3.
Specifications
3.1
Housing
Phoenix Contact EG22,5 ABS DIN rail housing
(EG22.5-G/ABS GN + EG22.5-A/ABS GN)
?? 22.5 mm 107.5 mm x 75 mm
?? IP40
?? Symmetrical DIN rail mounting according EN50 022
?? Green color
Standard ABS
Acryl Butadiene Styrene – Tmax = 80 °C
Inflammability class acc. to UL 94 : HB
Optional PC (only on special request)
Polycarbonate – Tmax = 115 °C
metal DIN-rail clip
Inflammability class acc. to UL 94 : V0
Bausch Datacom NV
DinBox PSTN Reference manual – V1.3
8
