Terex Genie S-45 XC Operator's Manual
Hide thumbs
Also See for Genie S-45 XC:
- Operator's manual (17 pages) ,
- Operator's manual supplement (15 pages) ,
- Maintenance manual (198 pages)
Related Manuals for Terex Genie S-45 XC
Summary of Contents for Terex Genie S-45 XC
- Page 1 Operator's Manual Supplement Off-Center Transport Lock Original Instructions First Edition Fourth Printing Part No. 1286694GT...
- Page 2 First Edition: Fourth Printing, September 2022 Genie and "S" are registered trademarks of Terex South Dakota, Inc. in the U.S.A. and many other countries. "XC" and "TraX" are trademarks of Terex South Dakota, Inc. These machines comply with Complies with EC Directive 2006/42/EC...
- Page 3 First Edition • Fourth Printing Operator's Manual Supplement Introduction Off-Center Transport Lock Read, understand and obey all warnings and instructions provided with the OCTL. OCTL assembly 1309977GT weighs 12.15 lbs./5.5 kg. OCTL assembly 1295702GT weighs Danger 26.8 lbs./12.2 kg. Failure to obey the instructions and OCTL assembly 1312240GT weighs 16.3 lbs./7.4 kg.
- Page 4 Operator's Manual Supplement First Edition • Fourth Printing Introduction Contents of Kit 1309977 Contents of Kit 1295702 For S-45 approved models: For S-65 approved models: Item Part No. Decal Description Item Part No. Decal Description 123839 Lanyard Assembly 1295642 Block Pin, Transport Lock 218457 Screw, HHF, M5-0.8X12, DIN6921, 1298405 Pin, Ball Lock, 5/8"X4"...
- Page 5 First Edition • Fourth Printing Operator's Manual Supplement Introduction Contents of Kit 1312240 For S-85XC approved models: Item Part No. Decal Description 123839 Lanyard Assembly 218457 Screw, HHF, M5-0.8X12, DIN6921, 10.9 1290025 Label – Warning, Crushing Hazard, 50X25 1312380 Decal, Lock Transport 1312153 Weldment, Transport Lock 1312154 Pin Block, Transport Lock 1312155 Knob, Tethered Threaded-Stud,...
-
Page 6: Symbol And Hazard Pictorials Definitions
Operator's Manual Supplement First Edition • Fourth Printing Introduction Symbol and Hazard Pictorials Definitions Read the supplement, part number 1286694GT. Crushing hazard 1290025 C Off-Center Transport Lock Part No. 1286694GT... -
Page 7: Pre-Operation Inspection
First Edition • Fourth Printing Operator's Manual Supplement Introduction Inspect the retainer pin and the holes in the Pre-operation Inspection OCTL for damage, excessive wear and corrosion. Verify the operator’s manual and any necessary supplements are complete, legible and in the storage container located in the platform. - Page 8 Operator's Manual Supplement First Edition • Fourth Printing Introduction Decal Inspection - S-45 XC, S-45 XC Trax Use the inspection to verify that all decals are legible and in place. Decals may vary depending on machine configuration. These decals are also applicable to S-45 XC Trax, even if the picture does not show the tracks.
- Page 9 First Edition • Fourth Printing Operator's Manual Supplement Introduction Decal Inspection - S-65 XC, S-65 XC Trax Use the inspection to verify that all decals are legible and in place. Decals may vary depending on machine configuration. These decals are also applicable to S-65 XC Trax, even if the picture does not show the tracks.
- Page 10 Operator's Manual Supplement First Edition • Fourth Printing Introduction Decal Inspection - S-85 XC Use the inspection to verify that all decals are legible and in place. Decals may vary depending on machine configuration. Part No. Decal Description 1290025 Label – Warning, Crushing Hazard, 50X25 1312380 Decal, Lock Transport, S85 XC 1312368...
-
Page 11: Installation Instructions
First Edition • Fourth Printing Operator's Manual Supplement Installation Instructions Installation Instructions Installation Instructions For S-45 XC and S-65 XC approved models For S-45XC Approved Models (from S45XCH-1198 and S45XCD-440), for S- 65XC Approved Models and for S-85XC Approved Models (from S-85XCD-101): Perform this procedure with the platform located at the non-steer end of the machine. - Page 12 Operator's Manual Supplement First Edition • Fourth Printing Installation Instructions "For S-45XC approved models Move the control handle to the right and the turntable will rotate to the right. Move the (to S45XCH- 1197 and S45XCD-439): control handle to the left and the turntable will Remove the part numbers shown below that rotate to the left until there is enough will be used for the new forming installation.
