5.3
Ethernet interface
This 10/100 Mbit/s LAN interface is primarily used to configure the DinBox GSM M4.
Default IP address is 192.168.1.44 / 255.255.255.0.
HTML is available on standard port 80.
5.4
Antenna interface
The GSM antenna must be connected on the GSM modem via a cable, depending on
the application and the GSM RF field strength at the site. The antenna interface
connector is SMA (female).
Never use the DinBox GSM M4 modem
without a proper antenna attached!
