- Page 1 Midilift SL/GL Dual Control Installation Supplement Midilift SL/GL Dual Control Platform Lift Installation Supplement (to be read in conjunction with Midilift SL Installation Guide) 28-07-15 Issue 2...
-
Page 2: Table Of Contents
Midilift SL/GL Dual Control Installation Supplement Contents INTRODUCTION ............................3 SAFETY EQUIPMENT AND PRECAUTIONS ..................... 3 CARRIAGE ..............................4 PLATFORM FRAME ............................ 5 PLATFORM DECK ............................5 PLATFORM WALL ............................6 DOCUMENT HISTORY ..........................9 28-07-15 Issue 2... -
Page 3: Introduction
Installation Supplement INTRODUCTION The installation procedure for the Dual Control Midilift SL/GL is almost identical to the standard Midilift SL & GL products. This Installation Supplement is therefore intended to be read in conjunction with the Midilift SL Installation Guide. This supplement only details those areas which differ from the standard SL/GL product. -
Page 4: Carriage
Midilift SL/GL Dual Control Installation Supplement CARRIAGE The Dual Control platform is heavier than a 2000mm carriage: standard SL/GL platform, so the loads imposed on the guide rails are higher. To keep the stress levels in the aluminium guide rails within acceptable limits, the carriage is supplied with bogie roller assemblies instead of single rollers. -
Page 5: Platform Frame
Midilift SL/GL Dual Control Installation Supplement PLATFORM FRAME Platform frame ≈ 56kg The Dual Control platform frame is wider than the standard platform and also incorporates brackets which are used to Feed wiring loom up connect the side wall to the platform. -
Page 6: Platform Wall
Midilift SL/GL Dual Control Installation Supplement PLATFORM WALL Attaching the wall frame to the platform Before installing the wall frame, ensure that the deck screws have been Wall installed. Once the wall is frame in position it is not possible to reach one of the screws! Wall frame ≈... - Page 7 Midilift SL/GL Dual Control Installation Supplement Attaching the wiring loom to the wall frame Feed the wiring loom up between the rear panel and the two central horizontal members. Fasten the cable(s) to the tab on the underside of both horizontal members, using cable ties through the holes provided.
- Page 8 Midilift SL/GL Dual Control Installation Supplement Attaching the cable shield to the trailing cable bracket Trailing cable Trailing cable Self drill screw Self drill screw Fasten the top end of the cable shield to bracket bracket the bottom corner of the trailing cable bracket using a self drill screw.
-
Page 9: Document History
Midilift SL/GL Dual Control Installation Supplement DOCUMENT HISTORY Issue Name Changes Date Issue 1 R Christopher First issue 14/04/2015 Issue 2 R Christopher 'Carriage' section added to show roller configuration 28/07/2015 28-07-15 Issue 2...
