contact your distributor or diﬀerent The capacities of BMS_CellImblance SolaX directly for servicing. cells are diﬀerent The software BMS_SlaveSwVer_Mism Contact your distributor or Contact your distributor or betwen slavers are Battery hardware...
Page 24: Decommissioning
8. Maintenance 7 7 . Decommissioning Maintenance Decommissioning Dismantling the Battery -If the ambient temperature for storage is -20~30°C, recharge the batteries at Shutting down T-BAT system least one time every 12 months. Disconnect the cables between BMS and inverter -If the ambient temperature for storage is 30~55°C, recharge the batteries at Disconnect the short-circuit plug on the last battery module least once every 6 months.
Page 25: Disclaimer
Signature Please visit our warranty website: https://www.solaxcloud.com/#/warranty to complete the online warranty registration or use your mobile phone to scan the QR code to register. For more detailed warranty terms, please visit SolaX oﬃcial website: www.solaxpower.com to check it. 614.00002.07...
Page 26 PLEASE REGISTER THE WARRANTY IMMEDIATELY AFTER INSTALLATION! GET YOUR WARRANTY CERTIFICATE FROM SOLAX! KEEP YOUR INVERTER ONLINE & WIN SOLAX POINTS! Open your Wait for the camera app camera to and point recognize your device the QR code at the QR code Notiﬁcation...

This manual is also suitable for:

T-bat h 5.8 T-bat h 5.8 v2 T-bat pack-hv Hv11550 Hv11550 v2
