3. Specifications

3.1

Housing and Connectors

 Housing
 Mounting
 Connectors
3.2

Environmental conditions

Temperature in use
Humidity in use
IP protection
3.3

Power Supply Specifications

Isolation
Input voltage
- Phoenix Contact EG22.5-G/ABS GN housing
- RAL6021 color
- ABS material
- Flame retardant UL 94V-0
- Dimensions: 107.5x75x22.5mm (LxHxW)
- standard DIN rail, with snap-in foot
- the DinBox GSM M4 must be mounted vertically on a flat
surface within a height of maximum 2 meters above the
floor level.
- power plug (screw connector) has a pitch of 3.81 mm
for a maximum wiring section 1.31 mm
- 2.54 mm pitch RS-232 and RS-485 connections
- standard RJ-45 Ethernet connector
- SMA 50 ohm antenna connector
-20°C / + 55°C
10%RH - 75%RH (non condensing)
IP2X
none
voltage input
maximum consumption
- this power supply input is polarity protected
- there is no build-in fuse
2
9 ~ 25Vdc
W
